Summary of Contents for OPTICOM OWB-1605

  • Page 1 OWB - 4 0 5 OWB - 8 0 5 OWB - 1 6 0 5...
  • Page 2 This symbol is intended to alert the user to the presence of unprotected “Dangerous voltage" within the product's enclosure that may be strong enough to cause a risk of electric shock. This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 3 All the safety and operating instructions must be read before the unit is operated. Make sure to switch the power off before you install the DVR. • There is the danger of an electric shock if the DVR is opened by an unqualified service •...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS Chapter 1 FEATURES ......................1 Chapter 2 MAIN MENU OPERATION..................2 2.1 Quick Setup ......................2 2.2 Network Remote Instructions..................4 2.3 Playback Mode .......................5 2.4 PTZ Mode.......................6 Chapter 3 INSTALLATION ....................8 3.1 System Configuration .....................8 3.2 Hard Disk Installation....................9 Chapter 4 BASIC OPERATION and MENU SETUP ............11 4.1 Main Menu Setup....................
  • Page 5: Chapter 1 Features

    Chapter 1 FEATURES Two USB ports (for mouse usage and backup). Dual streaming enhances the speed of network transmission Built-in VGA output up to 1024x768 resolution Individual setup of resolution, frame rate and video quality for each channel Still image snapshot AVI converter with time stamp H.264 compression ideal for saving HDD space Real time live display...
  • Page 6: Chapter 2 Main Menu Operation

    Chapter 2 MAIN MENU OPERATION 2.1 Quick Setup Graphic Icons Resting the cursor on this icon will bring up the four (Main Menu/ Search/ Backup/ PTZ) menu icons. MAIN MENU. SEARCH SETUP. BACKUP. PTZ CONTROL. Turn On/Off recording. PLAYBACK Resting the cursor on this icon will bring up five (PAUSE/ PIP/ ZOOM/ AUTO SEQ/ LOCK) display icons.
  • Page 7 GUI Hints and Tips Recording is on Number represents the current selected LIVE audio channel Live Audio is off Motion detected on the channel Sensor triggered on the channel Video loss detected on the channel USB device detected DVR has been connected onto the Internet. AUTO-SEQ is on FREZZE is on, screen is frozen LOCK is on...
  • Page 8: Network Remote Instructions

    2.2 Network Remote Instructions Same user and DVR-site interface, the only difference is network toolbar which is situated on the lower bottom right. Icon Description Low Video Quality (LQ) High Video Quality (HQ) * Please refet to 4.7.2 HTTP setup Full Screen Record Capture Image...
  • Page 9: Playback Mode

    2.3 Playback Mode Playback – Quick Function Icon Press button to Fast Rewind Speed : 2x, 4x, 8x, 16x, 32x, 64x Press button to Fast Forward Speed : 2x, 4x, 8x, 16x, 32x, 64x Press PLAY / button to Play/ Pause Playback / SLOW slow playback Speed : 1/2x, 1/4x, 1/8x, 1/16x stop playback...
  • Page 10: Ptz Mode

    2.4 PTZ Mode PTZ – Remote Controller Control / SLOW Move PTZ up. Move PTZ down. Move PTZ to the left. Move PTZ to the right. ZOOM + PTZ zoom-in. ZOOM - PTZ zoom-out. FOCUS + PTZ focus-in. PTZ focus-out. FOCUS - IRIS + PTZ iris-open.
  • Page 11 Same as [PIP]. Set current PTZ location as the starting point of the line-scan. Same as [FREEZE]. Activate line-scan. Same as [ZOOM]. Set current PTZ location as the ending point of the line-scan. To move PTZ in 360° PTZ zoom in or PTZ zoom out. PTZ focus in or PTZ focus out.
  • Page 12: Chapter 3 Installation

    Chapter 3 INSTALLATION 3.1 System Configuration...
  • Page 13: Hard Disk Installation

    3.2 Hard Disk Installation Step 1: Remove the 3 screws from DVR as cycled below (PIC 1). Step 2: Remove the front cover from DVR as indicated by the arrow (PIC 2).
  • Page 14 Step 3: Place the HDD on the HDD plate and connect the power and the SATA cables (PIC 3). Step 4: Screw the bottom of the DVR as indicated as cycled (PIC 4).
  • Page 15: Chapter 4 Basic Operation And Menu Setup

    Chapter 4 BASIC OPERATION and MENU SETUP 4.1 Main Menu Setup To enter the main menu and setup the DVR, please log-in account and enter user password. The default password of the administrator is “123456”. Please refer to “Account Setup” for related setup of other log-in users. Main Menu –...
  • Page 16: Record Setup

    Main Menu – Remote Control ler and Front Pannel Control (Click MENU button to enter Quick Setup Menu ) Switch to different options under one item Switch to different items Press to confirm setup (OK) Press to cancel setup (CANCEL) Enter the menu, or display virtual keyboard 4.2 Record Setup...
  • Page 17 Item Description Select STOP to stop recording or OVERWRITE to reuse the HDD when HDD is full. HDD FULL [Stop] Stop Recording [Overwrite] Start to overwrite beginning from the oldest data of HDD, and continue to record. OSD Position X Set time stamp of OSD position X OSD Position Y Set time stamp of OSD position Y...
  • Page 18: Event Setup

    4.3 Event Setup Item Description Motion Setup Enter to set up motion detection Sensor Setup Enter to set up sensor detection 4.3.1 Motion Setup...
  • Page 19 Item Description Alarm Duration(Seconds) Alarm duration time (1~60 seconds). Check the box to Enable/ Disable popup screen function for all channels. Motion Popup When motion is detected in LIVE mode, the detected channel image will popup in full screen display. Enable Check the box to Enable/ Disable motion detection for each channel.
  • Page 20 4.3.2 Sensor Setup Item Description Alarm Duration(Seconds) Alarm duration time (1~60 seconds). Sensor Popup Check the box to Enable/Disable popup screen function for all channels. When Sensor is detected in LIVE mode, the detected channel image will pop up in full screen display. Sensor Polarity Click or press to select between HIGH/ LOW voltage for triggering...
  • Page 21: Schedule Setup

    4.4 Schedule Setup Apart from manual recording, you can also setup the recording time by weeks and schedule recordings include: normal, motion detection, and sensor detection. Item Description Click or press to select Page. Each page provides 10 schedules for Page setup.
  • Page 22: Camera Setup

    Item Description Enables schedule recording according to the time Enable Schedule Record schedule (shown below). Enables schedule motion detection recording Enable Schedule Motion Detect according to the time schedule (shown below). Enables schedule sensor trigger recording according to Enable Schedule Sensor Trigger the time schedule (shown below).
  • Page 23: Account Setup

    Item Description Mask Check the box to Enable/ Disable mask function for LIVE mode Drag the white bar or press to adjust Sharpness of your camera from Sharpness value 0 to 15. The default value is 1. Drag the white bar or press to adjust Brightness of your camera from Brightness value 0 to 255.
  • Page 24: Network Setup

    4.6.1 Permission Setup The Account Setup is set to provide individual user (maximum of 4 users) role-based permissions, including access to Setup menu, Network operation, PTZ function, Playback, Utility, Backup and Mask on specific channels while playing back. 4.7 Network Setup...
  • Page 25 Item Description Setup mode for network connection: ADSL DHCP LAN. Connect type HTTP Setup Enter to set up HTTP for remote access into DVR. DDNS Setup Enter to Enable/ Disable DDNS function and set up. Mail Setup Enter to Enable/ Disable Email notification and setup. 4.7.1 Networking Setup The DVR supports DHCP, LAN and ADSL access for network connection.
  • Page 26 4.7.1.2 LAN Select LAN for network connection, the following information is required. Item Description Enter IP address provided by ISP IP Address Enter IP address of Subnet Mask provided by ISP Subnet Mask Gateway Enter IP address of Gate way provided by ISP Enter DNS address provided by ISP.
  • Page 27 4.7.1.3 ADSL Select ADSL for network connection, the following information is required. Item Description User Name Enter user name provided by ISP Password Enter password provided by ISP...
  • Page 28 4.7.2 HTTP Setup Item Description Check to enable HTTP server. Users can remotely access into the DVR Enable HTTP Server over the network if the HTTP function is activated. Enter a valid port value from 1 up to 65535. The default value is 80. Port Quality and Frame Rate Setup for Network Transmission Check to activate the transmission of each camera.
  • Page 29 4.7.3 DDNS Setup Item Description Enable DDNS Check/ Uncheck to Enable/ Disable DDNS function. Select the DDNS Server wanted. DDNS Server Host Name Enter the registered hostname. User Name Enter user name. Password Enter password. 4.7.4 Mail Setup...
  • Page 30 E-mail can be used as a form of notification when an event occurs (VLOSS, MOTION, and SENSOR). Item Description Enable E-mail Notification Check the box to enable/disable E-mail Notification function. SMTP Server Enter to set up SMTP Server name. User Name Enter to set up User Name.
  • Page 31: Ptz & Rs-485 Setup

    4.8 PTZ & RS-485 Setup The DVR allows users to control PTZ functions of your camera. To enable PTZ function, the 485 cable should be connected to the RS-485 port of DVR. Item Description Enable PTZ Click the box to Enable/Disable PTZ function for each channel. Protocol Set up the protocol of PTZ cam.
  • Page 32: System Setup

    4.9 System Setup Item Description DVR Name The name of DVR will be shown when users login from remote access. DVR Location The location of DVR will be shown when users login from remote access Language Click or press to select OSD language. Auto-Seq Interval Click or press to set up duration time in seconds for the interval...
  • Page 33 4.9.1 Display Setup Item Description Auto-Seq Interval Click or press to set up duration time in seconds for the interval ( Seconds) between channels under Auto-Seq mode (1~999 seconds). Turn On / Off OSD display Show OSD Show DVR Status Turn On / Off DVR illustration and record status display Show Date/Time Turn On / Off date and time display...
  • Page 34 4.9.2 Date/ Time Setup Item Description Hour Format 12HOURS/ 24HOURS MM-DD-YY/DD-MM-YY/YY-MM-DD Date Format Date/Time Position Choose the position of Time and Date display Change Date & Time Setup time and date of DVR Time Zone Setup Set up GMT and Daylight Saving Time. Internet Time Setup Setup automatic synchronization with internet server 4.9.2.1 Change Date &...
  • Page 35 4.9.2.2 Time Zone Setup In time zone setup, users can change the time zone and activate Daylight Saving Time function according to your DVR location. Item Description Select Time Zone Enter to modify GMT from GMT- 13 to GMT+ 13 Daylight Saving Time Turn On/ Off Daylight Saving Time 4.9.2.3 Internet Time Setup...
  • Page 36 Item Description Check to enable DVR automatic synchronization function. Select this Automatic Synchronization option to enable the function, DVR will automatically synchronize the time upon rebooting or by every 24 hours after booting. Date and Time show on DVR will immediately correspond with those in Update Now internet server.
  • Page 37 Item Description Mouse Speed Adjust the mouse moving speed Buzzer & Relay Setup Key Tone Enable/ Disable keystrokes. Enable/ Disable buzzer operation when the alarm is triggered for HDD ALARM BUZZER error, sensor, motion and vloss (Video Loss). Enable/ Disable the signal to be sent to the RELAY OUT blocks when the ALARM RELAY alarm is triggered for HDD error, sensor, motion and vloss.
  • Page 38: Utility Setup

    4.10 Utility Setup Item Description Select to enter hard disk initialization menu. Please stop recording before entering this menu. Enter the menu, system will show all the HDD Initialization data (model/ volume) of HDD that is installed in the DVR. Check the HDD you’d like to initialize, then press “Start”.
  • Page 39: Diagnostic

    4.11 Diagnostic Item Description Version The current firmware version of DVR The connected IP address of DVR. If disconnected from network, the IP Address screen will display” NETWORK DISCONNECT”. MAC Address MAC Address of DVR HDD Volume The capacity of HDD HDD Used Rate Percentage of space used on HDD.
  • Page 40: Chapter 5 Search & Backup

    Chapter 5 SEARCH & BACKUP 5.1 Search Setup Item Description Event Search Press to enter event search menu. Time Search Press to enter time search menu. 5.1.1 Event Search...
  • Page 41 The DVR automatically records events with type, time and channel information included. If there is recording data for an event, a yellow signal icon will be shown on the left side of time information. Rest your cursor under the line and press “enter”, or left click your mouse to playback the recording data.
  • Page 42 The amount of events can be numerous. Therefore, you can facilitate event sorting by setting up “criteria”. Setup “start time” and “end time” for each event search, then the search result will be limited to this specific period of time. Only events and channels that are ;...
  • Page 43: Backup Setup

    Click “date” to display recording time of that specific date with time bar. You can change time (hour/ minute/ second) or click on a specific time of time bar by mouse then press “YES”. DVR will playback the selected recording data. 5.2 Backup Setup User can back-up any segment of recorded data in a specified time frame.
  • Page 44: Chapter 6 Specification

    Chapter 6 SPECIFICATION Video System NTSC / PAL switch Video Input 4CH BNC Video Input Level 1.0 Vp-p Composite, 75 Ohm Balanced Video Output 1CH BNC SPOT Output 1CH BNC 1024x768 VGA Output Audio Input 1CH RCA Audio Input Level 0.5~1.4 Vp-p @ 20K Ohm Audio Output 1CH RCA...
  • Page 45 Post-Alarm 1-60 sec Recording Motion Detection 22X18 (sensitivity 0~10) PLAYBACK Search Mode Time, Event fast forward/backward 2X/4X/8X/16X/32X/64X Playback Speed slow forward/backward 1/2X,1/4X,1/8X,1/16X play/pause Backup Mode USB flash driver / Network NETWORK Network H.264 Compression Software Internet Explorer 3G Mobile Phone Support Network Users Remote Notification...
  • Page 46: Chapter 7 Network Surveillance

    Chapter 7 NETWORK SURVEILLANCE 7.1 Remote Connection Step 1 Enter the IP address of the DVR in the IE browser. Provides two different ways of DVR connection, one is the use the Internet Explorer; the other to download and install the software to the PC. Step 2: A window will pop-up.
  • Page 47 Step 3: You’ve logged into the DVR Internet Explorer Software Application...
