Congratulations on purchasing
your new Hunter® ceiling fan! It will
provide comfort and performance
in your home or office for many
years. This installation and operation
manual contains complete
instructions for installing and
operating your fan.
We are proud of our work and
appreciate the opportunity to
supply you with the best ceiling fan
available anywhere in the world.
To register your fan, please visit:
www.HunterFan.com/register
Save your receipt for proof of purchase.
What to Expect with
Your Installation
Tools Needed
30 inches
7 feet
2
Preparation
Downrod
6
Blades
Switch Housing
12
1
M0075-01 • 01/07/19 • © 2019 Hunter Fan Company
www.HunterFan.com
Mounting Options
Ladder
3
Wiring
7
Maintenance &
Cleaning
13
1.888.830.1326
Ceiling Bracket
4
5
Canopy
10
11
Troubleshooting
?
?
?
15
16
Advertisement
Table of Contents
Related Manuals for Hunter 53126
Summarization of Contents
What to Expect with Your Installation
Installation Requirements
Key requirements for fan installation, including structural support, wiring knowledge, and location assessment.
Downrod Selection Guide
Guidance on choosing the correct downrod length based on ceiling height and angle.
General Safety Warnings
Important safety precautions regarding electrical shock, fire, and personal injury during installation.
Tools Needed for Installation
Essential Tools
List of basic tools required for fan installation, including tools for cutting, stripping, and fastening.
Optional Tools
Optional tools that may be needed for specific mounting situations, such as drilling pilot holes.
Mounting Options and Ceiling Angle
Flat Ceiling Mounting
Instructions for hanging a fan on a flat ceiling using a standard downrod.
Angled Ceiling Mounting
Guidance for installing fans on angled ceilings, including downrod and kit requirements.
Ceiling Angle Determination
Method to determine ceiling angle and identify necessary mounting components based on angle.
Ceiling Bracket Installation
Bracket Attachment to Structure
Procedure for securing the ceiling bracket to a support structure using wood screws.
Bracket Attachment to Outlet Box
Procedure for attaching the ceiling bracket to an approved fan-rated outlet box using machine screws.
Angled Ceiling Orientation
Specific orientation for the ceiling bracket opening when installing on angled ceilings.
Preparation for Fan Installation
Shipping Block Removal
Instructions for removing shipping blocks from the motor and saving screws for blade installation.
Grommet Insertion Tip
Tip to involve a helper for inserting grommets into fan blades during preparation.
Downrod Options and Assembly
Downrod Type Selection
Overview of available downrod types: standard, shorter, and longer, based on ceiling height.
Downrod Replacement Steps
Detailed steps for disassembling the standard downrod pipe and reassembling with a new pipe.
Fan Fall Hazard Warning
Critical warning about fan fall hazards and the importance of correct downrod assembly and verification.
Downrod Securement
Setscrew Removal and Downrod Insertion
Procedure to remove the pre-installed setscrew to allow for proper downrod insertion.
Downrod Tightening
Instructions on how to hand-tighten the downrod and securely tighten the setscrew using pliers.
Wire Preparation
Guidance on cutting and stripping fan wires, ensuring sufficient length extends from the downrod.
Canopy and Ball Placement
Wire and Canopy Routing
Steps for routing wires and the downrod through the canopy, letting it sit loosely.
Downrod Ball to Bracket Seating
How to correctly place the downrod ball into the slot in the ceiling bracket.
Lifting Notice
Important notice on how to properly lift the fan assembly to prevent damage.
Wiring Connections
Ground Wire Connection
Procedure for connecting the grounding wires from the ceiling, downrod, and hanging bracket using wire connectors.
Power Wire Connection
Instructions for connecting the fan's power wires (black, blue, white) to the corresponding ceiling wires.
Wire Management in Outlet Box
How to tuck wired connections back into the outlet box and organize wires by grounding and ungrounded sides.
Wiring Safety Warning
Crucial warning regarding adherence to electrical codes and consulting an electrician if unsure about wiring.
Canopy Installation
Canopy Positioning and Alignment
Steps to position the canopy correctly and align its screw holes with the hanging bracket.
Securing the Canopy
How to insert and tighten the two canopy screws to secure the canopy to the hanging bracket.
Fan Style Note
A reminder that the fan style may differ from the illustration shown.
Blade Attachment to Fan
Grommet and Blade Iron Assembly
Instructions for inserting grommets into blades and securing each blade to a blade iron with screws.
Blade Iron to Motor Attachment
Steps for lightly attaching the blade irons to the motor, then securely tightening them.
Screw Reminder for Blades
Reminder to use screws saved from shipping blocks, plus additional screws from the hardware bag.
Switch Housing Installation (Part 1)
Initial Housing Screw Installation
Procedure for installing two housing assembly screws halfway into the motor housing.
Wire Plug and Housing Alignment
Steps to feed the wire plug through the housing and align keyhole slots with screws.
Final Screw Tightening for Housing
How to insert the final screw and tighten all three screws to secure the switch housing.
Switch Housing Securement Warning
Important warning about ensuring screws are tight to securely attach the upper switch housing to the mounting plate.
Switch Housing Installation (Part 2)
Connector Plug Alignment
Instructions for connecting the plugs from the upper and lower switch housings, aligning colored markings.
Lower Housing Attachment
How to lift the lower switch housing, align screw holes, and install three screws.
Pull Chain Pendant Attachment
Steps to attach the pull chain pendant to the short chain coming from the switch housing.
Light Fixture Securement Warning
Warning to ensure screws are tight for securing the light fixture to the fan.
Maintenance and Cleaning
Changing Airflow Direction
How to change the direction of airflow by moving the reverse switch to the opposite position.
Fan Cleaning Procedure
Guidance on cleaning the fan using soft materials to prevent scratching and damage to finishes.
Troubleshooting Fan Issues
Fan Not Working Solutions
Solutions for common problems such as the fan not turning on, including power, pull chain, and wiring checks.
Excessive Wobbling Solutions
Steps to address excessive fan wobbling, including tightening screws and using a balancing kit.
Noisy Operation Solutions
Methods to resolve noisy fan operation, such as tightening screws and checking for cracked blades.
