Actions On Storage Nodes - ACRONIS BACKUP AND RECOVERY 10 ADVANCED SERVER VIRTUAL EDITION - UPDATE 3 User Manual

The toolbar lets you perform operations (p. 337) with the selected storage node. The list of
storage nodes displays online and offline storage nodes added to the management server. It also
informs you about the total number of backups and archives on the storage node.

Information panel
Contains the detailed information about the selected storage node and lets you manage the
compacting task. The panel is collapsed by default. To expand the panel, click the
The content of the pane is also duplicated in the Storage node details (p. 339) window.
Way of working with storage nodes (typical workflow)
1. Install the Acronis Backup & Recovery 10 Storage Node.
2. Create a user account for each user whom you want to allow to access the storage node.
Note: You can skip this step if both the storage node and the users' machines are in the same Active
Directory domain.
For information about user rights on a storage node and in its managed vaults, see User rights on
a storage node (p. 84).
3. Add (p. 338) the storage node to the Acronis Backup & Recovery 10 Management Server.
4. Create a managed vault (p. 139): specify the path to the vault, select the storage node that will
manage the vault and select the management operations such as deduplication or encryption.
5. Create a backup policy (p. 367) or a backup plan that will use the managed vault.
7.1.5.1

Actions on storage nodes

All the operations described here, are performed by clicking the corresponding buttons on the
toolbar. The operations can be also accessed from the Storage nodes bar (on the Actions and tools
pane) and from the Storage nodes item of the main menu.
To perform an operation with a storage node added to the management server, first select the
storage node.
The following is a guideline for you to perform operations with storage nodes.
To
Add a storage node to
the management
server
Remove a storage
node from the
management server
337
Do
Click Add.
In the Add storage node (p. 338) window, specify the machine the storage node is
installed on.
Adding a storage node establishes a trusted relationship between the
management server and the storage node, in the same way as when you add
machines to the server. Once the storage node is added to the management
server, you will be able to create managed vaults on the node.
Click Remove.
Once the storage node is removed from the management server, the vaults being
managed by the storage node disappear from the vault list (p. 135) and become
unavailable for performing operations. All the plans and tasks that use these vaults
will fail. All the databases and vaults of this storage node remain untouched.
It is possible to add the previously removed storage node to the management
server again. As a result, all the vaults managed by the storage node will appear in
the vault list and become available once again for all the plans and tasks that used
these vaults.
chevron.
Copyright © Acronis, Inc., 2000-2010
