Summarization of Contents
Installation Location and Ceiling Bracket
Choosing the Right Installation Location
Verify room dimensions for clearance and ensure outlet box suitability for fan support.
Installing the Ceiling Bracket
Secure the ceiling bracket using machine screws or wood screws based on mounting location.
Hanging and Wiring the Fan
Hanging the Fan
Lift the motor assembly into the ceiling bracket and secure it with locking screws.
Wiring the Fan
Connect fan wires to ceiling wires based on single or dual switch setup.
Motor Housing and Blade Installation
Installing the Motor Housing
Align and secure the motor housing over the motor and ceiling bracket with screws.
Installing the Blades
Attach blades to blade arms with grommets and screws, then attach arms to motor.
Light Fixture Assembly and Installation
Assembling the Light Fixture
Install switch housings, connect wires, and secure the light fixture assembly.
Installing Bulbs and Glass
Install bulbs, secure glass globe, and thread pull chains through the finial cap.
Fan Operation and Features
Installing the Pull Chains
Feed pull chains through the housing and attach pendants to the fan and light chains.
Reversing the Fan Direction
Change fan rotation for updraft or downdraft airflow by sliding the reversing switch.
Troubleshooting and Warranty
Troubleshooting Fan Issues
Addresses common problems like fan not working, wobbling, or noisy operation.
Limited Lifetime Warranty
Details warranty coverage for motor and other parts, exclusions, and service procedures.
