JRC NSVA300 Manual

JRC SAW FILTER

Application

Cordless telephone
Electrical Specification: (Table 1)
The device characteristics are measured in the circuit shown in Fig.1.
Table 1. Electrical Specifications
Item
Input and Output Impedance
Nominal Center Frequency (f0)
Insertion Loss
Response Variation
Input and Output VSWR
Out of Band Rejection
(Relative to
Through Level)
Maximum Rating: (Table 2)
Table 2. Maximum Ratings
Item
Maximum Input Power
Maximum DC Voltage
Operating Temperature Range
Storage Temperature
Mechanical Specifications: (Fig.2)
Package is designed as small as 3.5x3.5x1.0[mm
Notice:
This part is electrostatic discharge sensitive and may be damaged by improper handling.
Communications Equipment Marketing Department
http://www.jrc.co.jp/jp/product/device/saw/index.html (Japanese)
http://www.jrc.co.jp/eng/product/saw/index.html (English)
NSVA300
913.3~915.7MHz
913.3~915.7MHz
913.3~915.7MHz
DC~<834.5MHz
834.5~872.9MHz
959.5~974.5MHz
<974.5~1500MHz
(Operating Temperature Range: -10~+60ºC)
Rating
+20dBm
7.5V
-10~+60ºC
-25~+70ºC
Communications and Device Group
10-1, Nishi-Shinjuku 6-chome, Shinjuku-ku,
Tokyo, 160-8328 Japan
Tel. +81 3-3348-3845
Fax. +81 3-3348-3935
Spec.
-
- 914.5MHz
3.5dB max. 2.5dB
1.5dB max. 0.5dB
2.5 max.
55dB min. 65dB
45dB min. 55dB
30dB min. 50dB
55dB min. 65dB
3
] for SMD (Surface Mount Device) type.
NSVA300 Oct. 2004
Typ.
50Ω
1.8
