- Page 1 S10/15 Semi-electric Operating Instructions Pallet Stacker Tel: +86 573 8622 9999 Fax: +86 573 8622 2900 info@eoslift.com 400-626-9090 Hotline:...
- Page 2 S10/15 Series Semi-electric Pallet Stackers Esteemed users: For proper and safe operation of the products, before using the products, be sure to read the operating instructions carefully and retain them properly for future reference. The operator needs to have proficient operation skills.
-
Page 3: Table Of Contents
S10/15 Series Semi-electric Pallet Stackers Table of contents Ⅰ．Technical parameters Ⅱ. Safe operating rules Ⅲ．Maintenance Ⅳ．Batteries Ⅴ．Control panel Ⅵ．Transport, loading, test run and storage Ⅶ．Troubleshooting Ⅷ．Electrical circuit diagram Ⅸ．Parts list... -
Page 4: Ⅰ．technical Parameters
S10/15 Series Semi-electric Pallet Stackers Technical parameters Safe operating rules 1. Requirements for operator Model The stacker must be operated by persons trained in operation.The operator shall be able to carry out operation demonstration of moving and controlling goods for users, and he or she is responsible for the... - Page 5 S10/15 Series Semi-electric Pallet Stackers Safe operating rules Maintenance 7. Stable operation No modifications or alterations to the parts of the stacker, especially the safety device shall be made without permission. All original spare parts have been checked by the quality inspection departments.
-
Page 6: Ⅴ．control Panel
S10/15 Series Semi-electric Pallet Stackers Control panel Battery ① 1. Battery power system Emergency stop switch When you press down this switch, it will switch off the power of the stacker, and then if you turn it 12V, 120Ah lead-acid storage batteries are used in this series of stackers. -
Page 7: Ⅵ．transport, Loading, Test Run And Storage
S10/15 Series Semi-electric Pallet Stackers Troubleshooting Transport, loading, test run and storage This chapter enables the user to identify and rectifies basic faults and the effects of incorrect operation. When trying to locate a fault, proceed in the order shown in the table below. If, after carrying out the following remedial action listed in “actions”, the stacker cannot be restored to operation, contact the... -
Page 8: Ⅷ．electrical Circuit Diagram
S10/15 Series Semi-electric Pallet Stackers Troubleshooting Electrical circuit diagram Replace the damaged Oil leakage Seals damaged seals with new seals Emergency stop switch Key switch FU2 20A Impurities in the oil cause Change hydraulic oil the valve to be unable to... - Page 9 S10/15 Series Semi-electric Pallet Stackers Parts list· Guide wheel,with brake Description Qty. Parts number WC02000237 Universal wheel bracket,with brake,black WC02000234 Big wheel shaft sleeve 1 WC02000243 Sprocket WC02000244 Backing ring WC02000245 Wheel shaft cover WC02000240 Compressions spring WC02000238 Brake lining, galvanized...
- Page 10 S10/15 Series Semi-electric Pallet Stackers Parts list· Guide wheel Parts list· Handle assemblies Description Qty. Description Qty. Parts number Parts number WC02000246 Guide wheel bracket,black WC02000821 Handle holder, welded GB276,Deep groove ball bearing 6204, WC02000818 Pivot Ⅱ WC02000022 two-side shielded...
- Page 11 S10/15 Series Semi-electric Pallet Stackers Parts list· Motor box Description Qty. Parts number WC02000815 Electrical box welded WC02000269 Hydraulic pump station WC04000022 Fuse connecting holder WC04000020 Emergency stop switch ZJK250A WE03000006 Pan head screw with cross recess WE03000004 Hexagon socket head cap screw...
- Page 12 S10/15 Series Semi-electric Pallet Stackers Parts list· Cylinder assembly Description Qty. Parts number WC01000015 Cylinder assembly (1.6m), black WC01000019 Cylinder assembly (2.0m), black WC01000016 Cylinder assembly (2.5m), black WC01000017 Cylinder assembly (3.0m), black WC01000018 Cylinder assembly (3.5m), black WC02000233 Cylinder weldment (1.6m), black WC02000333 Cylinder weldment (2.0m), black...
- Page 13 S10/15 Series Semi-electric Pallet Stackers Parts list· Top beam assembly Parts list· Steering chain Description Qty. Description Qty. Parts number Parts number WC02000256 Top shaft, galvanized WC02000219 Chain WC02000317 Sprocket (leaf chain) WC02000263 Threaded rod (right) GB276,Deep groove ball bearing 6204,...
- Page 14 S10/15 Series Semi-electric Pallet Stackers Parts list· Leaf chain Parts list· Single frame Description Qty. Description Qty. Parts number Parts number WC02000314 Leaf chain, 68 links (1.6m) WC02000899 External frame,5012(1.5t) WC02000332 Leaf chain, 88 links (2.0m) WE03000014 Hexagon socket head cap screw WC02000321 Leaf chain, 90 links (2.5m)
- Page 15 S10/15 Series Semi-electric Pallet Stackers Parts list· Single frame Parts list· Movable fork assy Description Qty. Parts number WC02000319 Fork guide plate bracket(1.5t), black Gb77, Hexagon socket set screw with flat point WE03000019 M12×20,galvanized WE07000007 GB893.1,Circlip for hole 52,blackening GB276,Deep groove ball bearing 6205,...
- Page 16 S10/15 Series Semi-electric Pallet Stackers Parts list· External frame Description Qty. Parts number WC02000830 External frame,5012(1.5t,2.5m) WC02000876 External frame,5012(1.5t,3.0m) WC02000904 External frame,5012(1.5t,3.5m) WC02000293 Upper guide wheel WC02000294 Upper guide bracket WE05000005 Spring lock washer WC02000227 Iron-core PU wheel WC02000022 Deep groove ball bearing...
- Page 17 S10/15 Series Semi-electric Pallet Stackers Parts list· Movable fork assy Parts list· Internal frame Description Qty. Description Qty. Parts number Parts number WC02000323 Fork guide plate bracket, black(1.5t/2.0t) WC02000812 Internal frame,5012（2.5m) Gb77, Hexagon socket set screw with flat point WE03000019 WC02000874 Internal frame,5012（3.0m)
- Page 18 S10/15 Series Semi-electric Pallet Stackers Parts list· Internal frame Parts list· Oil pipe Description Qty. Parts number WC02000266 High-pressure pipe WC02000270 Oil return pipe (1.6m) WC02000331 Oil return pipe (2.0m) WC02000296 Oil return pipe (2.5m) WC02000301 Oil return pipe (3.0m) WC02000311 Oil return pipe (3.5m)
- Page 19 S10/15 Series Semi-electric Pallet Stackers Parts list· Fixed fork assy Parts list· Fixed fork assy Description Qty. Description Qty. Parts number Parts number WC02000231 Iron wheel WC02000231 Iron wheel WE07000010 Circlip for shaft WE07000010 Circlip for shaft WE07000007 Circlip for hole...
