Summary of Contents for Iiyama ProLite XU2395WSU-B1
- Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a...
- Page 3 ProLite XU2390HS, ProLite XUB2390HS and ProLite XUB2790HS : TCO compliant Congratulations! This product is TCO Certified for Sustainable IT TCO Certified is an international third party sustainability certification for IT products. TCO Certified ensures that the manufacture, use and recycling of IT products reflect environmental, social and economic responsibility.
- Page 4 For displays with glossy bezels the user should consider the placement of the display as the bezel may cause disturbing reflections from surrounding light and bright surfaces. We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com...
-
Page 5: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 WALL MOUNTING ................5 FITTING AND REMOVAL OF BASE : ProLite XUB2395WSU ..6 FITTING AND REMOVAL OF BASE : ProLite XU2395WSU ..7 CONTROLS AND CONNECTORS : ProLite XUB2395WSU ..8 CONTROLS AND CONNECTORS : ProLite XU2395WSU .....9... -
Page 6: For Your Safety
DO NOT PUT ANY OBJECT INTO THE MONITOR Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fire, electric shock or damage. - Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables and possibly cause injury.
-
Page 8: Special Notes On Lcd Monitors
If you have to return your unit for service and the original packaging has been discarded, NOTE please contact your dealer or iiyama service center for advice or replacement packaging. CLEANING If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center. -
Page 9: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. Power Cable* DisplayPort Cable... -
Page 10: Wall Mounting
WALL MOUNTING WARNING When you use with the wall mounting, in consideration of thickness of the mounting stage, tighten the M4 Screw with washer which “L” length is 7mm to fasten the monitor. Using the screw longer than this may cause electric shock or damage because it may contact with the electrical parts inside the monitor. -
Page 11: Fitting And Removal Of Base : Prolite Xub2395Wsu
FITTING AND REMOVAL OF BASE : ProLite XUB2395WSU CAUTION Put the monitor on a stable surface. The monitor may cause injury or damage if it falls or is dropped. Do not give a strong impact to the monitor. It may cause damage. Unplug the monitor before removal or installation to avoid electric shock or damage. -
Page 12: Fitting And Removal Of Base : Prolite Xu2395Wsu
FITTING AND REMOVAL OF BASE : ProLite XU2395WSU CAUTION Put the monitor on a stable surface. The monitor may cause injury or damage if it falls or is dropped. Do not give a strong impact to the monitor. It may cause damage. Unplug the monitor before removal or installation to avoid electric shock or damage. -
Page 13: Controls And Connectors : Prolite Xub2395Wsu
CONTROLS AND CONNECTORS : ProLite XUB2395WSU <Front> <Back> Power Indicator Blue: Normal operation NOTE Orange: Power Management Auto (AUTO) - / ECO ( - ) + / Volume / Blue Light Reducer Button ( + ) Menu (MENU) Power Switch ( ) Speakers USB Downstream Connector ( USB Downstream Connector ( USB Upstream Connectore ( Headphone connector ( ) Audio Connector ( VGA Connector (D-SUB) HDMI Connector (HDMI) DisplayPort Connector (DP) -
Page 14: Controls And Connectors : Prolite Xu2395Wsu
CONTROLS AND CONNECTORS : ProLite XU2395WSU <Front> <Back> Power Indicator Blue: Normal operation NOTE Orange: Power Management Auto (AUTO) - / ECO ( - ) + / Volume / Blue Light Reducer Button ( + ) Menu (MENU) Power Switch ( ) Speakers USB Downstream Connector ( USB Downstream Connector ( USB Upstream Connectore ( Headphone connector ( ) Audio Connector ( VGA Connector (D-SUB) HDMI Connector (HDMI) DisplayPort Connector (DP) -
Page 15: Connecting Your Monitor : Prolite Xub2395Wsu
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. -
Page 16: Connecting Your Monitor : Prolite Xu2395Wsu
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. -
Page 17: Computer Setting
COMPUTER SETTING Signal Timing Change to the desired signal timing listed on page 30: COMPLIANT TIMING. ADJUSTING THE VIEWING ANGLE : ProLite XU2395WSU For optimal viewing it is recommended to look at the full face of the monitor. ... -
Page 18: Adjusting The Height And The Viewing Angle : Prolite Xub2395Wsu
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : ProLite XUB2395WSU For optimal viewing it is recommended to position yourself directly opposite to the full face of the monitor, then adjust the monitor’s height and angle to your own preference. ... -
Page 19: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 30. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 21 for SCREEN ADJUSTMENTS. -
Page 20: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Luminance ProLite XUB2395WSU LUMINANCE CONTRAST IMAGE SETTINGS COLOR SETTINGS BRIGHTNESS EXTRA I-STYLE COLOR STANDARD ADV. CONTRAST Adjustment Item Problem / Option Button to Press Too dull Contrast Too intense Too dark Brightness * Too bright For general windows environment and monitor Standard default setting. - Page 21 Image Settings ProLite XUB2395WSU LUMINANCE IMAGE SETTINGS IMAGE SETTINGS PIXEL CLOCK COLOR SETTINGS PHASE HORIZONTAL POSITION EXTRA VERTICAL POSITION ASPECT RATIO FULL Adjustment Item Problem / Option Button to Press Too narrow Pixel Clock* Too wide Phase* To correct flickering text or lines Too left Horizontal Position* Too right Too low...
- Page 22 Color Settings ProLite XUB2395WSU LUMINANCE COLOR SETTINGS IMAGE SETTINGS GAMMA GAMMA1 COLOR TEMP. COLOR SETTINGS USER USER PRESET EXTRA GREEN BLUE Adjustment Item Problem / Option Button to Press Gamma1 Normal Gamma Gamma2 High contrast Gamma3 Dark Warm Greenish white Normal Yellowish white Cool...
- Page 23 ProLite XUB2395WSU LUMINANCE ON SCREEN DISPLAY SETTINGS IMAGE SETTINGS OSD HORIZONTAL POSITION COLOR SETTINGS OSD VERTICAL POSITION OSD TIME EXTRA LANGUAGE ENGLISH Adjustment Item Problem / Option Button to Press OSD is too left OSD Horizontal Position OSD is too right OSD is too low OSD Vertical Position OSD is too high...
- Page 24 Extra ProLite XUB2395WSU LUMINANCE EXTRA IMAGE SETTINGS RESET COLOR SETTINGS DDC/CI SIGNAL SELECT HDMI EXTRA OVERDRIVE AUDIO SOURCE LINE IN OPENING LOGO INFORMATION Adjustment Item Problem / Option Button to Press Factory-preset data is restored. Reset Return to Menu. DDC/CI is On. DDC / CI DDC/CI is Off.
- Page 25 Direct You can skip the Menu items and display an adjustment scale directly by using the following button operations. Volume: Press the + Button when the Menu is not displayed. Adjustment Item Problem / Option Button to Press Too soft Volume Too loud Auto Adjust: Press and hold the AUTO Button for 3-4 seconds when the Menu is not displayed.
-
Page 26: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Image Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com). Adjust the image by following the procedure below to get the desired picture. - Page 27 Pressing and holding of the AUTO Button for about 3-4 seconds. (Auto Adjust) Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Image Adjust. Adjust the V.Position so that the top and bottom of the picture frame will fit to the display area. 1) Adjust the H.Position so that the left side of the picture frame will move to the left edge of the display area. 2) Stretch the right side of the picture frame to the right edge of the display area by adjusting the Clock.
- Page 28 Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern. NOTE In case the strong flicker or blurs remain on a part of the screen, repeat steps because the Clock may not be adjusted correctly. If the flicker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from again. Adjust the H.Position after the Phase adjustment if the horizontal position moves during the adjustment. Adjust the Brightness and Color to get the desired picture after you complete the Clock and Phase adjustments. Put back your favorite wallpaper.
-
Page 29: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of ENERGY STAR ® and VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. -
Page 30: Trouble Shooting
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... -
Page 31: Recycling Information
A strange noise The Audio Cable is properly connected. is heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. 26 TROUBLE SHOOTING / RECYCLING INFORMATION... -
Page 32: Appendix
APPENDIX Design and specifications are subject to change without prior notice. SPECIFICATIONS : ProLite XUB2395WSU Size Category 23" Panel technology Size Diagonal: 22.5" (57.15cm) Pixel pitch 0.25425mm H × 0.24765mm V Brightness 250cd/m (Typical) Panel Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left / Up / Down: 89 degrees each (Typical) Response time 4ms (Gray to Gray) Display Colors Approx.1.07B Analog: Horizontal: 30.0-89.0kHz, Vertical: 50-76Hz Sync Frequency Digital(HDMI): Horizontal: 30.0-85.0kHz, Vertical: 50-76Hz Digital(DisplayPort): Horizontal: 95.0-95.0kHz, Vertical: 48-75Hz... -
Page 33: Specifications : Prolite Xu2395Wsu
SPECIFICATIONS : ProLite XU2395WSU Size Category 23" Panel technology Size Diagonal: 22.5" (57.15cm) Pixel pitch 0.25425mm H × 0.24765mm V Brightness 250cd/m (Typical) Panel Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left / Up / Down: 89 degrees each (Typical) Response time 4ms (Gray to Gray) Display Colors Approx.1.07B Analog: Horizontal: 30.0-89.0kHz, Vertical: 50-76Hz Sync Frequency Digital(HDMI): Horizontal: 30.0-85.0kHz, Vertical: 50-76Hz Digital(DisplayPort): Horizontal: 95.0-95.0kHz, Vertical: 48-75Hz Native Resolution... -
Page 34: Dimensions : Prolite Xub2395Wsu
DIMENSIONS : ProLite XUB2395WSU 499.0mm/19.6” 43.5mm/1.7” 495.5mm/19.5” 250.0mm/9.8” ( ) : Maximum adjustment range DIMENSIONS : ProLite XU2395WSU 499.0mm/19.6” 43.5mm/1.7” 495.5mm/19.5” 219.5mm/8.6” APPENDIX 29... -
Page 35: Compliant Timing
COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 640 × 480 37.500kHz 75.000Hz 31.500MHz 37.861kHz 72.809Hz 31.500MHz 35.156kHz 56.250Hz 36.000MHz 37.879kHz 60.317Hz 40.000MHz 800 × 600 46.875kHz 75.000Hz 49.500MHz 48.077kHz 72.188Hz 50.000MHz 48.363kHz 60.004Hz 65.000MHz 1024 ×...
