- Page 1 ESP-01/07/12 Series Modules User's Manual OEM/Integrators Installation Manual Version 1.4 Ai-Thinker Inc Copyright (c) 2017...
- Page 2 ESP-01/07/12 Series Modules User's Manual V1.4 Revision Record Date Version Author Release Notes 2017.07.01 V1.0 Wang Chong First Version 2017.09.04 V1.1 Wang Chong Add ESP-01M, Delete ESP-12E Modify the GPIO4 pin description, change 2017.12.18 V1.2 Fang Dongbin the contact number 2018.3.10 V1.3 Lv Junxiong...
- Page 3 ESP-01/07/12 Series Modules User's Manual V1.4 FCC STATEMENT Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
-
Page 4: Table Of Contents
ESP-01/07/12 Series Modules User's Manual V1.4 Table Of Contents 1 Product Overview ....................1 1.1 Product Features ..................1 1.2 Application Plan ..................1 2 Module Interface ....................2 2.1 Package Size ................... 2 2.1 Pin Definition ..................6 ... - Page 5 ESP-01/07/12 Series Modules User's Manual V1.4 5.1.4 AT+RESTORE ................18 5.2 Use Examples ..................18 5.2.1 TCP Communication Test ............18 5.2.2 UDP Communication Test ............20 6 FAQ ......................... 22 6.1 Garbage Instructions When Power Is On ..........22 ...
-
Page 6: Product Overview
Wireless location sensing device n Smart socket/intelligent light n IP camera n Security ID tag n Mesh network n Sensor network n Wireless positioning system beacon Page 1 of 23 Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 7: Module Interface
ESP-01/07/12 Series Modules User's Manual V1.4 2 Module Interface 2.1 Package Size Figure 2.1 ESP-01/ESP-01S pin dimensions Figure 2.2 ESP-01M pin dimensions Page 2 of 23 Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... - Page 8 ESP-01/07/12 Series Modules User's Manual V1.4 Figure 2.3 ESP-01F pin dimensions Figure 2.4 ESP-07 pin dimensions Page 3 of 23 Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved...
- Page 9 ESP-01/07/12 Series Modules User's Manual V1.4 Figure 2.5 ESP-07S pin dimensions Figure 2.6 ESP-12F pin dimensions Page 4 of 23 Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved...
- Page 10 ESP-01/07/12 Series Modules User's Manual V1.4 Figure 2.7 ESP-12S pin dimensions Figure 2.7 ESP-01E pin dimensions Page 5 of 23 Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved...
-
Page 11: Pin Definition
VCC Module power supply pin, the voltage range of 3.0 ~ 3.6V CS0 Flash chip select signal Slave Output Master Input IO9 Gpio9，Only ESP-01M/01E Can Page 6 of 23 Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 12: Boot Mode
CH_PD Mode GPIO15 GPIO0 GPIO2 TXD0 (EN) Download high high high high mode Running high high high high high mode Chip Test high high mode Page 7 of 23 Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 13: Electrical Characteristics
Note: Unless otherwise specified, the test conditions are: VDD = 3.3 V and temperature 20 ℃. 3.4 Power Consumption All measurements are made at the antenna interface without SAW filters. Page 8 of 23 Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... - Page 14 100 seconds. Every 300 s wake up after 0.3s - 1s connected to the AP to send data, the overall average current can be much smaller than 2mA. Page 9 of 23 Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved...
-
Page 15: Transmit Power
Table 3.6 Receiving Sensitivity Parameter Unit DSSS, 1 Mbps CCK, 11 Mbps 6 Mbps (1/2 BPSK) 54 Mbps (3/4 64-QAM) HT20, MCS7 (65 Mbps, 72.2 Mbps) Page 10 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 16: Hardware Guidance
LDO 3.3V, it is strongly recommended to buy a new development board. Figure 4.1 Typical application of ESP-01 Figure 4.2 Typical application of ESP-01S Figure 4.3 Typical application of ESP-01M Page 11 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... - Page 17 ESP-01/07/12 Series Modules User's Manual V1.4 Figure 4.4 Typical application of ESP-01F Figure 4.5 Typical application of ESP-07 Figure 4.6 Typical application of ESP-07S Page 12 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved...
-
Page 18: Pcb Antenna Display Instructions
The ESP8266 series module can be soldered to the PCB board. In order to get the best RF performance of the end product, please pay attention to the rational Page 13 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 19: Module Peripheral Routing Instructions
I/O lines. This can suppress overshoot when switching power supplies and make the signal smooth. Series resistance can also prevent electrostatic discharge (ESD) to some extent. Page 14 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 20: Gpio Level Conversion
4.4 GPIO Level Conversion Figure 4.8 Transistor level conversion 4.5 Power Supply Reference Design Figure 4.9 Power supply reference 4.6 ADC Supply Reference Design Figure 4.10 ADC supply reference Page 15 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 21: Automatically Download Reference Design
ESP-01/07/12 Series Modules User's Manual V1.4 4.7 Automatically Download Reference Design Figure 4.11 Automatically Download Reference Design 4.8 Reflow oven temperature curve Figure 4.12 Reflow furnace temperature curve Page 16 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 22: Usage Guide
AT+GMR AT version:1.2.0.0(Jul 1 2016 20:04:45) Example SDK version:1.5.4.1(39cb9a32) Ai-Thinker Technology Co. Ltd. Dec 2 2016 14:21:16 5.1.3 AT+RST parameters Description soft restart module AT+RST Example Page 17 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 23: At+Restore
Ai-Thinker Technology Co. Ltd. ready AT+CWMODE=2 //configured for AP mode AT+CWSAP_DEF="TCP_Server","12345678",5,4 //Configure AP information AT+CIFSR //Query the local IP address +CIFSR:APIP,"192.168.4.1" +CIFSR:APMAC,"a2:20:a6:19:c7:0a" AT+CIPMUX=1 //open multiple links Page 18 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... - Page 24 //Query the local IP address +CIFSR:STAIP,"192.168.4.2" +CIFSR:STAMAC,"5c:cf:7f:91:8b:3b" AT+CIPMUX=0 //open single link AT+CIPSTART="TCP","192.168.4.1",333 //Connect to TCP server CONNECT AT+CIPSEND=10 //send 10 bytes of data to the server side Page 19 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved...
-
Page 25: Udp Communication Test
//Query the local IP address +CIFSR:APIP,"192.168.4.1" +CIFSR:APMAC,"a2:20:a6:19:c7:0a" AT+CIPSTART="UDP","192.168.4.2",8002,8001,0 //Open UDP connection CONNECT +IPD,10:Ai-Thinker //received 10 data (Ai-Thinker) AT+CIPSEND=10 //send 10 bytes of data to the server Page 20 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... - Page 26 //After the emergence of the symbol serial port to send Ai-Thinker (without carriage return line) Recv 10 bytes //The serial port receives the data SEND OK Page 21 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved...
-
Page 27: Faq
Note: After the exchange, the download pin on the hardware is still the original U0TXD and U0RXD. 6.3 Can’t Burn Normally Refer to http://wiki.ai-thinker.com/esp_download to download, pay attention to download before the module to ensure that the download mode. Page 22 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... -
Page 28: Sdk Development Environment
GPIO0 GPIO2 GPIO15 Download Mode Run mode 7 Module Selection model ESP-01 ESP-01S ESP-01M ESP-07 ESP-07S ESP-12F ESP-12S Package DIP-8 DIP-8 SMD-18 SMD-16 SMD-16 SMD-22 SMD-16 Page 23 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved... - Page 29 FCC/CE FCC/CE FCC/CE Ceramic Antenna IPEX IPEX Indicator TXD0 GPIO2 GPIO2 GPIO2 GPIO2 GPIO2 light POWER POWER Available For more selection information please see http://wiki.ai-thinker.com/esp8266 contact us. Page 24 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved...
-
Page 30: Contact Us
Business cooperation: sales@aithinker.com Technical support: support@aithinker.com Telephone: 0755-29162996 Company Address: 6/F, Block C2, Huafeng Industrial Park, Hangcheng Road, Bao'an Road, Baoan District, Shenzhen ,China WeChat AiSmart APP Page 25 of Copyright © 2017 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved...
