Sony SA-W17 Service Manual

SERVICE MANUAL
• MHC-M500AV is composed of following models.
As for the service manual, it is issued for each component
model, then, please refer to them.
COMPONENT MODEL NAME
COMPACT DISC DECK RECEIVER SYSTEM
FRONT SPEAKER
SPEAKER
SPEAKER
SYSTEM
PACK
SUPER WOOFER
SPECIFICATIONS
General
Power requirements: 120 V AC, 60Hz
Power consumption: 210 watts
Dimensions (w/h/d): Approx. 280 x 373 x 468 mm
Mass: Approx. 11.0 kg
Supplied accessories: AM loop antenna (1)
Remote commander (1)
Batteries (2)
FM lead antenna (1)
Speaker cords (2)
Center speaker pads (4)
Monaural connecting cord (1)
Design and specifications are subject to change without notice.
9-929-284-11
MHC-M500AV
CENTER SPEAKER
SS-RC175D
REAR SPEAKER
Sony Corporation
Audio Entertainment Group
HCD-M500AV
SS-M500AV
SS-CT175D
SS-RS175D
SA-W17
PARTS LIST
Part No. Description
ACCESSORIES & PACKING MATERIALS
*******************************
1-476-193-11 COMMANDER, STANDARD (RM-SX5)
1-501-374-11 ANTENNA, LOOP
1-501-659-41 ANTENNA (FM)
1-769-433-11 CORD, SPEAKER (10m) (SS-RS175D)
1-751-598-11 MONAURAL CONNECTING CORD ( 2m) (SA-W17)
4-227-898-11 MANUAL, INSTRUCTION (ENGLISH)
4-210-254-01 CUSHION (FOOT)
4-981-643-21 BATTERY COVER (FOR RM-SX5)
COMPACT COMPONENT SYSTEM
US Model
Remark
2000E001613-1D
Printed in Japan ©2000.5
Published by HA Quality Assurance Dept.
