TA785GE/TA785GE 128M BIOS Manual
BIOS Setup .................................................................................................1
1 Main Menu...............................................................................................3
2 Advanced Menu.......................................................................................7
3 PCIPnP Menu........................................................................................17
4 Boot Menu..............................................................................................20
5 Chipset Menu.........................................................................................22
6 T-S eries Menu........................................................................................28
7 Exit Menu...............................................................................................41
i
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biostar TA785GE - BIOS
Summary of Contents for Biostar TA785GE - BIOS
- Page 1 TA785GE/TA785GE 128M BIOS Manual BIOS Setup ....................1 1 Main Menu....................3 2 Advanced Menu..................7 3 PCIPnP Menu..................17 4 Boot Menu....................20 5 Chipset Menu..................22 6 T-S eries Menu..................28 7 Exit Menu....................41...
-
Page 2: Bios Setup
TA785GE/TA785GE 128M BIOS Manual BIOS Setup Introduction T he purpose of this manual is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. T he power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off. -
Page 3: Pci Bus Support
TA785GE/TA785GE 128M BIOS Manual PCI Bus Support T his AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconn ect) local bus speci fication. DRAM S upport DDR2 SDRAM (Double Data Rate II Synchronous DRAM) is supported. Supported CP Us T his AMI BIOS supports the AMD CPU . -
Page 4: System Memory
TA785GE/TA785GE 128M BIOS Manual 1 Main Menu Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system inform ation. BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et T-Series Exit Syste m Overview... -
Page 5: Hard Drive Configuration
TA785GE/TA785GE 128M BIOS Manual Floppy A Select the type of floppy disk drive installed in your system. Options: 360K, 5.25 in / 1.2M, 5.25 in / 720K, 3.5 in / 1.44M, 3.5 in / 2.88M, 3.5 in / Disabled Hard Drive Configuration T he BIOS will automatically detect the presence of ID E/SAT A devices. - Page 6 TA785GE/TA785GE 128M BIOS Manual Primary IDE Master/Slav e ; SATA 1/2/3/4/5/6 Dev ice BIOS SETUP UTILITY Main Primary IDE Master Select the type of device connected Device to the system. Type [Auto] LBA/Large Mode [Auto] Block (Multi-Sector Transfer)[Auto] PIO Mode [Auto] DMA Mode [Auto]...
-
Page 7: Hard Disk Write Protect
TA785GE/TA785GE 128M BIOS Manual 32Bit Data Transfer Enable or disable 32-bit data transfer. Options: Enabled (Default) / Disabled Hard Disk Write Protect Disable or enable device write protection. T his will be effective only if the device is accessed through BIOS. Options: Disabled (Default) / Enabled IDE Detect Time Out (Sec) -
Page 8: Advanced Menu
TA785GE/TA785GE 128M BIOS Manual 2 Advanced Menu T he Advanced Menu allows you to configu re the settings of CPU, Super I/O, Power Management, and other system devices. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. -
Page 9: Super Io Configuration
TA785GE/TA785GE 128M BIOS Manual Secure Virtual Machine Mode Virtualization T echnology can virtually separate your system resou rce into several parts, thus enhance the performance when running virtual machines or multi interf ace systems. Options: Enabled (Default) / Disabled Cool N Quiet T his item allows you to enable or disable the Cool &... - Page 10 TA785GE/TA785GE 128M BIOS Manual Serial Port1 Address Select an address and corresponding interrupt fo r the first and second seri al ports. Options: 3F8/IRQ4 (Default) / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Disabled Keyboard Pow erOn T his item allows you to control the keyboard power on function. Options: Disabled (Default) / Specific Key / Stroke Key / Any Key Specific Key Enter...
-
Page 11: Smart Fan Configuration
TA785GE/TA785GE 128M BIOS Manual Smart Fan Configuration BIOS SETU P U TILITY Advan ced Smart Fan Conf iguration When you choice [Auto] ,[3Pin] or [4Pin], CPU Smart Fan [Dis abled] please run the Smart Fan Cali bration calibration to define Control Mode the Fan parameters for Fan Ctrl OFF( C) -
Page 12: Hardware Health Configuration
TA785GE/TA785GE 128M BIOS Manual Fan Ctrl Start Value When CPU/System temperature arriv es to the set value, the CPU/System fan will work under Smart Fan Function mode. Options: 0~127 Fan Ctrl Sensitive Increasing the value will raise the speed of CPU/System fan. Options: 1~127 Hardware Health Configuration... -
Page 13: Power Configuration
TA785GE/TA785GE 128M BIOS Manual Power Configuration BIOS S ETUP UTILITY Advanced ACPI Settings Sele ct the ACPI stat e used for Suspe nd mode [ S1 (POS)] Syst em Suspend. ACPI Version Featu res [ ACPI v1.0] ACPI APIC support [ Enabled] AMI O EMB table [ Enabled]... - Page 14 TA785GE/TA785GE 128M BIOS Manual Headless mode T his is a server-speci f ic feature. A headless server is one that operates without a keyboard, monitor or mouse. To run in headless mode, both BIOS and operating system (e.g. Windows Server 2003) must support headless operation. Options: Disabled (Default) / Enabled RTC Resume...
-
Page 15: Usb Configuration
TA785GE/TA785GE 128M BIOS Manual USB Configuration T his item shows the USB controller and using USB device information. BIOS S ETUP UTILITY Advanced USB C onfiguration Enab les support for lega cy USB. AUTO Modul e Version - 2 .24.3-13.4 opti on disables lega cy support i f USB D evices Enable d:... -
Page 16: Audio Configuration
TA785GE/TA785GE 128M BIOS Manual USB Mass Storage Dev ice Configuration BIOS SETUP UTILITY Advanced USB Mass Storage Device Configuration Number of seconds POST waits for the USB Mass Storage Reset Delay [20 Sec] USB mass storage device after start Device # unit command. -
Page 17: Onboard Lan Configuration
TA785GE/TA785GE 128M BIOS Manual AMD 880 HD Audio T his item allows you to control the Northbridge HD Azalia (HDMI audio) fun ction. Options: Enable (Default) / Disabled HD Audio Azalia Device T his item allows you to control the onboard codec. Options: Enabled (Default) / Disabled / Audo Onboard LAN Configuration... -
Page 18: Pcipnp Menu
TA785GE/TA785GE 128M BIOS Manual 3 PCIPnP Menu T his section describes con figuring the PCI bus system. PCI, or Personal Computer Interconn ect, is a system which allows I/O devices to operate at speeds nearing the speed o f the CPU itself uses when communicating with its own special components. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. -
Page 19: Pci Latency Timer
TA785GE/TA785GE 128M BIOS Manual PCI Latency Timer T his item controls how long a PCI device can hold the PCI bus bef ore another takes over. T he longer the latency, the longer the PCI device can retain control of the bus before handing it over to another PCI device. -
Page 20: Reserved Memory Size
TA785GE/TA785GE 128M BIOS Manual IRQ3/4/5/7/9/10/11/14/15 T hese items will allow you to assign each system interrupt a type, depending on the type of device using the interrupt. T he option “Available” means the IRQ is going to assign automatically. Options: Available (Default) / Reserved DMA Channel 0/1/3/5/6/7 T hese items will allow you to assign each DMA channel a type, depending on the... -
Page 21: Boot Device Priority
TA785GE/TA785GE 128M BIOS Manual 4 Boot Menu T his menu allows you to setup the system boot options. BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et T-Series Exit Boot Settings Conf iguration Spec ifies the Boot Device Prio rity sequenc e. >... -
Page 22: Quick Boot
TA785GE/TA785GE 128M BIOS Manual CD/DV D Drives T he BIOS will attempt to arrange the CD/DVD drive boot sequence automatically. You can also change the booting sequence. The number of device items that appears on the screen depends on the number of devices installed in the system. Options: Pri. -
Page 23: Chipset Menu
TA785GE/TA785GE 128M BIOS Manual 5 Chipset Menu T his submenu allows you to configure the speci fic features of the chipset installed on your system. T his chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. BIOS S ETUP UTILITY Main Advanced... -
Page 24: Internal Graphics Configuration
TA785GE/TA785GE 128M BIOS Manual Internal Graphics Configuration BIOS S ETUP UTILITY Chips et Inter nal Graphics Configuratio n Options Inter nal Graphics Mode [ UMA] Disa ble UMA Frame Buffer Size [ Auto] GFX E ngine Clock O verride [ Disable] GFX Engine Clock [ 500] Surro und View... - Page 25 TA785GE/TA785GE 128M BIOS Manual PCI Express Configuration BIOS S ETUP UTILITY Chips et PCI E xpress Config uration > Por t #02 Feature s > Por t #07 Feature s > NB- SB Port Featu res S elect Screen S elect Item U pdate En ter G eneral Help...
-
Page 26: Primary Video Controller
TA785GE/TA785GE 128M BIOS Manual Link Width Options: Auto (Default) / x1 / x2 / x4 / x8 / x16 Slot Power Limit, W Options: 75 (Default) / 0-255 NB-SB Port Features BIOS S ETUP UTILITY Chips et NB-SB Link ASPM [ L1] Options NP NB -SB VC1 Traff ic Support [ Disabled]... -
Page 27: Southbridge Configuration
TA785GE/TA785GE 128M BIOS Manual SouthBridge Configuration BIOS S ETUP UTILITY Chips et South Bridge Chipse t Configurat ion Options SB710 CIMx Verison : 4.7.0 Disa bled Enab led OHCI HC(Bus 0 Dev 18 Fn o) [ Enabled] OHCI HC(Bus 0 Dev 18 Fn 1) [ Enabled] EHCI HC(Bus 0 Dev 18 Fn 2) [ Enabled]... -
Page 28: Power Saving Features
TA785GE/TA785GE 128M BIOS Manual SATA IDE Combined Mode T his option controls the SAT A/PAT A combined mode. Options: Enabled (Default) / Disabled Power Saving Features Disable / Enable power saving featu res in SB. Generally, this f eature should be disabled for desktop and enabl ed fo r mobile. -
Page 29: Overclock Navigator
OverClock Navigator OverClock .Navigator is designed for beginners in overclock field. Based on many test and experiments from Biostar Engineer Team, OverClock Navigator provid es 3 default overclo ck con figurations that are able to raise the system perfo rmance. - Page 30 TA785GE/TA785GE 128M BIOS Manual Auto OverClock S ystem BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et T-Series Exit T-Ser ies Settings Options WARNI NG: Pl ease Clear C MOS if syste m no display Norm al af ter overcloc king. Auto mate OverClo ck Manu al OverClock OverC lock Navigato r...
-
Page 31: Spread Spectrum
TA785GE/TA785GE 128M BIOS Manual Manual Overclock System (M.O.S.) BIOS S ETUP UTILITY Main Advanced PCIPnP Boot Chips et T-Series Exit T-Ser ies Settings Options WARNI NG: Pl ease Clear C MOS if syste m no display Norm al af ter overcloc king. Auto mate OverClo ck Manu al OverClock OverC lock Navigato r... -
Page 32: Over-Voltage Configuration
TA785GE/TA785GE 128M BIOS Manual Over-Voltage Configuration BIOS S ETUP UTILITY T-Series CPU T uning CPU Vcore Contro l. CPU V core [Auto] CPU N B Over Voltag e [Auto] Memor y Over-Voltag e [ 1.95V] Chips et Over-Volta ge [ 1.15V] HT Ov er-Voltage [ 1.20V] S elect Screen... -
Page 33: Processor Voltage
TA785GE/TA785GE 128M BIOS Manual CPU FID/VID Control (for AM2 CP U) BIOS S ETUP UTILITY T-Series CPU F ID/VID Contro l Options Proce ssor Multipli er [ Auto] Auto Proce ssor Voltage [ Auto] x4.0 800 MHz x4.5 900 MHz x5.0 1000 MHz Rese rved... - Page 34 TA785GE/TA785GE 128M BIOS Manual CPU FID/VID Control (for AM2+ CP U) BIOS S ETUP UTILITY T-Series CPU F ID/VID Contro l Tell s BIOS wheth er to use the setup op tions Custo m P-States [ Disabled] belo w this to Core FID [ x11.5 2300MH z] conf igure the...
-
Page 35: Hyper Transport Configuration
TA785GE/TA785GE 128M BIOS Manual NB VID T his function allows you to adjust the voltage of NB chip. Options: 0.0125V ~ 1.5500V NB FID T his item allows you to select the Frequency o f NB chip. Options: 800MHz ~ 7000MHz (Di ffered by CPU) Hyper Transport Configuration BIOS S ETUP UTILITY T-Series... -
Page 36: Dram Timing Configuration
TA785GE/TA785GE 128M BIOS Manual DRAM Timing Configuration BIOS S ETUP UTILITY T-Series DRAM Timing Config uration Mem ory CLK CAS Latency(Tcl) RAS /CAS Delay(Tr cd) Row Precharge Ti me(Trp) Min Active RAS(T ras) RAS /RAS Delay(Tr rd) Row Cycle (Trc) Com mand Rate(CR) Wri te Recover Ti me(Twr) S elect Screen... - Page 37 TA785GE/TA785GE 128M BIOS Manual Channel Interleaving T his item allows you to control the DDR2 dual-channel function. Options: XOR of Address bits [20:16, 6] (Default) / XOR of Address bits [20:16, 9] / Address bits 6 / Address bits 12 / Disabled Memory Clock Mode T his item allows you to control the Memory Clock.
-
Page 38: Ecc Configuration
TA785GE/TA785GE 128M BIOS Manual ECC Configuration BIOS SETU P U TILITY T-Series ECC Configurat ion Set the level of ECC protection. Note: The ECC Mode [Dis abled] Super ECC mode DRAM ECC Ena ble [Dis abled] dynamically sets the DRAM SCRUB R EDIRECT [Dis abled] DRAM scrub rate so 4-Bit ECC Mo de... - Page 39 TA785GE/TA785GE 128M BIOS Manual DRAM Timing Mode T his item allows you to choose to manually or automatically regul ate the DRAM T iming. Options: Auto (Default) / DCT0 / DCT 1 (with AM2+ CPU) / Both (with AM2+ CPU) CAS Latency (CL) Options: Auto (Default) / 4~12 CLK...
-
Page 40: Phase Control
TA785GE/TA785GE 128M BIOS Manual tWRRD Options: Auto (Default) / 2~10 CLK tWTR Options: Auto (Default) / 4~7 CLK tWRWR Options: Auto (Default) / 3~10 CLK tRDRD Options: Auto (Default) / 2~10 CLK tRFC0 / tRFC1 / tRFC2 / tRFC3 Options: Auto (Default) / 90ns / 110ns / 160ns / 300ns / 350ns G.P.U Phase Control BIOS S ETUP UTILITY... - Page 41 TA785GE/TA785GE 128M BIOS Manual Integrated Memory Test Integrat ed Memory T est allows users to test memory module compatibilities without additional device or sof tw are. Step 1: T his item is disabled on default; change it to “ Enable” to precede memory test. BIOS S ETUP UTILITY Main Advanced...
-
Page 42: Save Changes And Exit
TA785GE/TA785GE 128M BIOS Manual 7 Exit Menu T his menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset T-Series Exit Exit Options Exit system setup... -
Page 43: Cmos Backup Function
TA785GE/TA785GE 128M BIOS Manual CMOS Backup Function It allows users to save different CMOS settings into BIOS-ROM and reload any saved CMOS setting for customizing system configurations. Moreover, users are able to save an ideal overclock setting during overclock operation. T here are 10 sets o f record address es in total, and users are able to nam e the CMOS data acco rding to personal preference. - Page 44 TA785GE/TA785GE 128M BIOS Manual Change Supervisor Passw ord Setting the supervisor password will prohibit everyone except the supervisor from making changes using the CMOS Setup Utility. You will be prompted with to enter a password. User Acess Level T his item allows supervisor to set the user level. Options: Full Access (Default) / No Access / View Only / Limited Change User Password...
