BENDIX TU-FLO 550 COMPRESSOR Manual page 21

Symptom:
2.0 Oil on the Engine and/or other accessories
Outside of the leaking onto compressor.
Compressor
(a) Leak at the front or rear (fuel
2.1 Oil leaking at
compressor / engine
connections:
(b) Leak at air inlet fi tting.
(c) Leak at air discharge fi tting.
(d) Loose/broken oil line fi ttings.
2.2 Oil leaking
from compressor:
(a)
3.0 Oil at air dryer
purge/exhaust or
surrounding area
What it may indicate:
pump, etc.) mounting fl ange.
(a) Excessive leak at head gasket.
(b) Leak at bottom cover plate.
(c) Leak at internal rear flange
gasket.
(d) Leak through crankcase.
(e) (If unable to tell source of leak.)
Head
gaskets
and rear
fl ange
gasket
(c)
locations.
Air brake charging system functioning
normally.
What you should do:
Find the source and repair. Return the vehicle
to service.
Repair or replace as necessary. If the
mounting bolt torques are low, replace the
gasket.
Replace the fi tting gasket. Inspect inlet
hose and replace as necessary.
Replace gasket or fi tting as necessary to
ensure good seal.
Inspect and repair as necessary.
Go to Test 1 on page A-14.
Reseal bottom cover plate using RTV
silicone sealant.
Replace compressor.
Replace compressor.
Clean compressor and check periodically.
(c)
Air dryers remove water and oil from the air
brake charging system.
Check that regular maintenance is being
performed. Return the vehicle to service.
An optional kit (Bendix piece number
5011327 for the Bendix
air dryers, or 5003838 for the Bendix
air dryer) is available to redirect the air dryer
exhaust.
AD-IS or AD-IP ™
® ®
™
AD-9
®
A-5
