- Page 1 OFFICE - 3 ИНСТРУКЦИЯ MAX WEIGHT DESK MOUNT Нагрузка FOR LED/LCD MONITORS кг Настольный кронштейн для LED/LCD мониторов TILT Угол наклона 15° 15° TURN Угол поворота 360° COLOR Цвет GREY TITAN 75х75 100х100 FULL MOTION НАКЛОННО-ПОВОРОТНЫЙ...
- Page 2 Dear Customer! Thank you for choosing our product. This user manual contains the information about assembling procedure and mounting instructions. Please care- fully learn it and follow the guidelines stated here in order to completely use all the advantages and convenience which our wall mounts give you.
- Page 3 ATTENTION · ВНИМАНИЕ OFFICE-3 bracket for table mounting LED/LCD monitors and TV-sets with screen sizes 15“-34” inches (38-86 cm) and maxi mum load for 12 kg. • This bracket is designed for tabletop mounting. Included accessories are designed exclusively for attachment to the table.
-
Page 4: Complete Set
COMPLETE SET · КОМПЛЕКТАЦИЯ M4*8mm x 8 M5*12mm x 8 M4 *12mm x 8 M5*8mm x 8 M6*12mm x 8 M6*8mm x 8 Ø4 8 Ø5 8 Ø6 8 S=4 x 1 S=5 x 1 S=3 x 1 NECESSARY TOOLS Ø10... - Page 5 ШАГ STEP S=3 (J) VESA - Use the Inner hexagon spanner S=3(J) to loosen the locking screw in order to separate the table fixation and VESA plate. - According to the thickness of the desk to use inner hexagon spanner S=5 (L) to change the location of the mount (1). - Использую...
- Page 6 ШАГ STEP Install the bracket to the desk - Select right holes on the mount (1) according to the thickness of desk. - Insert the mount (1) to the edge of the desk then tighten the knob to fix it firmly. Монтаж...
- Page 7 ШАГ STEP Install the bracket on the top of desk - Remove the mount (1) from the bracket at first. - Install the mount (2) to the bracket. - Install the bracket to the top of the desk. Screw must pass through the hole. The diameter of hole have to from 8.5mm to 70mm.
- Page 8 ШАГ STEP A/B/C D/E/F/G/H/I - Attach the VESA plate to the back of monitor using right screws (D/E/F/G/H/I/) and washers (A/B/C). - The VESA plate mounted on the TV back should be mounted symmetrically and evenly. - Закрепите VESA пластину на задней части монитора, используя подходящие винты (D/E/F/G/H/I/) и шайбы (A/B/C).
- Page 9 ШАГ STEP VESA - Insert the monitor with VESA plate into the bracket, then use the Inner hexagon spanner S=3(J) to tighten the screw firmly. - Установите монитор с закрепленным на нем VESA пластиной в основную часть кронштейна, затем затяните фиксирующий...
- Page 10 ШАГ STEP - Adjust the position and angle of the monitor for convenient viewing. - Using the inner hexagon spanner S=4 (K) to loosen the bolt before adjusting the view angle, and firmly tighten the bolt after adjustment. - Отрегулируйте положение экрана для удобного просмотра. - При...
- Page 11 ШАГ STEP - Run the cable through the cable clips holder. - Make sure the сcables are not deformed when adjusting the position. - Установите соединительные провода в специальный кабель канал. - Убедитесь, что провода не деформируются при регулировки положения.
- Page 12 ШАГ STEP - Please fasten the fixed nut as below procedure if the tilt angle cannot be fixed properly. Using the inner hexagon spanner S=3 (J) to loosen the locking screw at first, then remove the TV together with the TV plate. - Firmly tighten the fixed nut with a spanner in the clockwise direction.
- Page 13 СХЕМА · SCHEME 160 mm 160 mm 160 mm 160 mm Ø30 mm 100 mm max 411 mm 75 mm Ø32 mm min 73 mm...
- Page 14 Company KROMAX grants 18 years producer guarantee on all welding and mechanical connections. In case of any defects detection the product will be repaired or replaced for free. If the model is out of production, the company KROMAX has the right to offer substitute of the similar price and functionality.
- Page 15 ЗАМЕТКИ · NOTE...
- Page 16 Office 1803, Olimpiyskiy10, Mytischi, Moscow region, Russia, 141009 8-800-5555-88-3 (all calls are for FREE on the territory of Russian Federation) +7(495)926 0677; +7(495)926 0688 Россия, МО, г. Мытищи, Олимпийский пр-т, дом 10, офис1803 8-800-5555-88-3 (звонки по РФ БЕСПЛАТНО) +7(495)926 0677; +7(495)926 0688...
