Summarization of Contents
General
INTRODUCTION
Overview of the Common Control System (CCS) development and purpose.
DESCRIPTION
Explains the functions of the display panel for supervisors and operators.
Button Keypad
Details the location and function of the four directional and one center button.
LED Indicator Lights
Describes the function of illuminated LEDs on the dash display.
LCD Screen
Lists the information displayed on the LCD screen when the key is ON.
DASH DISPLAY MENU ACCESS
Steps to access the dash display menu system and enter supervisor password.
Menu Navigation
Explains how to navigate menus using dash display buttons UP, RIGHT, DOWN, LEFT, ENTER.
DASH DISPLAY MENU OPERATION
How the CCS software is accessed and used for truck functions.
NODES
Defines "Node" as a term for control devices and lists common node designations.
MENU STRUCTURE
Describes the base menu structure and password protection for menu items.
Supervisor-Level Menu
HOUR METERS
Allows viewing of three different hour meter functions recorded by the display.
H1 Truck Hours
Accumulates time when the key switch is ON and operator presence is active.
H2 Traction Hours
Accumulates time when the traction motor is activated.
H3 Pump Hours
Accumulates time when the lift motor is activated.
H4 Steer Hours
Accumulates time when the steer motor is activated.
H5 Odometer Hours
Shows total miles/kilometers driven based on traction hours.
H10 Display Hours
Shows total hours of operation of the display unit.
H30 Traction Node Hours
Shows total hours of operation for the traction controller.
H41 Slave Traction Node Hours
Shows total hours of operation for the steer controller.
H50 Pump Node Hours
Shows total hours of operation for the pump controller.
PERFORMANCE
Allows setting of four independent performance levels, configurable by supervisor or technician.
Performance Level 1
Details parameters for setting Performance Level 1, covering forward, reverse, acceleration, etc.
P1.1 Forward Speed
Sets the maximum forward travel speed of the lift truck in MPH or KPH.
P1.2 Reverse Speed
Sets the maximum reverse travel speed of the lift truck in MPH or KPH.
P1.3 Acceleration
Adjusts traction acceleration from maximum to minimum, with a range of 1 to 9.
P1.4 Plug Braking
Adjusts maximum braking rate when the control handle is fully reversed (plugging mode).
P1.5 Coast Braking
Adjusts maximum braking rate when the control handle is returned to neutral.
P1.6 Lift Speed
Adjusts the mast lift speed from maximum to a lower setting (1-9).
P1.7 Lower Speed
Adjusts the mast lower speed from maximum to a lower setting (1-9).
P1.8 Lift Acceleration
Adjusts hydraulic pump motor acceleration during lifting (1-9).
P1.9 Lift Deceleration
Adjusts hydraulic pump motor deceleration during lifting (1-9).
P1.10 Lower Acceleration
Adjusts solenoid acceleration during lowering (1-9).
P1.11 Lower Deceleration
Adjusts solenoid deceleration during lowering (1-9).
P1.12 Tilt Speed Main
Adjusts tilt speed when mast is elevated above free lift.
P1.13 Tilt Speed Free
Adjusts maximum tilt speed when mast is raised above free-lift position (1-9).
P1.14 Tilt Acceleration
Adjusts the rate of tilt speed acceleration (1-9).
P1.15 Tilt Deceleration
Adjusts the rate of tilt speed deceleration (1-9).
P1.16 Sideshift Speed Main
Adjusts the maximum sideshift speed (1-9).
P1.17 4th Function In Speed
Adjusts the maximum speed for the 4th function when moving inward (1-9).
P1.18 4th Function Out Speed
Adjusts the maximum speed for the 4th function when moving outward (1-9).
P1.40 Sideshift Speed Free
Adjusts maximum sideshift speed when mast is above freelift position (1-9).
OPERATOR PASSWORDS
Allows supervisors to add, edit, or delete operator passwords and clear logs.
Add Password
Use this menu to add new operator passwords to the system.
Delete Password
Use this menu to delete existing operator or supervisor passwords.
Edit Password
Use this menu to edit existing operator passwords, including changing the password.
Operator Password Feature
Screen to enable or disable the operator password feature.
Clear Operator Log
Clears all stored information from the operator log.
OPERATOR LOGS
Provides access to operator logs, showing hours operated per selected operator.
Operator 1-150
Displays hours the selected operator has operated the truck.
INFORMATION
Displays specific, factory-installed information about the lift truck that cannot be changed.
I1 Model
Displays the lift truck model; for information only.
I3 Serial Number
Displays the serial number of the lift truck; for information only.
I5 Truck Voltage
Displays the voltage of the lift truck; for information only.
SOFTWARE VERSIONS
Displays the truck software version, coordinating software across all nodes.
