Use the fully-qualified domain name (FQDN) of the storage node, that is, a completely specified
domain name ending in a top-level domain. Do not enter "127.0.0.1" or "localhost" as the
storage node IP/name. These settings are no good even if the management server and the
storage node are on the same machine, because, after the policy using the storage node is
deployed, each agent will try to access the storage node as if it were installed on the agent's
host.
2. To provide a valid user account for the machine, click Options>>, and specify:

User name. When entering a name of an Active Directory user account, be sure to also
specify the domain name (DOMAIN\Username or Username@domain). The user account has
to be a member of the Administrators group on the machine.

Password. The password for the account.
Select the Save password check box to store the password for the account.
3. Click OK.
Because registration requires the storage node's participation, it cannot take place when the
machine is offline.
7.1.5.2

Storage node details

The Storage node details window accumulates in four tabs all information on the selected Acronis
Backup & Recovery 10 Storage Node. This information is also duplicated on the Information pane.
Storage node properties
The tab displays the following information about the selected storage node:
 Name - the name of the machine where the storage node is installed

IP - the IP address of the machine where the storage node is installed

Availability:

Unknown - this status is displayed until the first connection between the management server
and the storage node is established after adding the storage node or starting the
management server's service.
 Online - the storage node is available for the management server. This means that the last
management server's connection to the node was successful. Connection is established every
2 minutes.
 Offline - the storage node is unavailable.

Withdrawn - the storage node was registered on another management server. As a result, it
is not possible to control the node from the current management server.
 Archives - the total number of archives stored in all the vaults managed by the storage node
 Backups - the total number of backups stored within the archives in all the vaults managed by
the storage node.
Vaults
This tab displays a list of the vaults, managed by the storage node.
To open a managed vault for detailed examination and to perform operations on it, select the vault,
then click View vault (on the tab's toolbar). In the Centralized vault (p. 131) view, perform the
required actions.
