JRC NSVA352 Manual

JRC SAW FILTER
Application
1575.42MHz GPS
Electrical Specification: (Table 1)
The device characteristics are measured in the circuit shown in Fig.1.
Table 1. Electrical Specifications
Item
Input and Output Impedance
Nominal Center Frequency (f0)
Insertion Loss
Response Variation
Input and Output VSWR
Out of Band Rejection
(Relative to
Through Level)
Maximum Rating: (Table 2)
Table 2. Maximum Ratings
Item
Maximum Input Power
Maximum DC Voltage
Operating Temperature Range
Storage Temperature
Mechanical Specifications: (Fig.2)
Package is designed as small as 3.5x3.5x1.0[mm
Notice:
This part is electrostatic discharge sensitive and may be damaged by improper handling.
Communications Equipment Marketing Department
http://www.jrc.co.jp/jp/product/device/saw/index.html
http://www.jrc.co.jp/eng/product/saw/index.html
NSVA352
1574.42~1576.42MHz
1574.42~1576.42MHz
1574.42~1576.42MHz
1475.42MHz
1535.42MHz
1615.42MHz
1675.42MHz
Rating
+20dBm
7.5V
-40~+85ºC
-50~+100ºC
Communications Equipment Division
10-1, Nishi-Shinjuku 6-chome, Shinjuku-ku,
Tokyo, 160-8328 Japan
Tel. +81 3-3348-3845
Fax. +81 3-3348-3935
Spec.
-
-
3.5dB max.
1.5dB max.
2.5 max.
40dB min.
30dB min.
20dB min.
40dB min.
(Operating Temperature Range: -40~+85ºC)
3
] for SMD (Surface Mount Device) type.
(Japanese)
(English)
NSVA352 Oct. 2004
Typ.
50Ω
1575.42MHz
2.8dB
0.5dB
1.8
50dB
45dB
40dB
50dB
