Summarization of Contents
EQ Controls and Functions
Stereo vs. Mono Output EQ
Control EQ for stereo powered output (J2) and mono line level output (J12).
Bypass EQ Bands
Button to disable all EQ filter bands without resetting values for A/B testing.
Reset EQ Values
Button to reset all EQ values to their default settings.
EQ Filter Types
Peaking EQ Filter
Default EQ filter with adjustable center frequency, Q (bandwidth), and gain.
Notch EQ Filter
Removes a narrow bandwidth of frequency content to eliminate unwanted resonance.
High and Low Pass Filter Slopes and Q
Filter Slopes
Describes the steepness of HP/LP filters, measured in dB per octave.
Filter Q Value and Alignment
Q value determines filter alignment; inverse relationship with bandwidth.
