Summarization of Contents
Model Limitations Due to Prototypical Accuracy
Track Precision Requirements
Model requires precise track; M-track may cause issues.
Coupler Pocket Height
Coupler pockets are lower than NEM 362; use included couplers only.
Wheel Accessibility for Tire Changes
Wheels are deep, making traction tire changes difficult.
Connecting Multiple Motor Cars
Do not connect two motor cars via current-conducting couplers.
Safety Notes
System Compatibility and Power Supply
Use only designated Märklin systems and local power supplies.
Interference Suppression and Environmental Factors
Use interference suppression for analog, avoid direct sun/moisture.
Sharp Edges and Points Warning
Warning about sharp edges and points for safety during operation.
General Notes
Manual and Packaging Retention
Keep operating instructions and packaging with the product.
Repairs and Spare Parts Information
Contact authorized Märklin dealer for repairs or spare parts.
Website and Warranty Information
Website link and warranty details provided.
Locomotive Functions Overview
Automatic Mode Recognition and Addresses
Auto-detects system mode; adjustable addresses for various control units.
Mfx Technology and Factory Name
Features mfx technology; factory name is BR 798 667-2.
Adjustable Speed and Acceleration Parameters
Allows adjustment of acceleration, braking delay, and max speed.
Directional Headlights and Control Car Disabling
Headlights change with direction; can be turned off on the coupled end.
Analog Operation Limitations
Only driving and headlight functions available in analog mode.
Controllable Functions
Headlights and Interior Lighting Control
Controls headlights and interior lighting via function f0.
Headlights Off at Coupler End
Turns off headlights on the coupler end via function f1.
Operating Sounds Control
Activates operating sounds via function f2.
Horn Sound Control
Activates horn sound via function f3.
Adjustable Acceleration/Braking Delay (ABV)
Controls acceleration/braking delay via function f4.
Brake Squealing Sound Control
Controls brake squealing sound via function f5.
Door Closing Sound Control
Controls door closing sound via function f6.
Bell Sound Control
Activates bell sound via function f7.
Departure Whistle Sound Control
Activates departure whistle sound via function f8.
CV (Parameter) Reference
Address CV
CV 01 for setting the locomotive address.
Acceleration Delay CV
CV 03 for adjusting acceleration delay.
Braking Delay CV
CV 04 for adjusting braking delay.
Maximum Speed CV
CV 05 for setting the maximum speed.
Reset to Series Values CV
CV 08 to reset parameters to factory defaults.
Volume CV
CV 63 for adjusting volume levels.
Brake Hose Mounting Instructions
Mounting Condition
Mount brake hoses only when no other vehicle is coupled to this end.
Changing Traction Tires
Body and Floor Separation
Steps to separate the motor car body from the floor.
Circuit Board and Interior Removal
Instructions for removing circuit boards and interior detailing.
Motor and Spring Removal
How to lift the motor and remove springs.
Wheel Set Removal and Tire Replacement
Procedure for removing wheel sets and changing traction tires.
Reassembly and Final Checks
Steps for reassembling the rail bus correctly.
