- Page 1 ENGLISH MANUAL for devices of the MVP8 series Art.-No. 59504 | 59507 | 59604 | 59607...
- Page 2 MVP8-P3 DIO4 DIO4 8xM8-3 IOLB12 B0 59504 MVP8-P3 DIO4 DIO4 8xM8-3 IOLB12 E0 59604 Document status: Manual number 59507 Language Version Date 2021-09 Murrelektronik GmbH Falkenstraße 3 71570 Oppenweiler GERMANY Phone +49 7191 47-0 Fax +49 7191 47-491000 info@murrelektronik.com NOTE Translation of the original instructions...
-
Page 3: Table Of Contents
Mechanical data 4.2.6 Conformity, Approvals Art.-No. 59504 4.3.1 Electrical data 4.3.2 Environmental characteristics 4.3.3 Protection 4.3.4 Product reliability 4.3.5 Mechanical data 4.3.6 Conformity, Approvals ENGLISH MANUAL 3 / 51 for devices of the MVP8 series Art.-No. 59504 | 59507 | 59604 | 59607... - Page 4 Art.-No. 59604 Diagnostic 7.3.1 Vendor-specific IO-Link events Process data 7.4.1 Port-Based Bitmapping 7.4.2 Pin-Based Bitmapping Maintenance and cleaning Appendix Accessories Tools Legal notes ENGLISH MANUAL 4 / 51 for devices of the MVP8 series Art.-No. 59504 | 59507 | 59604 | 59607...
-
Page 5: Introduction
Please do not hesitate to call us at +49 (0) 7191 47-2050 or send an e-mail support@murrelektronik.com Service addresses Murrelektronik GmbH has a policy of customer proximity, both at national and international level. Please visit our website to find your contact person: https:/ /www.murrelektronik.com/... -
Page 6: Applicable Documents
Sort the separated components into the correct recycling line. persons! Disposal The product can be returned to Murrelektronik GmbH free of charge for dis- posal. The same is true for the original packaging and any batteries or power packs. Any units that have been contaminated with hazardous substances will not be accepted for repair or disposal. -
Page 7: About This Manual
Failure to observe the warning may cause damage to the device and/or the system. NOTE Other technical information and notes of Murrelektronik GmbH. RECOMMENDATION Notes with this symbol are recommendations of Murrelektronik GmbH. PRODUCTS AND ACCESSORIES This symbol indicates accessories or product recommendations. Instruction for use ... -
Page 8: Trademarks
Introduction 1.5.2 Trademarks Trademarks of the following companies and institutions are used in this docu- mentation: IO-Link c/o PROFIBUS Nutzerorganisation e.V. (PNO) 1.5.3 Specifications Specification Link IO-Link specification http://www.io-link.com Version 1.1.2 dated 07/2013 The features of the IO-Link Specification version 1.1.3 are supported as well. User manual 59507_hdb_en_12 8 / 51... -
Page 9: For Your Safety
Interventions in the hardware and software of the device dare, if they are not described in this document, only be carried out by qualified personnel from Murrelektronik GmbH. NOTE The operating instructions must always be available to the operator of the ma- chine where the device is used. -
Page 10: Description
Description Description Art.-No. 59507, 59607 IO-Link hub in 30 mm plastic housing 1 x M12 IO-Link class A 8 x M8 I/O 8 configurable digital inputs/outputs Art.-No. 59504, 59604 IO-Link hub in 30 mm plastic housing ... -
Page 11: Product Designation Code
Description Product Designation Code The product designation provides information on the module function. Art.-No. 59507 MVP8-P3 DIO8 8xM8-3 IOLA12 B0 MVP8-P3 Product family + module size D = Digital I = Input O = Output 8xM8-3 Number and size of ports + number of pins ... -
Page 12: Module Structure
Description Module structure Fig. 3-1: Module structure and port designations Art. No. Port designation Explanation 59507, 59607 X0 ... X7 Digital inputs and outputs US Module supply, IO-Link Class A 59504, 59604 X0 ... X3 Digital inputs and outputs UA X4 ... -
Page 13: Pin Assignment
Description PIN assignment 3.3.1 IO-Link Class A IO-Link XZ1 (M12 male connectors) Pin 1 24 V US (L+) Pin 2 n.c. Pin 3 0 V US (L-) Pin 4 C/Q IO-Link Pin 5 n.c. X0 ... X7 (M8 female connectors) Pin 1 24 V Pin 3... -
Page 14: Technical Data
Technical Data Technical Data Art.-No. 59507 4.1.1 Electrical data Module supply Operating voltage US 24 V Operating voltage range US 18 ... 30 V Total current US ≤50 °C (see Derating) ≤4 A Power consumption when idling ≤40 mA Galvanic isolation Total current US I [A] T [°C]... -
Page 15: Environmental Characteristics
Technical Data Input (DI) Cable length ≤30 m Input characteristic EN 61131-2 Type 1 + Type 3 Input filter 1 ms Output (DO) Connection/female connector Cable cross section ≤0.75 mm² Cable length ≤30 m Output current Per pin ≤0.5 A Switching frequency Resistive load ≤25 Hz... -
Page 16: Protection
Technical Data 4.1.3 Protection Device protection Overvoltage protection Overload protection of module supply To be ensured through load circuit monitoring Reverse polarity protection of module sup- Short-circuit protection, sensor supply Electronically Short-circuit protection, output (DO) Electronically Protective circuit for input Internal Suppressor diode 4.1.4... -
Page 17: Art.-No. 59607
Technical Data Art.-No. 59607 4.2.1 Electrical data Module supply Operating voltage US 24 V Operating voltage range US 18 ... 30 V Total current US ≤50 °C (see Derating) ≤4 A Power consumption when idling ≤40 mA Galvanic isolation Total current US I [A] T [°C] Fig. -
Page 18: Environmental Characteristics
Technical Data Output (DO) Connection/female connector Cable cross section ≤0.75 mm² Cable length ≤30 m Output current Per pin ≤0.5 A Switching frequency Resistive load ≤25 Hz 4.2.2 Environmental characteristics Climatic Operating temperature -25 °C ... +70 °C Storage temperature -40 °C ... -
Page 19: Product Reliability
Technical Data 4.2.4 Product reliability Product reliability MTTF SN 29500 (at 40 °C and rated data) 94 years 4.2.5 Mechanical data Assembly data Weight 129 g Dimensions L x W x H 126 x 30 x 34.5 mm 4.2.6 Conformity, Approvals Conformity, Approvals Product standard EN 61131-2... -
Page 20: Art.-No. 59504
Technical Data Art.-No. 59504 4.3.1 Electrical data Module supply Operating voltage US 24 V Operating voltage UA 24 V Operating voltage range US 18 ... 30 V Operating voltage range UA 18 ... 30 V Total current US ≤50 °C (see Derating) ≤4 A Total current UA ≤50 °C (see Derating) -
Page 21: Environmental Characteristics
Technical Data Input (DI) Cable length ≤30 m Input characteristic EN 61131-2 Type 1 + Type 3 Input filter 1 ms Output (DO) Connection/female connector Cable cross section ≤0.75 mm² Cable length ≤30 m Output current Per pin ≤2 A Switching frequency Resistive load ≤25 Hz... -
Page 22: Protection
Technical Data 4.3.3 Protection Device protection Overvoltage protection Overload protection of module supply To be ensured through load circuit monitoring Reverse polarity protection of module sup- Short-circuit protection, sensor supply Electronically Short-circuit protection, output (DO) Electronically Protective circuit for input Internal Suppressor diode 4.3.4... -
Page 23: Art.-No. 59604
Technical Data Art.-No. 59604 4.4.1 Electrical data Module supply Operating voltage US 24 V Operating voltage UA 24 V Operating voltage range US 18 ... 30 V Operating voltage range UA 18 ... 30 V Total current US ≤50 °C (see Derating) ≤4 A Total current UA ≤50 °C (see Derating) -
Page 24: Environmental Characteristics
Technical Data Input (DI) Cable length ≤30 m Input characteristic EN 61131-2 Type 1 + Type 3 Input filter 1 ... 10 ms, adjustable Output (DO) Connection/female connector Cable cross section ≤0.75 mm² Cable length ≤30 m Output current Per pin ≤2 A Switching frequency Resistive load... -
Page 25: Protection
Technical Data 4.4.3 Protection Device protection Overvoltage protection Overload protection of module supply To be ensured through load circuit monitoring Reverse polarity protection of module sup- Short-circuit protection, sensor supply Electronically Short-circuit protection, output (DO) Electronically Protective circuit for input Internal Suppressor diode 4.4.4... -
Page 26: Mounting
Mounting Mounting Requirements Conditions for mounting: Even mounting surface to avoid mechanical tension Provide suitable grounding Suitable installation site in terms of vibration and shock load, temperature and humidity (see chap. 4 "Technical Data" ) Protected to avoid tearing off the connecting cables by personnel or de- vice Dimensions... -
Page 27: Mounting Distance
Mounting Mounting distance Fig. 5-2: Distance between modules a | Male connector straight: 5 mm male connector angled: 50 mm NOTE If angled male connectors are used, a minimum distance of 50 mm must be adhered to. Mounting the module NOTICE Material damage due to incorrect installation The fastening screws and tightening torques depend on the surface of the in-... - Page 28 Mounting Module fastening Fig. 5-3: Mounting with two fastening screws M4 Distance between the fastening screws a = 75 mm Art.-No. 2 Nm 7000-98001-0000000 Mounting Align housing. Slightly tighten an M4 bolt. Slightly tighten the second M4 bolt. Tighten both screws M4 to the specified tightening torque. Fasten the grounding strap.
-
Page 29: Functional Ground
Mounting Functional ground Fig. 5-4: Ground strap fastening Art.-No. 2 Nm 7000-98001-0000000 User manual 59507_hdb_en_12 29 / 51... -
Page 30: Installation
Installation Installation WARNING! High electrical voltages Electric shock may cause life-threatening injuries. Only an electric installer is allowed to connect the device! Before performing work at the device, disconnect it from the voltage source. Observe five safety rules! Protective measures ... -
Page 31: Ensure Tight Seal
Seal unused male and female connectors. Fig. 6-1: Connecting cables Art.-No. 0.4 Nm 7000-99100-0000000 Art.-No. 0.6 Nm 7000-99102-0000000 PRODUCTS AND ACCESSORIES You will find a wide range of connecting lines in the catalog or in the Murrelek- tronik online shop http://shop.murrelektronik.com User manual 59507_hdb_en_12 31 / 51... -
Page 32: Operation
Operation Operation NOTE After writing an application-specific tag in the IO-Link hub, the hub briefly interrupts the IO-Link connection if the text is not the same as the text stored in the hub. LED indication The MVP8 modules are equipped with the following separate LED indicators: ... -
Page 33: Led Indication Ua
Operation Firmware update LED in- LED state Description dication Permanently on IO-Link in IDLE status, Firmware update completed success- Green fully Flashing IO-Link in status PREOPERATE/OP- ERATE, 1 Hz Green update is not yet performed Permanently on Update failed Flashing IO-Link in status PREOPERATE/OP- ERATE, 2 Hz... -
Page 34: Led Indication For Inputs And Outputs
0x0B DeviceID 1 (octet 0, 0x05 0x06 LSB) 0x0C FunctionID 1 (MSB) 0x0D FunctionID 2 (LSB) 0x0E Reserved 0x0F SystemCommand 0x0002 SystemCommand 0x0003 DataStorageIndex variable 0x000D ProfileCharacteristic R variable 0x000E PDInputDescriptor variable 0x000F PDOutputDescriptor R variable 0x0010 VendorName Murrelektronik GmbH User manual 59507_hdb_en_12 34 / 51... - Page 35 Operation ISDU Object name Access Length Meaning / default value index index in bytes 0x0011 VendorText www.murrelektronik.com. 0x0012 ProductName MVP8-P3 DIO8 8xM8-3 IO- MVP8-P3 DIO8 8xM8-3 IO- LA12 B0 LA12 E0 0x0013 ProductID 59507 59607 0x0014 ProductText Digital I/O hub...
-
Page 36: Art.-No. 59504, 59604
DataStorageIndex variable 0x000D ProfileCharacteristic R variable 0x000E PDInputDescriptor variable 0x000F PDOutputDescriptor R variable 0x0010 VendorName Murrelektronik GmbH 0x0011 VendorText www.murrelektronik.com. 0x0012 ProductName MVP8-P3 DIO4 DIO4 8xM8- MVP8-P3 DIO4 DIO4 8xM8- 3 IOLB12 B0 3 IOLB12 E0 0x0013 ProductID 59504 59604... - Page 37 Operation ISDU Object name Access Length Meaning / default value index index in bytes 0x0025 DetailedDeviceSta- variable 6 x (octet 1: EventQualifier, octet 2, 3: EventCode) 0x0028 ProcessDataInput length 0x0029 ProcessDataOutput R length 0x0031 Reserved for pro- files 0x003F User manual 59507_hdb_en_12 37 / 51...
-
Page 38: Isdu
Operation 7.2.2 ISDU 7.2.2.1 Art.-No. 59607 ISDU Object name Access Length Meaning Default index in Byte value 0x0040 Status: Power Supply Sta- Returns status of US tus US - 0x00 = OK - 0x01 = Undervoltage - 0x02 = Overvoltage 0x0041 Status: Power Supply Value Returns measured voltage of US in 0.1 V steps. -
Page 39: Art.-No. 59604
Operation ISDU Object name Access Length Meaning Default index in Byte value 0x0080 Inputs: Inverting Input Logic R/W Inversion of the input logic per channel. - Bit 0: X0 Pin 4 - Bit 1: X1 Pin 4 … - Bit 6: X6 Pin 4 - Bit 7: X7 Pin 4 Setting per channel (subindex): 0 = normal, no inversion... - Page 40 Operation ISDU Object name Access Length Meaning Default index in Byte value 0x0040 Status: Power Supply Sta- Returns status of US tus US - 0x00 = OK - 0x01 = Undervoltage - 0x02 = Overvoltage 0x0041 Status: Power Supply Value Returns measured voltage of US in 0.1 V steps.
- Page 41 Operation ISDU Object name Access Length Meaning Default index in Byte value 0x0072 In-/Outputs: Channel Con- Setting of the I / O function per channel. figuration - Subindex 1: X0 Pin 4 - Subindex 2: X1 Pin 4 - Subindex 7: X6 Pin 4 - Subindex 8: X7 Pin 4 Setting per channel (subindex): 0 = auto configuration / universal (DIO)
- Page 42 Operation ISDU Object name Access Length Meaning Default index in Byte value 0x0091 Outputs: Fail-Safe Behavior R/W Defines the behavior of each individual output (channel) in the event of a loss of communication with the master. - Subindex 1: X0 Pin 4 - Subindex 2: X1 Pin 4 - Subindex 7: X6 Pin 4 - Subindex 8: X7 Pin 4...
-
Page 43: Diagnostic
Operation Diagnostic 7.3.1 Vendor-specific IO-Link events In addition to the vendor-specific IO-Link events listed here, the standard events of the IO-Link specification also apply, version see chapter 1.5.3 "Specifications". Event Event type Description code 0x4000 Error The device shows a temperature fault - overload. 0x4210 Warning The device shows a temperature over-run. -
Page 44: Process Data
Operation Process data 7.4.1 Port-Based Bitmapping Byte 0 Inputs X0 ... X3 Input Process Data Contact Pin4_X0 Pin2_X0 Pin4_X1 Pin2_X1 Pin4_X2 Pin2_X2 Pin4_X3 Pin2_X3 Byte 1 Inputs X4 ... X7 Contact Pin4_X4 Pin2_X4 Pin4_X5 Pin2_X5 Pin4_X6 Pin2_X6 Pin4_X7 Pin2_X7 Byte 2 Diagnostic Description Error/Warning at power supply (too low or high) Error/Warning because of temperature rating... - Page 45 Operation Byte 3 Module Identification Description 0 ... 7 User defined module identification bits, e. g. for tool change applications; 0 = not used 1 ... 255 = ID value is read out from object Byte 0 Outputs X0 ... X3 Output Process Data Contact Pin4_X0...
-
Page 46: Pin-Based Bitmapping
Operation 7.4.2 Pin-Based Bitmapping Byte 0 Inputs X0 ... X7 Input Process Data Contact Pin4_X0 Pin4_X1 Pin4_X2 Pin4_X3 Pin4_X4 Pin4_X5 Pin4_X6 Pin4_X7 Byte 1 Inputs X0 ... X7 Contact Pin2_X0 Pin2_X1 Pin2_X2 Pin2_X3 Pin2_X4 Pin2_X5 Pin2_X6 Pin2_X7 Byte 2 Diagnostic Description Error/Warning at power supply (too low or high) Error/Warning because of temperature rating... - Page 47 Operation Byte 0 Outputs X0 ... X3 Output Process Data Contact Pin4_X0 Pin2_X0 Pin4_X1 Pin2_X1 Pin4_X2 Pin2_X2 Pin4_X3 Pin2_X3 Byte 1 Outputs X4 ... X7 Contact Pin4_X4 Pin2_X4 Pin4_X5 Pin2_X5 Pin4_X6 Pin2_X6 Pin4_X7 Pin2_X7 User manual 59507_hdb_en_12 47 / 51...
-
Page 48: Maintenance And Cleaning
Maintenance and cleaning Maintenance and cleaning NOTE Replace defective or damaged devices. Device cleaning: Use only oil-free compressed air or spirit Only use lint-free materials (e.g. leather cloth) Do not use contact spray User manual 59507_hdb_en_12 48 / 51... -
Page 49: Appendix
7000-98001-0000000 M8 torque wrench set, AF 10 7000-99100-0000000 M12 torque wrench set, AF 13 7000-99102-0000000 PRODUCTS AND ACCESSORIES You will find a wide range of products in our catalog or in our Murrelektronik online shop https://shop.murrelektronik.com User manual 59507_hdb_en_12 49 / 51... -
Page 50: Legal Notes
Murrelektronik GmbH if and the extent to which the documenta- tion is amended by the customer. The customers shall undertake to exempt Murrelektronik from claims for damages of third parties if the latter are attrib- utable to any defects in the documentation. This shall not apply to damage to the rights of third parties caused deliberately or by gross negligence. - Page 51 Murrelektronik GmbH | Falkenstraße 3 | 71570 Oppenweiler | GERMANY +49 7191 47-0 | +49 7191 47-491 000 | info@murrelektronik.com www.murrelektronik.com The information in the manual has been compiled with utmost care. Liability for the correctness, completeness and topicality of the information is restricted to gross negligence.
