Page 72: Serial Port Control
Serial Port Control •••••••••••••••••••••••••••••••••••••••••••••••••••••••• RS232 communication cable (please use cross data cables) This Device Computer RXD0 TXD0 TXD0 RXD0 ••••• •••• RS232 port of panel Cover Connect RS-232 port to the PC or controlling product. Enable RS-232 serial port connection and complete the following configuration. Port: COM1 (Set according to PC or controlling product's port number) Baud rate 1 9200...
