Summarization of Contents
Unboxing and Initial Inspection
Unboxing and Initial Inspection
Read the manual, inspect the package for damage, and ensure installation by professionals.
Installation Preparation
Environmental and Tool Requirements
Place batteries in a well-ventilated, clean, and dry area away from heat sources. Use insulated tools.
Battery Module Installation Procedure
Cabinet Information
Details on the 19-inch standard cabinet dimensions suitable for TL-LFP series modules.
Securing Battery Shelves and Modules
Step 1: Secure the battery shelf firmly into the cabinet using M6 bolts.
Placing and Securing Modules
Step 2: Place the module onto the shelf and push it into the cabinet.
Module Front Panel Attachment
Step 3: Secure the module front panel to the cabinet's 19" rails using M6 bolts.
Installing Multiple Modules
Step 4: Install remaining battery modules and ensure all are fixed firmly.
Stand-off Insulator and Busbar Mounting
Step 5: Install stand-off insulators and fix output busbars to the cabinet's top panel.
Positive Cable Connection
Step 6: Connect positive terminals to busbars through cabinet top panel holes.
Negative Cable Connection
Step 7: Connect negative terminals to negative busbars through cabinet top panel holes.
Repeating Module Connections
Step 8: Repeat steps 6 and 7 for all installed modules.
Communication Line Connection
Step 9: Connect communication lines between modules, reserving one for PCS.
Earthing Cable Connection
Step 10: Connect each module's front panel to the 19" rack using an earthing cable.
Final Installation Confirmation
Step 11: Installation is complete.
