Parts List
Seat Base
The primary seating component of the chair.
Headrest Cushion
Cushion for head and neck support.
Penta RS1 Caster x 5
Set of 5 wheels for the chair base.
Back Support
The main backrest component of the chair.
Lumbar Support Cushion
Cushion for lower back support.
M8 Tool
Tool provided for M8 screws.
Seat Mechanism
Component connecting the seat to the gas lift.
Gas Lift
Pneumatic cylinder for seat height adjustment.
Five Star Foot Base
The base with five legs for stability.
Custom M8 Screws x 4
Specific screws provided for assembly.
Assembly Instructions
Step 1: Seat Base Assembly
Assemble the seat base by attaching the mechanism.
Step 2: Base and Wheel Assembly
Install caster wheels onto the five-star foot base and prepare gas lift.
Step 3: Gas Lift and Base Assembly
Connect gas lift to seat mechanism and attach base assembly.
Step 4: Back Support Installation
Attach the back support to the chair mechanism.
Step 5: Cushion Installation
Install headrest and lumbar support cushions using screws.
Step 6: Recline Adjustment
Adjust the chair's recline angle using the lever.
Step 7: Seat Height Adjustment
Adjust the seat height using the lever.
Step 8: Tilt and Resistance Adjustment
Adjust chair tilt and resistance using levers and dials.
Step 9: Armrest Height Adjustment
Adjust the height of the armrests.
Step 10: Armrest Adjustment
Adjust armrest position (fore/aft) and rotation.
