- Page 1 USER MANUAL Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English...
- Page 2 ▌Important Notice Paragraphs beginning with the symbol indicate important instructions, tips or conditions for the following settings. For your own safety and the optimal performance of your device, ensure to read the safety instructions before performing any installation. Compatibility with 3rd party products, software and services are not guaranteed. We cannot be held liable for any damage or loss suffered whilst operating, using or connecting to incompatible devices or apps.
- Page 3 The intended use and ambient conditions for this device This device is intended for the rendering of video and audio signals, on a table-top, in a home or office environment. It must not be used in rooms with a high level of humidity or dust concentration. The warranty is only valid if used as intended by the manufacturer. WARNING High humidity and dust concentration may lead to current leaks in the device.
- Page 4 „ Power Supply - Do not place the power cable near a high temperature object. - Do not move the device with the power cable plugged into a Incorrect voltages can damage the device. Only connect this unit socket. to a power supply with the correct voltage and frequency noted - Do not use a damaged or loose power cable, or a damaged on the type plate, using the supplied power cable.
- Page 5 „ Warning about off-gassing „ Long periods of absence New furniture, carpet, paint, building materials and electronics As long as the power plug is connected to a live socket outlet, can release chemicals into the air through evaporation. After the device will consume power even in standby mode. The power you set your device up and turn it on for the first time, you may plug and all connected antenna cables should be disconnected notice a slight smell within a couple of hours.
- Page 6 „ Packaging „ Outdoor Antenna Grounding Keep the anti-moisture materials and plastic bags out of reach of If an outdoor antenna used, be sure the antenna system is children. protected against voltage surges and built-up static charges. Plastic bags can cause suffocation and the anti-moisture material „...
- Page 7 - If any object or water enters this device, please unplug this flammable. device and contact the service staff of Hisense. - Clean the lens periodically with a clean cloth and make - Do not place any exposed fire source (e.g. burning candle) sure the Laser TV is turned off before you start.
-
Page 8: Table Of Contents
Congratulations on the purchase of your new Laser TV! This Manual will walk you through a few easy steps to set up your Laser TV. Please visit Hisense official website for more details. Product image is only for reference, actual product may vary in appearance. -
Page 9: Accessories List
Accessories List • Laser TV × 1 • Laser TV User Manual × 1 • Remote control × 1 • Laser TV European Guarantee × 1 • AA or AAA batteries × 2 • Cleaning kit for the lens × 1 •... -
Page 10: Laser Tv Diagram
Laser TV Diagram Remote control receiver Air vents Power Indicator Eye protection sensor Lens with laser Power button We strongly recommend that two people handle this device when moving it from one place to another. Be sure to protect the lens when you handle this device. -
Page 11: Step 1 Mount The Screen
STEP 1 Mount the Screen Screen installation please refer to the specific screen installation guide! STEP 2 Install the Laser TV We strongly recommend that two people handle this device when moving it from one place to another. Be sure to protect the lens when you handle this device. - Page 12 (not included) Satellite antenna NOTE: ANT1 Jack supports power supply for satellite antenna (13/18V, 0.5A max.) Ethernet (you will need a router for Internet connectivity) CAM CARD SMART CARD Outdoor Antenna Cable ANT OUT Antenna Cable (75Ω) VHF/UHF Antenna NOTE: Before you insert/remove the CI+ module, ensure that the Laser TV is switched off.
- Page 13 NOTE: When connecting a hard disk or a USB hub, always connect the mains adapter of the connected device to the power supply. Exceeding a total current consumption may result in damage. The USB1.1 and USB2.0 devices maximum current consumption are 500mA. The USB3.0 device maximum current consumption is 1A. For individual non-standard high-capacity mobile hard disk, if its impulse current is greater than or equal 1A, it may cause Laser TV-rebooting or self-locking.
- Page 14 Wired setup LAN ( Connect your Laser TV to your network by connecting the LAN port on the back of your Laser TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below. Laser TV PORT IP Sharer (Router) External Modem (with DHCP server)
- Page 15 WARNING: Insufficient ventilation space will cause Plug the power cord into a wall outlet. this device to overheat or become damaged. Press the POWER button to turn on the Laser TV. • Do not block the air vents or place any object on this device. •...
-
Page 16: Step 3 Adjust The Display Image And The Screen
STEP 3 Adjust the Display Image and the Screen FIT THE BOTTOM OF THE IMAGE TO THE SCREEN • Follow the steps in the order shown below, only if they apply to • Make sure the bottom of the image always stays parallel your situation. - Page 17 ADJUST THE UPPER-RIGHT CORNER OF THE IMAGE ADJUST THE UPPER-LEFT CORNER OF THE IMAGE 1. If the top of the image is lower on the left and higher on the 1. If the top of the image is higher on the left and lower on the right, rotate the front-right foot clockwise.
- Page 18 FILL THE TOP OF THE IMAGE TO THE SCREEN If the top of the image is wider than the screen, rotate the left- and right-front feet clockwise. If the top of the image is narrower than the screen, rotate the left- and right-front feet counterclockwise, until the left and right borders of the image Next, move the Laser TV further from the screen to fill the image...
-
Page 19: Step 4 Use Your Remote
STEP 4 Use Your Remote BUTTONS ON YOUR LASER TV REMOTE NOTE: The button labels are provided as a reference. The actual appearance of the remote that is included with the Laser TV, may differ from this diagram. POWER: Switch the Laser TV on or into standby MIC: Activate the microphone mode SUBTITLE: Activate or deactivate the subtitle... - Page 20 BUTTONS ON YOUR LASER TV REMOTE NOTE: The button labels are provided as a reference. The actual appearance of the remote that is included with the Laser TV, may differ from this diagram. POWER: Switch the Laser TV on or into standby mode INPUT: Select input sources APP: Quick access buttons to apps : Display the Quick setup menu...
- Page 21 BUTTONS ON YOUR LASER TV REMOTE NOTE: The button labels are provided as a reference. The actual appearance of the remote that is included with the Laser TV, may differ from this diagram. POWER:Switch the Laser TV on or into standby mode INPUT: Select input sources MIC: Activate the microphone : Enter Channels / input numbers and special function buttons (Red/Green/Yellow/Blue)
- Page 22 REMOTE CONTROL RANGE INFORMATION 1. Slide the back cover to open the battery • The remote control can work at a distance of up to 8 metres compartment of the remote control. in front of the Laser TV. (This distance is used by infrared means in an unpaired state.) •...
-
Page 23: Step 5 Proceed Through The Screen Setup Menu
STEP 5 Proceed through the Screen Setup Menu PROJECTION MODE If you need to flip the image over top-to-bottom and/or left-to- right, select the Projection Mode. Alignment grid AUTO GEOMETRIC CORRECTION 4. Click "+" on your mobile device to take a photo of the full Before you use Auto Geometric Correction function, ensure screen. - Page 24 MANUAL GEOMETRIC CORRECTION Select points and move it to fit the projected image into the screen. NOTE: Manual Geometric Correction may not be applicable in some models/countries/regions. 1. Press / / < / > buttons on your remote control to move focus, and press OK button to choose a point you need to adjust.
-
Page 25: Maintenance & Quick Problem-Solving Tips
Maintenance • Do not touch this device when it is running or just turned off because it may be hot. • Do not wipe this device with oil because it may deteriorate the exterior or damage the paint. Contact with rubber or ethylene products for a long time may cause stains on this device. - Page 26 The picture is normal but there is no sound 1. Check the volume settings. 2. Check if 'Mute' mode is set to On. Sound but no picture or black and white picture 1. If the picture is black and white, unplug the Laser TV from the AC outlet and replug it after 60 seconds. 2.
-
Page 27: Product Specifications
Product Specifications Model Name 90" Laser TV 20.9 × 4.6 × 13.2 inches Dimension (W × H × D) (531 × 117 × 335 mm) Weight 16.9 lbs (7.7 kg) Active Screen Size (Diagonal) 90 inches Screen resolution 3840 × 2160 Audio power 2 ×... - Page 28 Temperature: 41°F - 104°F (5°C - 40°C) Environmental conditions Humidity: 20% - 80% RH Atmospheric pressure: 86 kPa - 106 kPa RGB / 60Hz (640×480, 800×600, 1024×768) YUV / 60Hz (480i, 480p, 720p, 1080i, 1080p) HDMI Input YUV / 50Hz (576i, 720p, 1080i, 1080p) 3840×2160 / 24Hz, 3840×2160 / 25Hz, 3840×2160 / 30Hz 3840×2160 / 50Hz, 3840×2160 / 60Hz Network Standby Power Consumption ≤...
-
Page 29: Recycling / Licenses
The terms HDMI and HDMI High-Definition Recycling / Licenses Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of WEEE (Waste Electronic Electric Equipment) HDMI Licensing Administrator, Inc. in the European Directive 2012/19/EU United States and other countries. This symbol on the product or on its packaging indicates that this product must not be disposed of with your household Dolby, Dolby Vision, Dolby Atmos, and... - Page 30 SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, Hisense Visual Technology Co., Ltd. declares that the radio equipment type [90L5HE / 90L5HD / 90L5HD-PRO / 90L5HD- LITE / 90L5HCHD / 90L5HCHD-PRO / 90L5HCHD-LITE / 90L5HTUKD / 90L5HTUKD-PRO / 90L5HTUKD-LITE / 90L5H / 90L5H1...
- Page 31 ES-A2222Z0-1 A...
