Rolls SLC19 Specifications

INTRODUCTION
Thank you for your purchase of the SLC19 Stereo Level Control.
The SLC19 is a simple device designed to control stereo line-level
audio signals such as those connected to powered speakers, com-
puter speakers, microphones, or anywhere an inline level control is
desired.
WARRANTY INFO
Please visit our website, www.rolls.com, for the Rolls 1 Year War-
ranty information and registration.
FRONT PANEL
LEFT: 1/4" TRS and XLR Input jack.
LEVEL: Adjusts the level of the signals at the Left and Right Input
jacks.
RIGHT: 1/4" TRS and XLR Input jack.
MUTE: When pressed in, the signals are all muted.
REAR PANEL
LEFT: 1/4" TRS and XLR Output jack.
RIGHT: 1/4" TRS and XLR Output jack.
WARNING: DO NOT CONNECT THE SLC19 IN REVERSE.
VERIFY THAT THE SLC19 INPUTS ARE CONNECTED TO THE
LINE-LEVEL OUTPUTS OF THE DEVICE TO BE CONTROLLED.
ALSO - DO NOT CONNECT THE SLC19 TO ANY SPEAKER-
LEVEL OR POWERED SIGNAL. DOING SO WILL DAMAGE THE
UNIT.
