ИНСТРУКЦИЯ
WALL MOUNT
FOR LED/LCD TV-SETS
Настенное крепление для LED/LCD телевизоров
22"-65"
56 -165
FULL MOTION
пожизненная
ГАРАНТИЯ
НАКЛОННО-ПОВОРОТНЫЙ
ATLANTIS-45
MAX WEIGHT
Нагрузка
45
кг
DISTANCE
Расстояние до стены
55-470
мм
TILT
Угол наклона
+5° -15°
TURN
Угол поворота
160°
COLOR
Цвет
GREY TITAN
min
стандарты
75 х 75
VESA
max
400 х 400
Advertisement
Related Manuals for KROMAX ATLANTIS-45 White
Summary of Contents for KROMAX ATLANTIS-45 White
- Page 1 ИНСТРУКЦИЯ WALL MOUNT ATLANTIS-45 FOR LED/LCD TV-SETS Настенное крепление для LED/LCD телевизоров 22"-65" MAX WEIGHT Нагрузка 56 -165 кг DISTANCE Расстояние до стены 55-470 мм TILT Угол наклона +5° -15° TURN Угол поворота 160° COLOR Цвет GREY TITAN стандарты 75 х 75 VESA 400 х...
- Page 2 Dear Customer Thank you for choosing our product. This user manual contains the information about the assembling procedure and mounting instructions. Please carefully it and follow the guidelines stated here in order to completely all the advantages and convenience which our wall mounts give you.
- Page 3 ATTENTION · ВНИМАНИЕ ATLANTIS-45 bracket for wall mounting LED /LCD TV-sets with screen sizes 22“-65” inches (56-165 cm) and maximum load for 45 kg. • The wall plate must be mounted on solid concrete, concrete block mounting or wood stud with plaster thickness not more than 3 mm.
-
Page 4: Complete Set
COMPLETE SET · КОМПЛЕКТАЦИЯ M4*30mm x 4 M4*15mm x 4 M5*30mm x 4 5*15 M6*30mm x 4 M6*15mm x 4 M8*30mm x 4 M8*15mm x 4 WALL MOUNTING SET M8*8mm x 8 S=13 Ø5×Ø16×1,5 x 4 S=5 x 1 Ø6.3*65mm x 5 Ø10*65mm x 5 Ø6×Ø12×1 x 5 NECESSARY TOOLS... - Page 5 ШАГ STEP - Using a screwdriver to loosen the bolt on the TV plate. - Then lift and remove the TV plate from the bracket. - Remove the plastic covers. - Открутите винт на ТВ пластине. - Снимите ТВ пластину с кронштейна. - Снимите...
- Page 6 ШАГ STEP Wood Stud Mounting: - Using the bracket plate as a template, mark with a pencil five dots on a wall for drilling holes. - Drill in the wall five holes with 4 mm diameter and at least 40 mm depth. - Mount the bracket to the wall and fasten it with the bolts (A) and washers (E).
- Page 7 ШАГ STEP Solid Concrete and Concrete Block Mounting: - Using the bracket plate as a template, mark with a pencil five dots on a wall for drilling holes. - Drill in the wall five holes with 10 mm diameter and at least 65 mm depth. - Insert plastic anchors (B) in the holes and ensure they are fully wedged inside the wall.
- Page 8 ШАГ STEP - Attached the TV plate directly to the back of TV. - If the size of the TV plate is smaller than the size of the holes on the back of the TV, you can use the beams and the vertical bars refer to the following measure.
- Page 9 ШАГ STEP +5° - Lift the display together with the TV plate to the wall plate as shown in the fig. -15° - Than tighten the bolt back to the TV plate to fix them firmly. ±160° - Using the spanner to loosen the bolts before adjusting the view angle, and firmly tighten the them after adjustment.
- Page 10 СХЕМА · SCHEME +5° -15° 160° 75 mm 100 mm 200 mm ±3° 300 mm 400 mm...
-
Page 11: Warranty
The company Kromax provides a manufacturer’s warranty on all welded and mechanical connections of this item during the entire life period. In the event of a defect, the product will be repaired or replaced free of charge. Should the model be out of production, the company Kromax reserves the right to replace it for an equal cost and functionality. - Page 12 Office 1803, Olimpiyskiy10, Mytischi, Moscow region, Russia, 141009 8-800-5555-88-3 (all calls are for FREE in the territory of the Russian Federation) +7(495)926 0677; +7(495)926 0688 Россия, МО, г. Мытищи, Олимпийский пр-т, дом 10, офис1803 8-800-5555-88-3 (звонки по РФ БЕСПЛАТНО) +7(495)926 0677; +7(495)926 0688 Подробная информация на WWW.KROMAX.RU...
