Summarization of Contents
Important Safeguards and Warnings
Electrical Safety Precautions
Adherence to electrical safety codes, power supply verification, SELV, limited power sources, safe installation, cord protection, and avoiding multiple power sources.
Environmental Operating Conditions
Guidance on camera placement and use regarding light, temperature, humidity, dust, liquids, ventilation, and protection against stress during transport.
Operation and Daily Maintenance
Dome Cover Cleaning
Methods for cleaning dirt from the dome cover using a soft brush or hairdryer, and for removing grease or fingerprints with a soft cloth and alcohol.
Device Structure
Device External Cables
Details the function, connector type, and description for external cables including audio in/out, LAN, and I/O ports.
Framework and Dimensions
Provides physical dimensions of the camera device through an illustration, with measurements indicated in millimeters.
Alarm Setup Configuration
Instructions on configuring alarm input and output settings via the web interface, covering relay activation and sensor types.
Alarm Output Application Modes
Describes two modes (A and B) for alarm output, detailing level and switch applications with voltage and current specifications for external circuits.
Device Installation
SD Card Installation (Optional)
Steps for installing a Micro SD card, including opening the lower cover, inserting the card, and re-securing the cover.
Mounting the Device
Guide to fixing the camera onto a surface using an installation map, expansion bolts, and mounting screws.
Connecting External Cables
Procedure for connecting power, audio, alarm, and network cables, with emphasis on waterproof connections for network cables.
Waterproof Network Connector
Instructions for installing an optional waterproof connector for the network port, crucial for outdoor installations.
Adjusting Monitoring Direction
Steps to adjust the camera's viewing angle by loosening, positioning, and re-tightening the adjustment screw.
Network Configuration
Modify IP Address
Instructions on changing the camera's IP address using the 'Quick Configuration Tool' or the WEB interface for network accessibility.
Login WEB Interface
Procedure to access the camera's web interface via a browser, requiring the correct IP address and user credentials.
