KROMAX OFFICE-4 Manual

Desk mount for led/lcd monitors
Hide thumbs

Advertisement

Quick Links

Download this manual
ИНСТРУКЦИЯ
DESK MOUNT
FOR LED/LCD MONITORS
Настольный кронштейн для LED/LCD мониторов
15"-34"
38
-86
8
75 75
MAX
VESA
WEIGHT
100 100
4x
FULL MOTION
пожизненная
ГАРАНТИЯ
НАКЛОННО-ПОВОРОТНЫЙ
OFFICE-4
MAX WEIGHT
Нагрузка
8
4x
кг
TILT
Угол наклона
±15°
TURN
Угол поворота
360°
COLOR
Цвет
BLACK
75х75
100х100

Advertisement

loading
Need help?

Need help?

Do you have a question about the OFFICE-4 and is the answer not in the manual?

Questions and answers

Related Manuals for KROMAX OFFICE-4

Summary of Contents for KROMAX OFFICE-4

  • Page 1 ИНСТРУКЦИЯ OFFICE-4 DESK MOUNT FOR LED/LCD MONITORS Настольный кронштейн для LED/LCD мониторов 15"-34" MAX WEIGHT Нагрузка кг 75 75 VESA WEIGHT TILT 100 100 Угол наклона ±15° TURN Угол поворота 360° COLOR Цвет BLACK 75х75 100х100 FULL MOTION пожизненная ГАРАНТИЯ...
  • Page 2 Dear Customer! Thank you for choosing our product. This user manual contains the information about assembling procedure and mounting instructions. Please care- fully learn it and follow the guidelines stated here in order to completely use all the advantages and convenience which our wall mounts give you.
  • Page 3 ATTENTION · ВНИМАНИЕ OFFICE-4 bracket for table mounting LED/LCD monitors and TV-sets with screen sizes 15“-34” inches (38-86 cm) and the maximum total load for 4x8 kg. • This bracket is designed for tabletop mounting. Included accessories are designed exclusively for attachment to the table.

  • Page 4: Complete Set

    COMPLETE SET · КОМПЛЕКТАЦИЯ Ø4 16 Ø5 16 Ø6 16 M4*8mm x 16 M4 *12mm x 16 M5*8mm x 16 M5*12mm x 16 M6*8mm x 16 M6*12mm x 16 S=13x 1 S=4 x 1 S=5x 1 NECESSARY TOOLS Ø10...
  • Page 5 ШАГ STEP Install the bracket to the desk - Select right holes on the mount (1) according to the thickness of desk. - Insert the mount (1) to the edge of the desk then tighten the knob to fix it firmly. Монтаж...
  • Page 6 ШАГ STEP Install the bracket on the top of desk - Remove the mount (1) from the bracket at first. - Install the mount (2) to the bracket. - Install the bracket to the top of the desk. Screw must pass through the hole. The diameter of hole have to from 8.5mm to 70mm.
  • Page 7 ШАГ STEP - Insert the two arm components to the tube, then tighten the knob to fix the arm component to a proper height on the tube. - Установите кронштейны на штангу и зафиксируйте их на нужной высоте с помощью регулировочных ручек.
  • Page 8 ШАГ STEP A/B/C D/E/F/G/H/I - Use the inner hexagon spanner S=4 (J) to remove the locking screw in order to separate the table fixation and TV plate. - Screw two bolts on the back the display, don’t tighten it. Note: The washer (A/B/C) is only used for bolts (D,E,F,G,H,I). - Используя...
  • Page 9 ШАГ STEP - Lift and put the TV plate together with the TV back to the table fixation, then use the inner hexagon spanner S=4 (J) to firmly tighten the locking screw. - Установите монитор с закрепленной на нем ТВ пластиной в основную часть кронштейна, затем затяните фиксирующий...
  • Page 10 ШАГ STEP - Using the inner hexagon spanner S=4 (J) to loosen the bolt before adjusting the view angel, and firmly tighten the bolt after adjustment. - Route the cables along through the cable clip, the cables should be obligated some surplus in corner. Adjust the position and angle of the flat panel TV for convenient viewing.
  • Page 11 ШАГ STEP - Use the spanner to adjust the three bolts on the TV plate if the tilt angle cannot be fixed properly. Firmly tighten the three bolts after adjustment. - Если угол наклона не фиксируется в нужном положении, закрутите три регулировочных винта на ТВ пластине.
  • Page 12 СХЕМА · SCHEME max 872 mm 100 mm 75 mm max 300 mm...

  • Page 13: Warranty

    The company Kromax provides a manufacturer’s warranty on all welded and mechanical connections of this item during the entire life period. In the event of a defect, the product will be repaired or replaced free of charge. Should the model be out of production, the company Kromax reserves the right to replace it for an equal cost and functionality.
  • Page 14 ЗАМЕТКИ · NOTE...
