Rolls RD320 Owner's Manual

LIMITED WARRANTY

This product is warranted to the original consumer purchaser to be free
from defects in materials and workmanship under normal installation, use and
service for a period of one (1) year from the date of purchase as shown on the
purchaser's receipt.
The obligation of Rolls Corporation under this warranty shall be limited
to repair or replacement (at our option), during the warranty period of any part
which proves defective in material or workmanship under normal installation,
use and service, provided the product is returned to Rolls Corporation, TRANS-
PORTATION CHARGES PREPAID. Products returned to us or to an authorized
Service Center must be accompanied by a copy of the purchase receipt. In the
absence of such purchase receipt, the warranty period shall be one (1) year from
the date of manufacture.
This warranty shall be invalid if the product is damaged as a result of
defacement, misuse, abuse, neglect, accident, destruction or alteration of the
serial number, improper electrical voltages or currents, repair, alteration or
maintenance by any person or party other than our own service facility or an
authorized Service Center, or any use violative of instructions furnished by us.
This one-year warranty is in lieu of all expressed warranties, obligations
or liabilities. ANY IMPLIED WARRANTIES, OBLIGATIONS, OR LIABILI-
TIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED IN DURATION TO THE ONE YEAR DURATION OF
THIS WRITTEN LIMITED WARRANTY. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to
you.
IN NO EVENT SHALL WE BE LIABLE FOR ANY SPECIAL, INCI-
DENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF THIS OR
ANY OTHER WARRANTY, EXPRESSED OR IMPLIED, WHATSOEVER.
Some states do not allow the exclusion or limitation of special, incidental or
consequential damages so the above limitation or exclusion may not apply to
you. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
ROLLS CORPORATION
SALT LAKE CITY, UTAH
7/99
RD320
Digital Room Delay
PWR
5 10 20 40 80 160 MS uS

SPECIFICATIONS

Max. Input:
Input Impedance:
Output Impedance:
Delay Range (long):
Delay Resolution (long):
Delay Range (short):
Delay Resolution (short):
Frequency Response:
THD:
Size:
Weight:
INPUT LEVEL
+16 +10 0 -7 -13
INPUT
LEVEL
RD320
+16 dBV
10k balanced
50 balanced
.005 to .320 Sec.
.005 Sec.
.00004 Sec. to .00128
.00004 Sec (Approx 1/2 the Long range and res.)
20Hz to 20kHz (+/-3 dB)
.09%
1.75" H x 19" W x 5.25" D.
7 lbs.
OWNERS MANUAL
OUTPUT
LEVEL
