System 3000
RF operating top unit
RF operating top unit, 1-gang
Order no.: 5104 .., 5105 .., 5106 ..
RF operating top unit, 2-gang
Order no.: 5107 .., 5108 ..
Operating instructions
1
Safety instructions
Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the device or load. In
so doing, take all the circuit breakers into account, which support dangerous voltages to the
device and or load.
The radio communication takes place via a non-exclusively available transmission path, and is
therefore not suitable for safety-related applications, such as emergency stop and emergency
call.
These instructions are an integral part of the product, and must remain with the end customer.
32403802
10867449
10.11.2021
1 / 12
Advertisement
Table of Contents
Related Manuals for Gira 5107 Series
Summary of Contents for Gira 5107 Series
- Page 1 System 3000 RF operating top unit RF operating top unit, 1-gang Order no.: 5104 .., 5105 .., 5106 .. RF operating top unit, 2-gang Order no.: 5107 .., 5108 .. Operating instructions Safety instructions Electrical devices may only be mounted and connected by electrically skilled persons. Serious injuries, fire or property damage possible.
-
Page 2: Device Components
System 3000 RF operating top unit Device components Front view 1-channel (Figure 1) and 2-channel (Figure 2) Figure 1: Device components 1-channel Figure 2: Device components 2-channel Rockers Status LED Cover frame System 3000 insert 32403802 10867449 10.11.2021 2 / 12... - Page 3 The device can be updated. Firmware can be easily updated with the Gira ETS Service App (additional software). The device is KNX Data Secure capable. KNX Data Secure offers protection against manipula- tion in building automation and can be configured in the ETS project.
-
Page 4: Operation Concept
System 3000 RF operating top unit - "Room temperature controller insert with sensor connection" - "Auxiliary insert 3-wire" For accurate temperature measurement, make sure that the connected loads do not ex- ceed 40 W for the electronic switch insert. To ensure good transmission quality, keep a sufficient distance from any possible sources of interference, e.g. - Page 5 System 3000 RF operating top unit 4.2 Examples for operating various standard applications ￭ Switch: Short press on button. ￭ Dim: Long press on the button. The dimming process ends when the button is released. ￭ Move Venetian blind: Long press on button. ￭...
-
Page 6: Error Message
System 3000 RF operating top unit Insert-cover alignment The device combination of insert and cover carries out an automatic insert-cover alignment as soon as a cover is placed on an insert and the mains voltage is switched on. Case 1: Insert and cover are brand new After the insert-cover alignment, the device combination is functional in a standard configura- tion. -
Page 7: Delivery State
System 3000 RF operating top unit Delivery state The device combination of insert and cover functions in the delivery state after successful in- sert-cover alignment. The cover is for local use in a standard configuration. The device combination does not transmit RF telegrams. The ETS can reset the device to the delivery state with the "Unload device"... - Page 8 System 3000 RF operating top unit Information for electrically skilled persons 7.1 Fitting and electrical connection DANGER! Mortal danger of electric shock. Disconnect the device. Cover up live parts. Mounting and connecting the device In secure operation (preconditions): – Secure commissioning is activated in the ETS. –...
- Page 9 System 3000 RF operating top unit 7.2 Commissioning Programming the physical address and application program, 1-channel (Figure 5) and 2- channel (Figure 6) Project design and commissioning with ETS from version5.7.5and above. The RF operating top unit works with the RF/TP media coupler (order no. 5110 00) from index I01.
- Page 10 System 3000 RF operating top unit ￭ Programming the application program. The status LED is switched off while the application program is programmed. As soon as the programming is successfully completed, the status LED carries out its parameterised function. For "Dimming": The load must be connected before ETS commissioning. Without a con- nected load, the ETS aborts the programming process of the application program.
- Page 11 System 3000 RF operating top unit 7.2.1 Safe-state mode and master reset Safe-state mode The safe state mode stops the execution of the loaded application program. If the device does not work properly - for instance as a result of errors in the project design or during commissioning - the execution of the loaded application program can be halted by activ- ating the safe-state mode.
-
Page 12: Technical Data
Receiver category Ambient conditions Ambient temperature -5 ... +45 °C Storage/transport temperature -25 ... +70 °C Relative humidity max. 93 % (no condensation) Gira Giersiepen GmbH & Co. KG Elektro-Installations- Systeme Industriegebiet Mermbach Dahlienstraße 42477 Radevormwald Postfach 12 20 42461 Radevormwald...
