Motherboard Features - Biostar A740G M2L PLUS - SETUP MANUAL 2 Setup Manual

Motherboard Manual
1.3 M
OTHERBOARD
Socket AM2+
AMD Sempron / Athlon / Athlon II / Phenom
CPU
/ Phenom II processors
(Maximum Watt: 95W)
Support HyperTransport 2.0
FSB
Supports up to 2 GT/s Bandwidth
AMD 740G (A740G M2L+)
Chipset AMD 780L (A780LB)
AMD SB710
ITE 8718F
Super I/O Provides the most commonly used legacy
Super I/O functionality
DDR2 DIMM Slots x 2
Max Memory Capacity 8GB
Main
Memory
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Graphics Integrated in AMD 740G Chipset
IDE Integrated IDE Controller
SATA II Integrated Serial ATA Controller
LAN Realtek RTL 8102EL
Sound ALC662
PCI Express X16 slot
Slots
PCI slot
On Board Floppy Connector
Connectors
IDE Connector
SATA Connector
Front Panel Connector
Front Audio Connector
2
F
EATURES
SPEC
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 2.0
Low Pin Count Interface
Environment Control initiatives
H/W Monitor
ITE's "Smart Guardian" function
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+/AM3 CPU)
Registered DIMM and ECC DIMM is not supported
Max Shared Video Memory is 512MB
Avivo support
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
Data transfer rates up to 3 Gb/s
SATA Version 2.0 specification compliant
10 / 100 Mb/s auto negotiation
5.1 channels audio out
High Definition Audio
x1 Supports PCI-E X16 expansion cards
x2 Supports PCI expansion cards
x1 Each connector supports 2 Floppy drives
x1 Each connector supports 2 IDE device
x4 Each connector supports 1 SATA devices
x1 Supports front panel facilities
x1 Supports front panel audio function
