ASSEMBLY AND INSTALLATION INSTRUCTIONS
Important: Read entire instruction sheet before
assembling or installing mantel kit.
These mantels are only approved for use with any
DESA Heating, LLC 21" or 23" electric and gas
fireplace system. Do not use mantel with any other
product.
This mantel kit contains the following:
• Mantel pieces - unassembled and numbered as follows:
#1 Base
#2 Right Side Assembly
#3 Left Side Assembly
#4Header
#5 Top
• Hardware Package
16 - 1
/
" Wood Screws
1
4
* Extra hardware may be included
Tools required:
• Power Screwdriver with #2 Phillips Bit
W21TP and W21TO
Mantel and Base
114325-01
www.desatech.com
If any wood pieces are missing or damaged, contact the
dealer where you purchased this mantel for replacement. If
hardware is missing or damaged, contact DESA Heating, LLC
at 1-866-672-6040 for referral information. You can also visit
DESA Heating, LLC's web site at www.desatech.com.
Note: Gather all mantel pieces together before assembling
mantel.
WARNING: Only use 1
mantel. Damage to mantel will result if other screws
are used for this purpose.
IMPORTANT: A serial number label is located inside of right
side panel and on outside package. When calling to request
technical assistance or for replacement parts please have
serial number ready.
/
" screws to assemble
1
4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Desa Mantel and Base W21TO
Summary of Contents for Desa Mantel and Base W21TO
-
Page 1: Assembly And Installation Instructions
Important: Read entire instruction sheet before assembling or installing mantel kit. These mantels are only approved for use with any DESA Heating, LLC 21" or 23" electric and gas fireplace system. Do not use mantel with any other product. This mantel kit contains the following: • Mantel pieces - unassembled and numbered as follows:... -
Page 2: Assembling Mantel
ASSEmbLING mANTEL Important: more than one person is required to lift assembled mantel. Lift mantel by leg assemblies. Lifting by header or mantel top could damage mantel. Use the following illustrations to assemble mantel. Use only screws provided. Header #4 Right Leg Assembly #2 Header... - Page 3 INSTALLING mANTEL WITH GAS fIREpLACE 1. Mantel must be installed flush with wall. Remove base- board. Baseboard will prevent proper installation of man- tel and base. Baseboard must be altered to fit mantel. 2. Place mantel against wall at installation location. Cut an access hole in hearth base to run gas line to fireplace (see Figure 4, page 2). Make sure to locate access hole so it is inside cabinet mantel. Note: You can secure base to floor using wood screws. Countersink screw heads and putty over. 3. Route flexible gas line through access hole in hearth base.
- Page 4 DESA Heating, LLC 2701 Industrial Drive Bowling Green, KY 42101 www.desatech.com 1-866-672-6040 123751 01 NOT A UPC 123751-01 Rev. A 04/08...
