- Page 1 E20V Scale Operating Instructions Pallet Truck Tel: +86 573 8622 9999 Fax: +86 573 8622 2900 info@eoslift.com 400-626-9090 Hotline:...
- Page 2 E20V Series Scale Pallet Trucks Esteemed users: For proper and safe operation of the products, before using the products, be sure to read the operating instructions carefully and retain them properly for future reference. The operator needs to have proficient operation skills.
-
Page 3: Table Of Contents
E20V Series Scale Pallet Trucks Table of contents Ⅰ．Technical parameters Ⅱ. Safety rules Ⅲ．Installation of handles Ⅳ．Adjusting the finger grip handle Ⅴ．Operating instruction Ⅵ．Appendix Ⅶ．Troubleshooting Ⅷ．Transport, loading, test run and storage Ⅸ．Parts list... -
Page 4: Ⅰ．technical Parameters
E20V Series Scale Pallet Trucks Technical parameters Safety rules The pallet truck is only applicable to indoor use and the application environment must meet the following Model E20V conditions: Rated capacity 2000 Free from rainwater or corrosion of harmful gases;... -
Page 5: Ⅲ．installation Of Handles
E20V Series Scale Pallet Trucks Installation of handles Adjusting the finger grip handle On the handle of this pallet truck, you can find finger grip control handle(1-1) which can be regulated in three positions : Upper Middle Lower 1.Make sure the chain on the handle 2.Push the handle shaft through the... - Page 6 E20V Series Scale Pallet Trucks Operating Instructions 1.Using the Scale Pallet Truck 2.Normal weighing mode The truck shall be correctly used to ensure accurate weighing. The following conditions are prohibited in 2.1Operating panel the application. TARE Figure 2-1 Operating panel in Normal Weighing Mode...
- Page 7 E20V Series Scale Pallet Trucks Operating Instructions 2.2 Display 3.Parameter setting mode If any cargo is placed on the frame, its weight will be displayed after 1 second; once “ dynamic cursor” 3.1Operating panel disappears, value as displayed on the screen will be the weight of the cargo.
- Page 8 E20V Series Scale Pallet Trucks Operating Instructions 3.2Default unit setting 4.Calibration Default unit of the system is kilogram (KG). The first option in parameter setting mode is default unit setting; when “ UNIT” is displayed on the screen, press “ T” key to confirm entry into unit setting mode; press “U” key for cancellation to proceed with next setting.
- Page 9 E20V Series Scale Pallet Trucks Operating Instructions 5.Battery replacement 7-2. Press “ P " key to adjust the input 7-1. Press “0”key to input values. digit bit. Diagram for disassembly of battery cover Battery holder Battery cover The instrument uses 2 CR2447 button cells.
- Page 10 E20V Series Scale Pallet Trucks Troubleshooting Appendix Description of items displayed on the screen 1.System halt This product has received strict testing before delivery and no system halt will occur under normal conditions. Please remove the battery, and refit it again to recover its normal operation...
-
Page 11: Ⅷ．transport, Loading, Test Run And Storage
E20V Series Scale Pallet Trucks Troubleshooting Transport, loading, test run and storage If the truck has to be transported for a long distance, it should be packed in the wooden pallet in order Piston rod or the frame is Replace the related parts of to avoid collision during transportation. - Page 12 E20V Series Scale Pallet Trucks Parts list · Frame(85) Description Qty. Description Qty. Parts number Parts number WC02000192 Frame (560 × 1150), 5012 WC02000020 Gb308, Steel ball S18 WC02000207 Frame (685 × 1220), 5012 WE07000003 GB894.1,Circlip for shaft 52,blackening WC02000204...
- Page 13 E20V Series Scale Pallet Trucks Parts list · Frame(85) Parts list · Frame(75) Description Qty. Parts number WC02000851 Frame, 5012 GB70.1, Hexagon socket head cap screw WE03000001 M6 × 16, galvanized GB93,Normal type spring lock washer 6, WE05000001 galvanized WC02000204...
- Page 14 E20V Series Scale Pallet Trucks Parts list · Frame(75) Description Qty. Parts number WC02000010 Push rod connecting shaft, galvanized WC02000850 Right push rod, 5012 WC02000849 Left push rod, 5012 WC02000019 JB7940.4, Push-fit type grease nipple 6 GB879.1,Spring type straight pin WE06000002 5×26,blackening...
- Page 15 E20V Series Scale Pallet Trucks Parts list· Cylinder Description Qty. Parts number WC02000170 Valve body welded(75), galvanized WC02000157 Valve body welded(85), galvanized WC02000060 GB982, Combination sealing gasket 10 WC02000036 Screw WC02000061 Seal ring UHS35 WC02000059 GB3452.1,O-ringφ34.5×3.55 WC02000058 Dustproof ring DH35...
- Page 16 E20V Series Scale Pallet Trucks Parts list · Integrated valve Description Qty. Parts number WC02000051 Push pin sleeve WC02000065 GB3452.1,O-ringφ15.2×2.4 WC02000067 GB3452.1,O-ringφ8×1.8 WC02000053 Return valve sleeve WC02000066 GB3452.1,O-ringφ9.5×1.8 WC02000050 Stem WC02000052 Unloading spring WC02000054 O-ring retainer Ⅱ WC02000069 GB308,Steel ball S7...
- Page 17 E20V Series Scale Pallet Trucks Parts list· Handle Description Qty. Parts number WJ10800014 Handle welded WJ10800015 Clamping roller WJ10800016 Roller pin WJ10800011 Finger grip handle WJ10800006 Spring type pin (5) WJ10800003 Spring type pin (6) WJ10800004 Spring type pin (7)
