SMART APP ONLINE
STEP-DOWN
TRANSFORMER
INSTALLATION AND OPERATION MANUAL
OL6KSTF | OL10KSTF
SAVE THESE INSTRUCTIONS
Please read this manual and follow the instructions for installation and operation.
©201 Cyber Power Systems, Inc. All rights reserve.
K01-0000755-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OL10KSTF and is the answer not in the manual?

Questions and answers

Summary of Contents for CyberPower OL10KSTF

  • Page 1 SMART APP ONLINE STEP-DOWN TRANSFORMER INSTALLATION AND OPERATION MANUAL OL6KSTF | OL10KSTF SAVE THESE INSTRUCTIONS Please read this manual and follow the instructions for installation and operation. ©201 Cyber Power Systems, Inc. All rights reserve. K01-0000755-01...
  • Page 2: Special Symbols

    This manual contains important instructions that should be followed during installation and maintenance of the STEP-DOWN TRANSFORMER The Smart App Online OL6KSTF and OL10KSTF step-down transformer models that are covered in this manual are intended for installation in an environment within 32°F to 104°F (0°C to 40°C), free of conductive contaminants.
  • Page 3 SAFETY INSTRUCTIONS CONT. PERSONAL SAFETY CAUTION The AC electrical service where the step-down transformer is connected should be close to the unit and easily accessible. Please use only UL-marked mains cable, (e.g. the mains cable of your equipment), to connect the step-down transformer to the AC outlet. Please use only UL-marked power cables to connect any equipment to the step-down transformer.
  • Page 4: Product Safety

    SAFETY INSTRUCTIONS CONT. PERSONAL SAFETY CONT. RISK OF ELECTRIC SHOCK CONT. The step-down transformer must be connected to a grounded AC power source with fuse or circuit breaker protection. DO NOT plug the step-down transformer into an unplug the unit. (No User Serviceable Parts): Risk of electric shock, do not remove cover.
  • Page 5: Table Of Contents

    TABLE OF CONTENTS SAFETY INSTRUCTIONS..........................II Special Symbols.................................... II Personal Safety.................................... III Product Safety .................................... INTRODUCTION..............................1 Unpacking Procedures................................1 Whats In The Box..................................2 OVERVIEW............................3 Step-Down Transformer................................HARDWARE INSTALLATION .......................... Rackmount Installation For 4-Post Rack ......................... Rackmount Installation For 2-Post Rack .........................
  • Page 6: Introduction

    INTRODUCTION The CyberPower Step-Down and Isolation Transformers support hardwire installations (OL6KSTF/ OL10K- STF) and are designed for a variety of CyberPower UPS systems. When connected to a UPS, the step-down transformer converts voltage from 200-240V down to 100-120V. UNPACKING PROCEDURES Information, advice, help The UPS system is very heavy, please handle with care.
  • Page 7: Whats In The Box

    INTRODUCTION CONT. WHATS IN THE BOX REGISTRATION QUICK START INSTALLATION AND OL6KSTF 6,000 VA/6,000 W STEP-DOWN AND ISOLATION TRANSFORMER OR CARD GUIDE OPERATION MANUAL OL10KSTF 10,000 VA/10,000 W STEP-DOWN AND ISOLATION TRANSFORMER 6 FT NEMA L6-30 LOCKING 3 FT 10/3 AWG CONDUCTOR TERMINAL LEFT &...
  • Page 8: Overview

    OVERVIEW STEP-DOWN TRANSFORMER FRONT: OL6KSTF/OL10KSTF BACK: OL6KSTF/OL10KSTF Input Circuit Breaker Provides input overload and fault protection. Input/Output Terminal Block Connect to input power source / output to equipment load. 6x NEMA 5-20R Outlets (120Vac) Output receptacles to connect equipment load.
  • Page 9: Hardware Installation

    HARDWARE INSTALLATION RACKMOUNT INSTALLATION FOR 4-POST RACK Caution: Important Instructions To prevent the risk of fire or electric shock, only use the supplied hardware to attach the mounting brackets. Step 1: Remove the dust covers Remove five dust covers from the screw holes as shown below. Step 2: Rackmount ear &...
  • Page 10 HARDWARE INSTALLATION CONT. RACKMOUNT INSTALLATION FOR 4-POST RACK: RACKMOUNT EARS INSTALLATION CONT. Rackmount ear Rackmount rail position 4 position 4 position 5 position 1 position 1 position 2 Step 5: Place and secure the step-down transformer on the rails Slide the hanging brackets on the step-down transformer on to the rails mounted in the rack with the front of the unit facing toward you.
  • Page 11: Rackmount Installation For 2-Post Rack

    HARDWARE INSTALLATION CONT. RACKMOUNT INSTALLATION FOR 2-POST RACK CAUTION! Due to the weight of this unit, it is strongly recommended to install it at the bottom of the rack. CAUTION! It is strongly recommended to have 2-3 people to assist during the installation process.
  • Page 12: Vertical/Tower Installation

    HARDWARE INSTALLATION CONT. VERTICAL/TOWER INSTALLATION Step 1: Adhere rubber pads Adhere the protective rubber pads to the left hand side of the step-down transformer. Step 2: Attach the base stands and attach the dust covers Stand the step-down transformer on its side with the rubber pads facing down. Install dust covers on open screw holes.
  • Page 13: Electrical Installation

    ELECTRICAL INSTALLATION Check wiring dimensions with the following table. STEP-DOWN AND ISOLATION TRANSFORMERS WIRING AWG WIRING mm WITH HARDWIRE INPUT TERMINAL BLOCK OL6KSTF 10 AWG 5.5 mm OL10KSTF 6 AWG 14.0 mm HARDWIRING THE INPUT/OUTPUT TERMINALS Step 1: Separate the terminal block cover Loosen the two screws joining the top and bottom terminal block covers to separate them.
  • Page 14 ELECTRICAL INSTALLATION CONT. Terminal Block Identification AC OUTPUT AC INPUT 208V 208V 240V 240V 120V 120V Terminal Block Configuration INPUT VOLTAGE AC OUTPUT CONNECTION OUTPUT VOLTAGE L1  N  L2 100 Vac  0  100 Vac L1  L2 = 200 Vac L1 ...
  • Page 15: Connecting A Step-Down Transformer To A Ups Power Module

    ELECTRICAL INSTALLATION CONT. CONNECTING A STEP-DOWN TRANSFORMER TO A UPS POWER MODULE The following illustrations provide the recommended connections between a step-down transformer and a CyberPower Smart App Online UPS System. OL6KRTF OL8KRTF/OL10KRTF OL6KRTMBTF OL8KRTMBTF/OL10KRTMBTF ©2019 Cyber Power Systems (USA), Inc. All rights reserved. All other trademarks are the property of their respective owners.
  • Page 16: Technical Specifications

    *200V are derated by 20%, 208 V are derated by 10% for OL10KSTF PRODUCT REGISTRATION CyberPower requests that you complete and return the Warranty Registration Card enclosed with the Product or register the Product at its website (www.cyberpowersystems.com/registration) to establish that you are the Initial Customer of the Product, and therefore entitled coverage under the Limited Warranty and the Connected Equipment Guarantee.
  • Page 17: Limited Warranty And Connected Equipment Guarantee

    LIMITED WARRANTY AND CONNECTED EQUIPMENT GUARANTEE Read the following terms and conditions carefully before using the CyberPower OL6KSTF/OL10KSTF. By using the Product you consent to be bound by and become a party to the terms and conditions of this Limited Warranty and Connected Equipment Guarantee (together referred to as this “Warranty”). If you do not agree to the terms and conditions of this Warranty, you should return the Product for a full refund prior to using it.
  • Page 18 If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required).
  • Page 19 1ms has occurred, the occurrence will be deemed outside the rated capabilities of the Product and the Limited Warranty is void. CyberPower Does Not Cover or Undertake Any Liability in Any Event for Any of the Following: Loss of or damage to data, records, or software or the restoration of data or records, or the reinstallation of software.
  • Page 20 (collectively, "High Risk Activities"). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High Risk Activities or with Aquariums. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF THE PRODUCT.
  • Page 21: Conformance Approval

    Cet appareil numerique de la class A respecte toutes les exigencies du Reglement sur le materiel brouilleur du Canada. This document is believed to be accurate, but CyberPower reserves the right to change or correct the contents and does not assume any responsibility for omissions or errors.
  • Page 22 Cyber Power Systems, Inc. | www.CyberPowerSystems.com For USA and Canada | 4241 12th Ave East, Suite 400, Shakopee, MN 55379 | Toll-free: 877.297.6937 For all other regions | Please visit our website for local contact information. Copyright ©2019 Cyber Power Systems, Inc. All rights reserved.
