FOREWORD
Introduction
This guide covers various models; assembly and feature videos are available online.
PARTS LIST
Seat Base
The foundational component of the chair where the seat mechanism attaches.
Headrest Cushion
Padded support for the head and neck.
Caster Wheels
Wheels for mobility, attach to the five-star base.
Back Support
The main backrest structure providing comfort and support.
M8 Tool
Specialized wrench for tightening M8 screws during assembly.
Seat Mechanism
The assembly for adjusting seat height and tilt.
Gas Lift
Pneumatic cylinder for seat height adjustment.
Five Star Foot Base
The stable, five-legged base supporting the chair.
Custom M8 Screws x 4
Specific screws required for securing chair components.
Step 1: Seat Base Assembly
Prepare Seat Base
Invert seat base and remove 4 screws and washers.
Attach Seat Mechanism
Mount seat mechanism to base, ensuring arrow points forward, and secure with screws.
Step 2: Base and Caster Installation
Install Casters
Invert five-star base, align caster wheels, and press them into place.
Prepare Gas Lift
Remove the red protective cap from the gas lift before proceeding.
Step 3: Gas Lift and Base Integration
Install Gas Lift and Base
Attach gas lift to seat mechanism, then attach the five-star base assembly to the gas lift.
Position Chair Upright
Carefully turn the chair upright; do not adjust the lever until assembly is complete.
Step 4: Back Support Attachment
Orient Mounting Bracket
Rotate the bracket to its vertical position for correct alignment.
Attach Back Support
Slide the back support onto the mounted brackets.
Step 5: Armrest Installation
Secure Armrests
Fasten 2 custom M8 screws on each side to attach the armrests.
Adjusting Recline Angle
Operate Recline Lever
Pull lever to adjust angle, release to lock. Maintain slight back support pressure for safety.
Adjusting Seat Height
Operate Height Lever
Pull lever up for height adjustment, release to maintain set height.
Tilt Function Control
Operate Tilt Lever
Pull lever out to enable tilt, push in to disable tilt.
Product Registration
Registration Benefits
Register online for enhanced support, warranty, and additional benefits.
Warranty Information
Accessing Warranty Details
Visit the official website for comprehensive warranty information.
