NF520D3 Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biostar NF520D3
Summary of Contents for Biostar NF520D3
- Page 1 NF520D3 Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Introduction ........1 Before You Start ................1 Package Checklist ................1 Motherboard Features..............2 Rear Panel Connectors ..............3 Motherboard Layout................. 4 Chapter 2: Hardware Installation ......5 Installing Central Processing Unit (CPU)........5 FAN Headers.................. -
Page 3: Chapter 1: Introduction
NF520D3 CHAPTER 1: INTRODUCTION EFORE TART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the computer from power outlet before operation. -
Page 4: Motherboard Features
Motherboard Manual OTHERBOARD EATURES SPEC Socket AM3 AMD 64 Architecture enables 32 and 64 bit computing AMD Phenom II/ Athlon II processors Supports Hyper Transport 2.0 (Maximum Watt: 95W) Support HyperTransport 2.0 Supports up to 2.0 GT/s Bandwidth Chipset nVIDIA nForce 520 Low Pin Count Interface ITE 8718F Environment Control initiatives,... -
Page 5: Rear Panel Connectors
Board Size 200 mm (W) x 293 mm (L) Special RAID 0 / 1 / 0+1 / 5 support Feature Biostar reserves the right to add or remove support for OS Support Windows XP / Vista / 7 any OS with or without notice. ANEL... -
Page 6: Motherboard Layout
Motherboard Manual OTHERBOARD AYOUT CP U_FA N1 KBMS1 JATX P WR2 J_PRINT1 JUSB V 1 USB1 RJ45USB11 ATX P WR1 A UDIO 1 F_A UDIO1 nForce S ATA 3 S ATA 4 PEX1_1 S ATA 1 S ATA 2 PEX16_1 Codec BIOS PCI1... -
Page 7: Chapter 2: Hardware Installation
NF520D3 CHAPTER 2: HARDWARE INSTALLATION (CPU) NSTALLING ENTRAL ROCESSING Step 1: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle. Step 2: Look for the white triangle on socket, and the gold triangle on CPU should point forwards this white triangle. - Page 8 Motherboard Manual Step 3: Hold the CPU down firmly, and then close the lever toward direct B to complete the installation. Step 4: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the CPU_FAN1. This completes the installation.
-
Page 9: Fan Headers
NF520D3 FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1. CPU_FAN1: CPU Fan Header Assignment Ground... -
Page 10: Installing System Memory
Motherboard Manual NSTALLING YSTEM EMORY A. Memory Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated. - Page 11 NF520D3 B. Memory Capacity DIMM Socket Total Memory DDR3 Module Location Size DDR3_A1 512MB/1GB/2GB/4GB DDR3_B1 512MB/1GB/2GB/4GB Max is 16GB. DDR3_A2 512MB/1GB/2GB/4GB DDR3_B2 512MB/1GB/2GB/4GB C. Dual Channel Memory installation Please refer to the following requirements to activate Dual Channel function: Install memory module of the same density in pairs, shown in the table. Dual Channel Status DDR3_A1 DDR3_B1 DDR3_A2 DDR3_B2 Enabled Enabled...
-
Page 12: Connectors And Slots
Motherboard Manual ONNECTORS AND LOTS FDD1: Floppy Disk Connector The motherboard provides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. IDE1: Hard Disk Connector The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 functionality. - Page 13 NF520D3 PEX16_1: PCI-Express x16 Slot PCI-Express 1.0a compliant. Maximum theoretical realized bandwidth of 4GB/s simultaneously per direction, for an aggregate of 8GB/s totally. PEX1_1: PCI-Express x1 Slot PCI-Express 1.0a compliant. Data transfer bandwidth up to 250MB/s per direction; 500MB/s in total. PCI-Express supports a raw bit-rate of 2.5Gb/s on the data pins.
- Page 14 Motherboard Manual ATXPWR1: ATX Power Source Connector ATXPWR1 allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V +3.3V -12V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V +12V +12V +3.3V Ground ATXPWR2: ATX Power Source Connector This connector provides +12V to CPU power circuit.
-
Page 15: Chapter 3: Headers & Jumpers Setup
NF520D3 CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened Pin closed Pin1-2 closed ETAIL... - Page 16 Motherboard Manual F_AUDIO1: Front Panel Audio Header This header allows user to connect the front audio output cable with the PC front panel. This header allows only HD audio front panel connector; AC’97 connector is not acceptable. Assignment Mic Left in Ground Mic Right in GPIO...
- Page 17 NF520D3 JUSBV1/JUSBV2: Power Source Headers for USB Ports Pin 1-2 Close: JUSBV1: +5V for USB ports at USB1/RJ45USB1. JUSBV2: +5V for USB ports at front panel (F_USB1/F_USB2). Pin 2-3 Close: JUSBV1: +5V STB for USB ports at USB1/ RJ45USB1. JUSBV2: +5V STB for USB ports at front panel (F_USB1/F_USB2). JUSB V1 Pin 1-2 close Pin 2-3 close...
- Page 18 Motherboard Manual F_PRINT1: Printer Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK Data 2 Ground -Scltin Busy Data 3 Ground Ground Data 4...
-
Page 19: Chapter 4: Nvidia Raid Functions
NF520D3 CHAPTER 4: NVIDIA RAID FUNCTIONS PERATING YSTEM Supports Windows XP, Windows Vista, and Windows 7. RRAYS NVRAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications. - Page 20 Motherboard Manual RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array.
- Page 21 NF520D3 RAID 0+1: RAID 0 drives can be mirrored using RAID 1 techniques. Resulting in a RAID 0+1 solution for improved performance plus resiliency. Features and Benefits Drives: Minimum 4, and maximum is 6 or 8, depending on the platform. ...
- Page 22 Motherboard Manual RAID 5: RAID 5 stripes both data and parity information across three or more drives. It writes data and parity blocks across all the drives in the array. Fault tolerance is maintained by ensuring that the parity information for any given block of data is placed on a different drive from those used to store the data itself.
-
Page 23: Chapter 5: Useful Help
NF520D3 CHAPTER 5: USEFUL HELP RIVER NSTALLATION After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD The setup guide will auto detect your motherboard and operating system. -
Page 24: Software
Motherboard Manual OFTWARE Installing Software 1. Insert the Setup CD to the optical drive. The drivers installation program would appear if the Autorun function has been enabled. 2. Select Software Installation, and then click on the respective software title. 3. Follow the on-screen instructions to complete the installation. BIOScreen Utility This utility allows you to personalize your boot logo easily. -
Page 25: Award Bios Beep Code
NF520D3 AMI BIOS B Boot Block Beep Codes Number of Beeps Description No media present. (Insert diskette in floppy drive A:) “AMIBOOT.ROM” file not found in root directory of diskette in Insert next diskette if multiple diskettes are used for recovery Flash Programming successful File read error No Flash EPROM detected... -
Page 26: Extra Information
Motherboard Manual XTRA NFORMATION CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again. -
Page 27: Troubleshooting
NF520D3 ROUBLESHOOTING Probable Solution There is no power in the system. Make sure power cable is Power LED does not shine; the securely plugged in. fan of the power supply does not Replace cable. work Contact technical support. Indicator light on keyboard does not shine. -
Page 28: Appendix: Spec In Other Languages
Motherboard Manual APPENDIX: SPEC IN OTHER LANGUAGES ERMAN Spezifikationen Sockel AM3 Die AMD 64-Architektur unterstützt eine 32-Bit- und AMD Phenom II/ Athlon II Prozessoren 64-Bit-Datenverarbeitung (Maximales Watt: 95W) Unterstützt Hyper Transport 2.0 Unterstützt HyperTransport 2.0 mit einer Bandbreite von bis zu 2.0 GT/s Chipsatz nVIDIA nForce 520 ITE 8718F... - Page 29 Audioanschluss Platinengröße. 200 mm (B) X 293 mm (L) Sonderfunktio Unterstützt RAID 0 / 1 / 0+1 / 5 Biostar behält sich das Recht vor , ohne Ankündigung OS-Unterstütz Windows XP / Vista / 7 die Unterstützung für ein Betriebssystem...
-
Page 30: French
Motherboard Manual RENCH SPEC Socket AM3 L'architecture AMD 64 permet le calcul 32 et 64 bits Processeurs AMD Phenom II/ Athlon II Prend en charge Hyper Transport 2.0 (Watt maximum : 95W) Prend en charge Hyper Transport 2.0 Bus frontal jusqu'à... - Page 31 Fonctionnali tés Prise en charge RAID 0 / 1 / 0+1 / 5 spéciales Biostar se réserve le droit d'ajouter ou de supprimer le Support SE Windows XP / Vista / 7 support de SE avec ou sans préavis.
-
Page 32: Italian
Motherboard Manual TALIAN SPECIFICA Socket AM3 L’architettura AMD 64 abilita la co mputazione 32 Processori AMD Phenom II/ Athlon II e 64 bit (Watt massimo: 95W) Supporto di Hyper Transport 2.0 Supporto di HyperTransport 2.0 fino a 2.0 GT/s di larghezza di banda Chipset nVIDIA nForce 520 ITE 8718F... - Page 33 (altezza) Caratterist iche Supporto RAID 0 / 1 / 0+1 / 5 speciali Biostar si riserva il diritto di aggiungere o Sistemi operativi Windows XP / Vista / 7 rimuovere il supporto di qualsiasi sistema supportati operativo senza preavviso.
-
Page 34: Spanish
Motherboard Manual PANISH Especificación Conector AM3 La arquitectura AMD 64 permite el procesado de 32 y Procesadores AMD Phenom II/ Athlon II 64 bits (Vatio máximo: 95W) Soporta las tecnologías Hyper Transport 2.0 Admite HyperTransport 2.0 con un ancho de banda de hasta 2.0 GT/s Conjunto de nVIDIA nForce 520 chips... - Page 35 Funciones Admite RAID 0 / 1 / 0+1 / 5 especiales Soporte de Biostar se reserva el derecho de añadir o retirar el sistema Windows XP / Vista / 7 soporte de cualquier SO con o sin aviso previo. operativo...
-
Page 36: Portuguese
Motherboard Manual ORTUGUESE ESPECIFICAÇÕES Socket AM3 A arquitectura AMD 64 permite uma computação de Processadores AMD Phenom II/ Athlon II 32 e 64 bits (Watt máximo: 95W) Suporta as tecnologias Hyper Transport 2.0 Suporta a tecnologia HyperTransport 2.0 com uma largura de banda até 2.0 GT/s Chipset nVIDIA nForce 520 Interface LPC (Low Pin Count). - Page 37 200 mm (L) X 293 mm (A) da placa Característi Suporta as funções RAID 0 / 1 / 0+1 / 5 especiais A Biostar reserva-se o direito de adicionar ou Sistemas operativos Windows XP / Vista / 7 remover suporte para qualquer sistema operativo suportados com ou sem aviso prévio.
-
Page 38: Polish
Motherboard Manual OLISH SPEC Socket AM3 Architektura AMD 64 umożliwia przetwarzanie 32 i 64 Procesor AMD Phenom II/ Athlon II Procesory bitowe (Maksymalny Watt: 95W) Obsługa Hyper Transport 2.0 Obsługa HyperTransport 2.0 o szerokości pasma do 2.0 GT/s Chipset nVIDIA nForce 520 Gniazda DDR3 DIMM x 4 Moduł... - Page 39 200 mm (S) X 293 mm (W) płyty Funkcje Obsługa RAID 0 / 1 / 0+1 / 5 specjalne Obsluga Biostar zastrzega sobie prawo dodawania lub systemu Windows XP / Vista / 7 odwoływania obsługi dowolnego systemu operacyjnego operacyjne bez powiadomienia.
-
Page 40: Russian
Motherboard Manual USSIAN СПЕЦ Гнездо AM3 Архитектура AMD 64 разрешать обработка данных (центральн Процессоры AMD Phenom II/ Athlon II на 32 и 64 бит ый (Максимальный ватт: 95W) Поддержка Hyper Transport 2.0 процессор) Поддержка HyperTransport 2.0 с пропускной способностью до 2.0 GT/s Набор... - Page 41 панели Специальн ые технически Поддержка RAID 0 / 1 / 0+1 / 5 е характерис тики Biostar сохраняет за собой право добавлять или Поддержка Windows XP / Vista / 7 удалять средства обеспечения для OS с или без предварительного уведомления.
-
Page 42: Arabic
Motherboard Manual RABIC اﻟﻤﻮاﺻﻔﺎت ﻡﻘﺒﺲAM3 ﺗﻤﻜﻦ ﺗﻘﻨﻴﺔAMD 64 ﺏﺖ و إﺝﺮاء اﻟﻌﻤﻠﻴﺎت اﻟﺤﺎﺳﻮﺏﻴﺔ ﺏﺴﺮﻋﺔ اﻟﻤﻌﺎﻟﺠﺔ وﺣﺪة ﻡﻌﺎﻟﺠﺎتAMD Phenom II/ Athlon II اﻟﻤﺮآﺰﻳﺔ ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔHyper Transport و ()و59 :ﻗﺼ ﻮى واط HyperTransport ﻴﺔ ﺗﻘﻨ ﺗﺪﻋﻢ إﻟﻰ ﻳﺼﻞ ﺏﺘﺮدد اﻟﺠﺎﻥﺒﻲ اﻷﻡﺎﻡﻲ اﻟﻨﺎﻗﻞ GT/s nVIDIA nForce 520 اﻟﺸﺮاﺋﺢ... - Page 43 ﻡﻨﺎﻓﺬ ﻋﺪد ﻡﻘﺒﺲ ﺻﻮت RAID 0 / 1 / 0+1 / 5 ﺥﺎﺻﺔ ﻡﺰاﻳﺎ ﺗﻘﻨﻴﺔ ﺗﺪﻋﻢ ارﺗﻔﺎع ﻡﻢ ﻋﺮض ﻡﻢ اﻟﻠﻮﺣﺔ ﺣﺠﻢ ﺗﺤﺘﻔﻆBiostar ون ﺏﺪ أو ﺏﺈﺥﻄﺎر ﺗﺸﻐﻴﻞ ﻥﻈﺎم ﻷي اﻟﺪﻋﻢ إزاﻟﺔ أو إﺿﺎﻓﺔ ﻓﻲ ﺏﺤﻘﻬﺎ Windows XP / Vista / 7 اﻟﺘﺸﻐﻴﻞ...
-
Page 44: Japanese
Motherboard Manual APANESE 仕様 Socket AM3 AMD 64アーキテクチャでは、32ビットと64ビット計算が可 AMD Phenom II/ Athlon II プロセッサ 能です (最高のワット: 95W) ハイパートランスポート2.0サポートします 2.0 GT/sのバンド幅までハイパートランスポ ート2.0をサポートします チップセット nVIDIA nForce 520 DDR3 DIMMスロット x 4 デュアル チャンネルモードDDR3メモリモジュール 最大メモリ容量16GB DDR3 800 / 1066 / 1333 をサポート メインメモリ 各DIMMは... - Page 45 各コネクタは2つのフロントパネルUSBポートをサポートし USBコネクタ ます 電源コネクタ(24ピン) 電源コネクタ(4ピン) PS/2キーボード PS/2マウス シリアルポート 背面パネル LANポート USBポート オーディオジャック ボードサイズ 200 mm (幅) X 293 mm (高さ) RAID 0 / 1 / 0+1 / 5 のサポート 特殊機能 Biostarは事前のサポートなしにOSサポートを追加または削 OSサポート Windows XP / Vista / 7 除する権利を留保します。 2009/12/07...
