CHAPTER 2: HARDWARE INSTALLATION
2.1
I
NSTALLING
Step 1: Pull the lever toward direction A from the socket and then raise the
lever up to a 90-degree angle.
Step 2: Look for the white triangle on socket, and the gold triangle on
CPU should point towards this white triangle. The CPU will fit only
in the correct orientation.
C
P
ENTRAL
ROCESSING
A740G M2L+/A780LB
U
(CPU)
NIT
5
