Summarization of Contents
Special Tools
Oil Pressure Controller Tool
Tool for fitting and removing the oil pressure controller.
Slide Hammer Tool
Slide hammer for various removal tasks.
Timing Cover Removal Procedure
Initial Steps for Timing Cover Removal
Drain engine oil and remove the sump before timing cover removal.
Remove Engine Ancillaries
Remove fan, belts, water pump, and torsional absorber.
Timing Cover Sensor Removal
Remove crankshaft position sensor and its harness clamps.
Timing Cover Fastener Removal
Remove timing cover bolts and nuts, and specific 4-cylinder bolt.
Front Panel Removal
Front Panel Component Removal
Remove oil pressure controller, thermostat, camshaft, injection pump, and sensor target.
Front Panel Drive Components Removal
Remove lower intermediate pinion, oil pump, and balancer shafts.
Front Panel Fitting
Front Panel Preparation and Installation
Prepare surfaces, apply sealant, and fit bypass valve.
Front Panel Fastener Installation
Fit and tighten front panel bolts and studs, including specific 6-cylinder bolt.
Balancer Shaft Fitting
Balancer Shaft and Pinion Timing
Set timing for 4-cylinder balancer shafts and lower intermediate pinion.
Oil Pump Fitting
6-Cylinder Oil Pump Installation
Install the oil pump on a 6-cylinder engine.
Timing Pinions Fitting
Lower Intermediate Pinion Fitting
Fit the lower intermediate pinion on a 6-cylinder engine.
Camshaft Fitting
Camshaft and Upper Pinion Timing
Fit the camshaft and set timing for the upper intermediate pinion.
Crankshaft Sensor Target Fitting
Crankshaft Sensor Target Installation
Fit the target for the crankshaft sensor.
Timing Cover Fitting
Timing Cover Installation Steps
Install new seal, fit timing cover, and tighten fasteners.
Timing Cover Bolt Installation
Fit and tighten the timing cover bolt to the recommended torque.
Crankshaft Position Sensor Fitting
Fit crankshaft position sensor and harness clamp bolts.
Oil Pressure Controller Fitting (6-Cylinder)
Fit the oil pressure controller on a 6-cylinder engine.
Sump Fitting
Sump Installation
Fit the sump.
Crankshaft Bearing Seal Fitting
Front Bearing Seal Installation
Fit the front bearing seal.
Water Pump Fitting
Water Pump Installation
Fit the water pump.
Fan and Belt System Fitting
Fan Belt Tensioner and Fan Installation
Fit fan belt tensioner, roller, and fan support.
Engine Oil Top-up
Top up the engine oil after assembly.
Oil Pressure Controller Removal
6-Cylinder Oil Pressure Controller Removal
Undo and remove the pressure controller and its components.
4-Cylinder Oil Pressure Controller Removal Prep
Remove timing cover and prepare for controller removal using special tool.
Oil Pressure Controller Fitting
6-Cylinder Oil Pressure Controller Fitting Steps
Check the spring and fit the controller assembly with sealing washer.
4-Cylinder Oil Pressure Controller Fitting
Insert and push controller using special tool and hammer.
Engine Flywheel Housing
Engine Flywheel Housing Removal
Remove electric starting motor and flywheel housing, then disconnect from block.
Engine Flywheel Housing Fitting
Inspect surfaces, fit O-ring, and install the seal.
