Colour Television
Contents
Published by CQZ/SC 1623 Quality
©
2016
TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page
Contents
2
11. Styling Sheets
2
6
10
10
11
11
12
12
13
13
34
37
46
57
58
Drawing PWB
59
63-64
65
69-70
71
73-74
75
79-80
81
85-86
87
91-92
93
97-98
99
104-105
106
130-131
132
156-157
158
159
160
161
162
163
164
165
166
167
168
169
170
172
173
175
176
178
179
183
Printed in the Netherlands
6801 series 43"
6801 series 49"
6801 series 55"
7101 series 55"
7101 series 65"
7601 series 65"
7101 series 75"
Subject to modification
Chassis
QM16.3A
LA
Page
184
185
186
187
188
189
190
EN 3122 785 20152
Advertisement
Table of Contents
Related Manuals for Philips 55PUT6801/98
Summarization of Contents
Revision List
Technical Specifications
Detailed technical specifications and online support links.
Directions for Use
Information on downloading user manuals from Philips support websites.
Connections Overview
Overview of rear and side connectors, with detailed pin configurations.
Chassis Overview
Reference to block diagrams for PWB/CBA locations.
Precautions, Notes, and Abbreviation List
Safety Instructions
Safety regulations for repairs, including isolation transformers and component substitution.
Warnings
Warnings regarding electrostatic discharge (ESD) and high voltage measurements.
General Notes
Notes on measuring voltages and waveforms, and general service precautions.
Schematic Notes
Notes on resistor and capacitor value notations, and usage of asterisk symbols.
Spare Parts
Guidance on consulting the Philips Spare Part web portal for part overviews.
BGA (Ball Grid Array) ICs
Information on handling BGA devices and temperature profiles.
Lead-free Soldering
Rules for lead-free soldering, including tools and temperature settings.
Alternative BOM Identification
Explanation of identifying alternative BOMs using serial numbers and design variants.
Board Level Repair (BLR) or Component Level Repair (CLR)
Decision criteria for board exchange versus component-level repair.
Practical Service Precautions
General precautions for service, including avoiding electrical shock and proper wiring.
Abbreviation List
List of abbreviations used in the manual, with their meanings.
Mechanical Instructions
Cable Dressing
Figures showing cable routing for specific model series (43" 6801 series).
Service Positions
Guidelines for placing the TV for servicing to prevent display damage.
Assembly/Panel Removal (for 7101 series)
Instructions for stand removal on 7101 series models.
Stand
Steps to remove the stand bracket and the bracket itself.
Rear Cover
Procedure for removing the rear cover, including safety warning and connector unplugging.
AmbiLight Panel
Steps to release clamps, unplug connectors, and lift the Ambilight panel.
Keyboard Control Unit
Steps to release connectors, remove screws, and take out the keyboard control panel.
Small Signal Board (SSB)
Procedure for releasing LVDS and other connectors, removing fixation screws, and taking out the SSB.
IR/LED Board
Steps to remove fixation screw, pull out the assembly, and unplug the connector.
Power Supply Unit (PSU)
Procedure for unplugging connectors, removing fixation screws, and taking out the PSU.
Speakers
Steps to release tapes, unplug speaker connector, and take out speakers.
WIFI module
Steps to unplug connector, remove fixation screw, and remove the module.
LED Logo Board
Steps to remove fixation screws, pull out assembly, and unplug connector from LED Logo board.
LCD Panel
Steps to remove SSB, PSU, keyboard control, stand bracket, IR/LED, WIFI module, clamps and other parts.
Assembly/Panel Removal (for 6801 series)
Instructions for stand removal on 6801 series models.
Stand
Steps to remove fixation screws that secure the stand bracket and take it out.
Rear Cover
Procedure for removing the rear cover, including safety warning and connector unplugging.
Keyboard Control Unit
Steps to release connector from SSB, remove fixation screws and take out the keyboard panel.
Small Signal Board (SSB)
Steps to release LVDS and other connectors, remove fixation screws and take out the SSB.
IR/LED Board
Steps to remove fixation screws, pull out assembly, and unplug connector from IR/LED board.
Power Supply Unit (PSU)
Procedure for unplugging connectors, removing fixation screws, and taking out the PSU.
Speakers
Steps to release tapes, unplug speaker connector, and take out speakers.
WIFI module
Steps to unplug connector, remove fixation screw, and remove the module.
LCD Panel
Steps to remove SSB, PSU, keyboard control, stand bracket, IR/LED, WIFI module, clamps and other parts.
Assembly/Panel Removal (for 7601 series)
Instructions for stand removal on 7601 series models.
Stand
Steps to remove fixation screws and take out the stand bracket.
Rear Cover
Procedure for removing the rear cover, including safety warning and connector unplugging.
AmbiLight Panel
Steps to release clamps, unplug connectors, and lift the Ambilight panel.
Keyboard Control Unit
Steps to release connectors, remove fixation screws, and take out the keyboard control panel.
Small Signal Board (SSB)
Steps to release LVDS and other connectors, remove fixation screws and take out the SSB.
IR/LED Board
Steps to remove fixation screws, pull out assembly, and unplug connector from IR/LED board.
Power Supply Unit (PSU)
Procedure for unplugging connectors, removing fixation screws, and taking out the PSU.
Speakers
Steps to release tapes, unplug speaker connector, and take out speakers.
WIFI module
Steps to unplug connector, remove fixation screw, and remove the module.
LED Logo Board
Steps to remove fixation screws, pull out assembly, and unplug connector from LED Logo board.
LCD Panel
Steps to remove SSB, PSU, keyboard control, stand bracket, IR/LED, WIFI module, clamps and other parts.
Set Re-assembly
Instructions to reassemble the set by reversing the disassembly process.
Service Modes, Error Codes, and Fault Finding
Service Modes
Introduction to service modes like SAM, Factory Mode, and CSM.
General
General information applicable to all service modes, including life timers and software identification.
Service Alignment Mode (SAM)
Purpose and specifications of SAM mode, including how to activate it.
How to Navigate SAM Menu
Instructions on navigating menus and changing values using the remote control.
How to Store SAM Settings
How to store changed settings in SAM mode, except for RGB Align settings.
How to Exit SAM
Methods to exit SAM mode, including switching to standby.
Factory Mode
Purpose and specifications of Factory mode, including how to activate it.
How to Exit Factory Mode
Methods to exit Factory mode, including using the OK button or standby.
Customer Service Mode (CSM)
Purpose and specifications of CSM mode, including how to activate it.
How to Navigate CSM
Instructions on navigating CSM menus and using channel up/down for surfing.
How to Exit CSM
Methods to exit CSM mode, including using MENU/HOME or POWER buttons.
Contents of CSM
Details on Set Type, Production Code, Option Codes, and software versions available in CSM.
Stepwise Start-up
Diagram illustrating the TV's power-on sequence and state transitions.
Service Tools
Information about the ComPair Tool and its current support status.
Software Upgrading
Description and introduction to upgrading TV software via USB port.
Check the current TV software version
Procedure to check the current TV software version before upgrading.
Download the latest software
Steps to download the latest software update file from the Philips support website.
Update the TV software
Detailed steps for updating the TV software using a USB memory stick.
Content and Usage of the One-Zip Software File
Explanation of the contents of the One-Zip software file and instructions for use.
How to Copy NVM Data to/from USB
Instructions on copying NVM data to and from a USB memory stick using the "repair" folder.
Error Codes
Introduction to error codes and their availability for failures and I2C devices.
Introduction to Error Codes
Explanation of what error codes indicate, the error buffer, and how failures are displayed.
How to Read the Error Buffer
Methods for reading the error buffer, including via SAM/CSM or blinking LED.
Error Codes Table
Table listing defined layer 2 error codes and their corresponding defective devices.
How to Clear the Error Buffer
Cases for clearing the error buffer, including SAM/Factory mode and automatic reset.
The Blinking LED Procedure
Introduction to displaying errors via blinking LED procedure when OSD is not working.
Introduction to LED Blinking Procedure
Explanation of how errors are displayed by blinking the front LED with pulses.
How to Activate Blinking LED Procedure
Methods to activate the blinking LED procedure, including activating CSM.
Fault Finding and Repair Tips
General tips for fault finding, including checking NVM settings and component mounting.
NVM Editor
Information on changing NVM contents directly using the "NVM Editor" in SAM mode.
CSM Functionality
How CSM activation with USB stick collects CSM content into Csm.xml file.
Troubleshooting No Picture
Troubleshooting steps for no picture issues, including checking display code.
Guidelines for Uart Logging
Possible cases indicated by UART loggings, including I2C errors and wrong option codes.
Unstable Picture via HDMI Input
Checking HDMI EDID data for unstable picture issues.
Troubleshooting TV Will Not Start-up from Stand-by
Troubleshooting steps for TV not starting up from standby, including re-flashing software.
Handling Audio Amplifier
Handling of Class D IC U606, ensuring proper powerpad contact with PWB.
Loudspeaker Handling Precautions
Precaution for disconnecting speakers in ON-state to avoid amplifier damage.
Display Option Code Setting
Importance of checking Panel Code in CSM after SSB replacement, even if picture is available.
Alignments
General Alignment Conditions
General conditions for performing electrical adjustments, including power supply and warm-up time.
Hardware Alignments
Not applicable section.
Software Alignments
Procedures for software alignments, including white point adjustment.
RGB Alignment
Steps for RGB alignment, including setting picture parameters and white tone values.
Display Adjustment
Procedure for display adjustment using default values for color temperature and RGB settings.
Option Settings
Introduction to option settings and how the microprocessor communicates with I2C ICs.
Option Code Overview
How to check and edit option codes in SAM mode.
Display Code Overview
Procedure to access and reset the Display Code using key sequences.
Reset of Repaired SSB
Importance of resetting NVM on repaired SSB and setting type/production codes.
Instruction for Resetting Repaired SSB
Instruction for reloading MAC address via SAM menu after NVM replacement.
SSB Identification
How SSB's are identified by a "715" code and its sub-categories.
Cable Position Numbers
Rule for defining cable position numbers, always starting with "E" followed by connector number.
Circuit Descriptions
Introduction to Circuit Descriptions
Introduction to the QM16.3A LA chassis and its key features compared to its predecessor.
Implementation Details
List of key components used in the QM16.3A LA chassis.
QM16.3A LA Architecture Overview
Reference to block diagrams for chassis architecture overview.
SSB Cell Layout
Top view PWB layout for the SSB (for 71x1 series).
IC Data Sheets
SOC-EMMC Block Diagram
Internal block diagram of the SOC-EMMC, B01, MT5593UGIJ (IC U9400).
MT5593UGIJ Pinning Information
Internal pin configuration of the MT5593UGIJ IC.
BE-NT324a-Vx1-INPUT Block Diagram
Internal block diagram and pin configuration of the BE-NT324a-Vx1-INPUT, B06, NT72324BG (IC U3100).
FE-TUNER-DEMOD-TPV Block Diagram
Internal block diagram and pin configuration of the FE-TUNER-DEMOD-TPV, B05, SI2169-C50 (IC U201).
DCDC-SYSTEM-POWER2 (AOZ1360DIL) Block Diagram
Internal block diagram and pin configuration of the DCDC-SYSTEM-POWER2, B15, AOZ1360DIL (IC U4405).
DCDC-SYSTEM-POWER2 (MP8124GD) Block Diagram
Internal block diagram and pin configuration of the DCDC-SYSTEM-POWER2, B15, MP8124GD (IC U751).
BE-NT324a-Vx1-INPUT Block Diagram
Internal block diagram and pin configuration of the BE-NT324a-Vx1-INPUT, B06, NT72324BG (IC U3100).
DCDC-Novatek-POWER (G5318RE1D) Block Diagram
Internal block diagram and pin configuration of the DCDC-Novatek-POWER, B12, G5318RE1D (IC U4103).
AUDIO-1st-CLASS-D-AMP (TAS5760LDDCAR) Block Diagram
Internal block diagram and pin configuration of the AUDIO-1st-CLASS-D-AMP, B16, TAS5760LDDCAR (IC U5100).
BE-NT72333a-Vx1-INPUT Block Diagram
Internal block diagram and pin configuration of the BE-NT72333a-Vx1-INPUT, B06, NT72333TBG/C (IC U3100).
DCDC-SYSTEM-POWER1 (G5318RE1D) Block Diagram
Internal block diagram and pin configuration of the DCDC-SYSTEM-POWER1, B14, G5318RE1D (IC U4306).
Block Diagrams
Block Diagram 7101/7601 Series
Block diagram of the 7101/7601 series, showing connections between major modules.
Block Diagram 6801 Series
Block diagram of the 6801 series, showing connections between major modules.
Circuit Diagrams and PWB Layouts
A 715G7831 PSU - AC Input
Circuit diagram for the AC input section of the A 715G7831 PSU.
A 715G7831 PSU - PFC with LD7591T
Circuit diagram for the PFC section with LD7591T for the A 715G7831 PSU.
A 715G7831 PSU - Flyback with SSC3S121
Circuit diagram for the Flyback section with SSC3S121 for the A 715G7831 PSU.
A 715G7831 PSU - LLC with TPV101
Circuit diagram for the LLC with TPV101 for the A 715G7831 PSU.
A 715G7831 PSU - Power Layout Top
Top view PWB layout for the A 715G7831 PSU.
A 715G7831 PSU - Power Layout Bottom
Bottom view PWB layout for the A 715G7831 PSU.
A 715G7732 PSU - AC Input
Circuit diagram for the AC input section of the A 715G7732 PSU.
A 715G7732 PSU - PFC with TI
Circuit diagram for the PFC section with TI for the A 715G7732 PSU.
A 715G7732 PSU - Flyback with Sanken QR
Circuit diagram for the Flyback section with Sanken QR for the A 715G7732 PSU.
A 715G7732 PSU - LLC with Sanken
Circuit diagram for the LLC with Sanken for the A 715G7732 PSU.
A 715G7732 PSU - Power Layout Top
Top view PWB layout for the A 715G7732 PSU.
A 715G7732 PSU - Power Layout Bottom
Bottom view PWB layout for the A 715G7732 PSU.
A 715G7854 PSU - LED OZ9908A
Circuit diagram for the LED OZ9908A section of the A 715G7854 PSU.
A 715G7854 PSU - Jumper Configurations
Diagram showing various jumper configurations and their descriptions.
A 715G7854 PSU - Power Layout Top
Top view PWB layout for the A 715G7854 PSU.
A 715G7854 PSU - Power Layout Bottom
Bottom view PWB layout for the A 715G7854 PSU.
A 715G6679 PSU - AC Input
Circuit diagram for the AC input section of the A 715G6679 PSU.
A 715G6679 PSU - PFC
Circuit diagram for the PFC section of the A 715G6679 PSU.
A 715G6679 PSU - Main Power
Circuit diagram for the main power section of the A 715G6679 PSU.
A 715G6679 PSU - LED Driver
Circuit diagram for the LED driver section of the A 715G6679 PSU.
A 715G6679 PSU - Power Layout Top
Top view PWB layout for the A 715G6679 PSU.
A 715G6679 PSU - Power Layout Bottom
Bottom view PWB layout for the A 715G6679 PSU.
A 715G6677 PSU - AC Input
Circuit diagram for the AC input section of the A 715G6677 PSU.
A 715G6677 PSU - PFC
Circuit diagram for the PFC section of the A 715G6677 PSU.
A 715G6677 PSU - Standby
Circuit diagram for the standby power supply section of the A 715G6677 PSU.
A 715G6677 PSU - LED Driver
Circuit diagram for the LED driver section of the A 715G6677 PSU.
A 715G6677 PSU - Power Layout Top
Top view PWB layout for the A 715G6677 PSU.
A 715G6677 PSU - Power Layout Bottom
Bottom view PWB layout for the A 715G6677 PSU.
A 715G6973 PSU - AC Input
Circuit diagram for the AC input section of the A 715G6973 PSU.
A 715G6973 PSU - PFC
Circuit diagram for the PFC section of the A 715G6973 PSU.
A 715G6973 PSU - Main Power
Circuit diagram for the main power section of the A 715G6973 PSU.
A 715G6973 PSU - LED Driver
Circuit diagram for the LED driver section of the A 715G6973 PSU.
A 715G6973 PSU - Power Layout Top
Top view PWB layout for the A 715G6973 PSU.
A 715G6973 PSU - Power Layout Bottom
Bottom view PWB layout for the A 715G6973 PSU.
A 715G7720 PSU - AC Input
Circuit diagram for the AC input section of the A 715G7720 PSU.
A 715G7720 PSU - PFC
Circuit diagram for the PFC section of the A 715G7720 PSU.
A 715G7720 PSU - Main Power
Circuit diagram for the main power section of the A 715G7720 PSU.
A 715G7720 PSU - LED Driver
Circuit diagram for the LED driver section of the A 715G7720 PSU.
A 715G7720 PSU - Power Layout Top
Top view PWB layout for the A 715G7720 PSU.
A 715G7720 PSU - Power Layout Bottom
Bottom view PWB layout for the A 715G7720 PSU.
A 715G8063 PSU - LED DRIVER 1-16
Circuit diagram for the LED DRIVER 1-16 section of the A 715G8063 PSU.
A 715G8063 PSU - LED DRIVER 49-64
Circuit diagram for the LED DRIVER 49-64 section of the A 715G8063 PSU.
A 715G8063 PSU - LED DRIVER 33-48
Circuit diagram for the LED DRIVER 33-48 section of the A 715G8063 PSU.
A 715G8063 PSU - LED DRIVER 49-64
Circuit diagram for the LED DRIVER 49-64 section of the A 715G8063 PSU.
A 715G8063 PSU - LED DRIVER 65-72
Circuit diagram for the LED DRIVER 65-72 section of the A 715G8063 PSU.
A 715G8063 PSU - Power Layout Top
Top view PWB layout for the A 715G8063 PSU.
A 715G8063 PSU - Power Layout Bottom
Bottom view PWB layout for the A 715G8063 PSU.
B 715G7772 SSB - SOC-EMMC
Circuit diagram for the SOC-EMMC section of the B 715G7772 SSB.
B 715G7772 SSB - SOC-DDR3-1-2
Circuit diagram for the SOC-DDR3-1-2 section of the B 715G7772 SSB.
B 715G7772 SSB - SOC-DDR3-3-4
Circuit diagram for the SOC-DDR3-3-4 section of the B 715G7772 SSB.
B 715G7772 SSB - SOC-DDR3-5
Circuit diagram for the SOC-DDR3-5 section of the B 715G7772 SSB.
B 715G7772 SSB - FE-TUNER-DEMOD-TPV
Circuit diagram for the FE-TUNER-DEMOD-TPV section of the B 715G7772 SSB.
B 715G7772 SSB - BE-NT324a-Vx1-INPUT
Circuit diagram for the BE-NT324a-Vx1-INPUT section of the B 715G7772 SSB.
B 715G7772 SSB - BE-NT72333b-GPIO
Circuit diagram for the BE-NT72333b-GPIO section of the B 715G7772 SSB.
B 715G7772 SSB - BE-NT72333c-TX-VB1
Circuit diagram for the BE-NT72333c-TX-VB1 section of the B 715G7772 SSB.
B 715G7772 SSB - BE-NT72333d-POWER
Circuit diagram for the BE-NT72333d-POWER section of the B 715G7772 SSB.
B 715G7772 SSB - BE-NT72333e-DDR
Circuit diagram for the BE-NT72333e-DDR section of the B 715G7772 SSB.
B 715G7772 SSB - BE-NT72333f-GND
Circuit diagram for the BE-NT72333f-GND section of the B 715G7772 SSB.
DCDC-SYSTEM-POWER1 - DCDC-SOC-VCCK-DVSS
Circuit diagram for the DCDC-SOC-VCCK-DVSS section.
DCDC-SYSTEM-POWER1 - DCDC-SYSTEM-POWER1
Circuit diagram for the DCDC-SYSTEM-POWER1 section.
DCDC-SYSTEM-POWER2 - DCDC-SYSTEM-POWER2
Circuit diagram for the DCDC-SYSTEM-POWER2 section.
DCDC-SYSTEM-POWER2 - AUDIO-1st-CLASS-D-AMP
Circuit diagram for the AUDIO-1st-CLASS-D-AMP section.
DCDC-SYSTEM-POWER2 - AUDIO-2nd-CLASS-D-AMP
Circuit diagram for the AUDIO-2nd-CLASS-D-AMP section.
DCDC-SYSTEM-POWER2 - BE-NT72333f-GND
Circuit diagram for the BE-NT72333f-GND section.
DCDC-SYSTEM-POWER2 - BE-NT72333a-Vx1-INPUT
Circuit diagram for the BE-NT72333a-Vx1-INPUT section.
DCDC-SYSTEM-POWER2 - HDMI-SOC-ARC
Circuit diagram for the HDMI-SOC-ARC section.
DCDC-SYSTEM-POWER2 - SCART-YPbPr-CVBS
Circuit diagram for the SCART-YPbPr-CVBS section.
DCDC-SYSTEM-POWER2 - CTRL-CONNECTORS
Circuit diagram showing various connectors like IR receiver, debug, and control signals.
DCDC-SYSTEM-POWER2 - CTRL-ETHERNET-PHY
Circuit diagram for the Ethernet PHY control, Wi-Fi, and Bluetooth sections.
DCDC-SYSTEM-POWER2 - HTV
Circuit diagrams for Ballroom SPK, IR IN/OUT, and 12V output current protection.
DCDC-SYSTEM-POWER2 - SSB Layout Top
Top view PWB layout for the SSB.
DCDC-SYSTEM-POWER2 - SSB Layout Bottom
Bottom view PWB layout for the SSB.
J 715G7778 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for LED, IR, 3D, and Light sensor components.
J 715G8045 IR/LED Panel - IR & 3D & Light sensor & LOGO
Circuit diagrams for IR receiver, 3D & Light sensor, and LOGO components.
J 715G8045 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for IR receiver, LED, and Light sensor components.
J 715G8045 IR/LED Panel - IR/LED Board Layout
Layout diagrams for the IR/LED board (top and bottom sides).
E 715G7065 Keyboard control panel - Key+AL
Circuit diagrams for Key and AL (Ambilight) sections.
E 715G7065 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
E 715G7088 Keyboard control panel - Key
Circuit diagram for the Key section of the control panel.
E 715G7088 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
AL 715G7789 LED board - LOGO
Circuit diagram for the LOGO section of the LED board.
AL 715G7789 LED board - LED board layout top/bottom
Layout diagrams for the LED board (top and bottom sides).
AL 715G7004 Ambilight Board - TCL5971
Circuit diagram for the TLC5971 section of the Ambilight board.
AL 715G7004 Ambilight Board - Ambilight 9-LED
Circuit diagram for the Ambilight 9-LED section.
AL 715G7004 Ambilight Board - Ambilight board layout top/bottom
Layout diagrams for the Ambilight board (top and bottom sides).
AL 715G7006 Ambilight Board - Key
Circuit diagram for the Key section of the Ambilight board.
AL 715G7006 Ambilight Board - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
AL 715G7006 Ambilight Board - Ambilight 7-LED
Circuit diagram for the Ambilight 7-LED section.
AL 715G7006 Ambilight Board - LED DRIVER 49-64
Circuit diagram for the LED DRIVER 49-64 section.
AL 715G7006 Ambilight Board - HDMI Inputs
Circuit diagrams for HDMI inputs, including ESD protection.
BE-NT72333c-TX-VB1
Circuit diagram for the BE-NT72333c-TX-VB1 section.
BE-NT72333c-TX-VB1 - SCART-YPbPr-CVBS
Circuit diagram for the SCART-YPbPr-CVBS section.
BE-NT72333c-TX-VB1 - CTRL-CONNECTORS
Circuit diagram showing various connectors like IR receiver, debug, and control signals.
BE-NT72333c-TX-VB1 - CTRL-ETHERNET-PHY
Circuit diagram for the Ethernet PHY control, Wi-Fi, and Bluetooth sections.
BE-NT72333c-TX-VB1 - HTV
Circuit diagrams for Ballroom SPK, IR IN/OUT, and 12V output current protection.
BE-NT72333c-TX-VB1 - SSB Layout Top
Top view PWB layout for the SSB.
BE-NT72333c-TX-VB1 - SSB Layout Bottom
Bottom view PWB layout for the SSB.
J 715G7778 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for LED, IR, 3D, and Light sensor components.
J 715G8045 IR/LED Panel - IR & 3D & Light sensor & LOGO
Circuit diagrams for IR receiver, 3D & Light sensor, and LOGO components.
J 715G8045 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for IR receiver, LED, and Light sensor components.
E 715G7065 Keyboard control panel - Key+AL
Circuit diagrams for Key and AL (Ambilight) sections.
E 715G7065 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
E 715G7088 Keyboard control panel - Key
Circuit diagram for the Key section of the control panel.
E 715G7088 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
AL 715G7789 LED board - LOGO
Circuit diagram for the LOGO section of the LED board.
AL 715G7789 LED board - LED board layout top/bottom
Layout diagrams for the LED board (top and bottom sides).
AL 715G7004 Ambilight Board - TCL5971
Circuit diagram for the TLC5971 section of the Ambilight board.
AL 715G7004 Ambilight Board - Ambilight 9-LED
Circuit diagram for the Ambilight 9-LED section.
AL 715G7004 Ambilight Board - Ambilight board layout top/bottom
Layout diagrams for the Ambilight board (top and bottom sides).
AL 715G7007 Ambilight Board - TCL5971
Circuit diagram for the TLC5971 section of the Ambilight board.
AL 715G7007 Ambilight Board - Ambilight 6-LED
Circuit diagram for the Ambilight 6-LED section.
AL 715G7007 Ambilight Board - Ambilight 7-LED
Circuit diagram for the Ambilight 7-LED section.
AL 715G7007 Ambilight Board - Ambilight 9-LED
Circuit diagram for the Ambilight 9-LED section.
AL 715G7007 Ambilight Board - Ambilight board layout top/bottom
Layout diagrams for the Ambilight board (top and bottom sides).
BE-NT72333d-POWER
Circuit diagram for the BE-NT72333d-POWER section.
BE-NT72333e-DDR
Circuit diagram for the BE-NT72333e-DDR section.
BE-NT72333f-GND
Circuit diagram for the BE-NT72333f-GND section.
DCDC-SYSTEM-POWER1 - DCDC-SOC-VCCK-DVSS
Circuit diagram for the DCDC-SOC-VCCK-DVSS section.
DCDC-SYSTEM-POWER1 - DCDC-SYSTEM-POWER1
Circuit diagram for the DCDC-SYSTEM-POWER1 section.
DCDC-SYSTEM-POWER2 - DCDC-SYSTEM-POWER2
Circuit diagram for the DCDC-SYSTEM-POWER2 section.
DCDC-SYSTEM-POWER2 - AUDIO-1st-CLASS-D-AMP
Circuit diagram for the AUDIO-1st-CLASS-D-AMP section.
DCDC-SYSTEM-POWER2 - AUDIO-2nd-CLASS-D-AMP
Circuit diagram for the AUDIO-2nd-CLASS-D-AMP section.
DCDC-SYSTEM-POWER2 - BE-NT72333f-GND
Circuit diagram for the BE-NT72333f-GND section.
DCDC-SYSTEM-POWER2 - BE-NT72333a-Vx1-INPUT
Circuit diagram for the BE-NT72333a-Vx1-INPUT section.
DCDC-SYSTEM-POWER2 - HDMI-SOC-ARC
Circuit diagram for the HDMI-SOC-ARC section.
DCDC-SYSTEM-POWER2 - SCART-YPbPr-CVBS
Circuit diagram for the SCART-YPbPr-CVBS section.
DCDC-SYSTEM-POWER2 - CTRL-CONNECTORS
Circuit diagram showing various connectors like IR receiver, debug, and control signals.
DCDC-SYSTEM-POWER2 - CTRL-ETHERNET-PHY
Circuit diagram for the Ethernet PHY control, Wi-Fi, and Bluetooth sections.
DCDC-SYSTEM-POWER2 - HTV
Circuit diagrams for Ballroom SPK, IR IN/OUT, and 12V output current protection.
DCDC-SYSTEM-POWER2 - SSB Layout Top
Top view PWB layout for the SSB.
DCDC-SYSTEM-POWER2 - SSB Layout Bottom
Bottom view PWB layout for the SSB.
B 715G7772 SSB - SOC-EMMC
Circuit diagram for the SOC-EMMC section of the B 715G7772 SSB.
B 715G7772 SSB - SOC-DDR3-1-2
Circuit diagram for the SOC-DDR3-1-2 section of the B 715G7772 SSB.
B 715G7772 SSB - SOC-DDR3-3-4
Circuit diagram for the SOC-DDR3-3-4 section of the B 715G7772 SSB.
B 715G7772 SSB - SOC-DDR3-5
Circuit diagram for the SOC-DDR3-5 section of the B 715G7772 SSB.
B 715G7772 SSB - FE-TUNER-DEMOD-TPV
Circuit diagram for the FE-TUNER-DEMOD-TPV section of the B 715G7772 SSB.
B 715G7772 SSB - BE-NT324a-Vx1-INPUT
Circuit diagram for the BE-NT324a-Vx1-INPUT section of the B 715G7772 SSB.
B 715G7772 SSB - BE-NT72333b-GPIO
Circuit diagram for the BE-NT72333b-GPIO section of the B 715G7772 SSB.
B 715G7772 SSB - BE-NT72333c-TX-VB1
Circuit diagram for the BE-NT72333c-TX-VB1 section of the B 715G7772 SSB.
BE-NT72333d-POWER
Circuit diagram for the BE-NT72333d-POWER section.
BE-NT72333e-DDR
Circuit diagram for the BE-NT72333e-DDR section.
BE-NT72333f-GND
Circuit diagram for the BE-NT72333f-GND section.
DCDC-SYSTEM-POWER1 - DCDC-SOC-VCCK-DVSS
Circuit diagram for the DCDC-SOC-VCCK-DVSS section.
DCDC-SYSTEM-POWER1 - DCDC-SYSTEM-POWER1
Circuit diagram for the DCDC-SYSTEM-POWER1 section.
DCDC-SYSTEM-POWER2 - DCDC-SYSTEM-POWER2
Circuit diagram for the DCDC-SYSTEM-POWER2 section.
DCDC-SYSTEM-POWER2 - AUDIO-1st-CLASS-D-AMP
Circuit diagram for the AUDIO-1st-CLASS-D-AMP section.
DCDC-SYSTEM-POWER2 - AUDIO-2nd-CLASS-D-AMP
Circuit diagram for the AUDIO-2nd-CLASS-D-AMP section.
DCDC-SYSTEM-POWER2 - BE-NT72333f-GND
Circuit diagram for the BE-NT72333f-GND section.
DCDC-SYSTEM-POWER2 - BE-NT72333a-Vx1-INPUT
Circuit diagram for the BE-NT72333a-Vx1-INPUT section.
DCDC-SYSTEM-POWER2 - HDMI-SOC-ARC
Circuit diagram for the HDMI-SOC-ARC section.
DCDC-SYSTEM-POWER2 - SCART-YPbPr-CVBS
Circuit diagram for the SCART-YPbPr-CVBS section.
DCDC-SYSTEM-POWER2 - CTRL-CONNECTORS
Circuit diagram showing various connectors like IR receiver, debug, and control signals.
DCDC-SYSTEM-POWER2 - CTRL-ETHERNET-PHY
Circuit diagram for the Ethernet PHY control, Wi-Fi, and Bluetooth sections.
DCDC-SYSTEM-POWER2 - HTV
Circuit diagrams for Ballroom SPK, IR IN/OUT, and 12V output current protection.
DCDC-SYSTEM-POWER2 - SSB Layout Top
Top view PWB layout for the SSB.
J 715G7778 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for LED, IR, 3D, and Light sensor components.
J 715G8045 IR/LED Panel - IR & 3D & Light sensor & LOGO
Circuit diagrams for IR receiver, 3D & Light sensor, and LOGO components.
J 715G8045 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for IR receiver, LED, and Light sensor components.
E 715G7065 Keyboard control panel - Key+AL
Circuit diagrams for Key and AL (Ambilight) sections.
E 715G7065 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
E 715G7088 Keyboard control panel - Key
Circuit diagram for the Key section of the control panel.
E 715G7088 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
AL 715G7789 LED board - LOGO
Circuit diagram for the LOGO section of the LED board.
AL 715G7789 LED board - LED board layout top/bottom
Layout diagrams for the LED board (top and bottom sides).
AL 715G7004 Ambilight Board - TCL5971
Circuit diagram for the TLC5971 section of the Ambilight board.
AL 715G7004 Ambilight Board - Ambilight 9-LED
Circuit diagram for the Ambilight 9-LED section.
AL 715G7004 Ambilight Board - Ambilight board layout top/bottom
Layout diagrams for the Ambilight board (top and bottom sides).
AL 715G7007 Ambilight Board - TCL5971
Circuit diagram for the TLC5971 section of the Ambilight board.
AL 715G7007 Ambilight Board - Ambilight 6-LED
Circuit diagram for the Ambilight 6-LED section.
AL 715G7007 Ambilight Board - Ambilight 7-LED
Circuit diagram for the Ambilight 7-LED section.
AL 715G7007 Ambilight Board - Ambilight 9-LED
Circuit diagram for the Ambilight 9-LED section.
AL 715G7007 Ambilight Board - Ambilight board layout top/bottom
Layout diagrams for the Ambilight board (top and bottom sides).
BE-NT72333d-POWER
Circuit diagram for the BE-NT72333d-POWER section.
BE-NT72333e-DDR
Circuit diagram for the BE-NT72333e-DDR section.
BE-NT72333f-GND
Circuit diagram for the BE-NT72333f-GND section.
DCDC-SYSTEM-POWER1 - DCDC-SOC-VCCK-DVSS
Circuit diagram for the DCDC-SOC-VCCK-DVSS section.
DCDC-SYSTEM-POWER1 - DCDC-SYSTEM-POWER1
Circuit diagram for the DCDC-SYSTEM-POWER1 section.
DCDC-SYSTEM-POWER2 - DCDC-SYSTEM-POWER2
Circuit diagram for the DCDC-SYSTEM-POWER2 section.
DCDC-SYSTEM-POWER2 - AUDIO-1st-CLASS-D-AMP
Circuit diagram for the AUDIO-1st-CLASS-D-AMP section.
DCDC-SYSTEM-POWER2 - AUDIO-2nd-CLASS-D-AMP
Circuit diagram for the AUDIO-2nd-CLASS-D-AMP section.
DCDC-SYSTEM-POWER2 - BE-NT72333f-GND
Circuit diagram for the BE-NT72333f-GND section.
DCDC-SYSTEM-POWER2 - BE-NT72333a-Vx1-INPUT
Circuit diagram for the BE-NT72333a-Vx1-INPUT section.
DCDC-SYSTEM-POWER2 - HDMI-SOC-ARC
Circuit diagram for the HDMI-SOC-ARC section.
DCDC-SYSTEM-POWER2 - SCART-YPbPr-CVBS
Circuit diagram for the SCART-YPbPr-CVBS section.
DCDC-SYSTEM-POWER2 - CTRL-CONNECTORS
Circuit diagram showing various connectors like IR receiver, debug, and control signals.
DCDC-SYSTEM-POWER2 - CTRL-ETHERNET-PHY
Circuit diagram for the Ethernet PHY control, Wi-Fi, and Bluetooth sections.
DCDC-SYSTEM-POWER2 - HTV
Circuit diagrams for Ballroom SPK, IR IN/OUT, and 12V output current protection.
DCDC-SYSTEM-POWER2 - SSB Layout Top
Top view PWB layout for the SSB.
J 715G7778 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for LED, IR, 3D, and Light sensor components.
J 715G8045 IR/LED Panel - IR & 3D & Light sensor & LOGO
Circuit diagrams for IR receiver, 3D & Light sensor, and LOGO components.
J 715G8045 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for IR receiver, LED, and Light sensor components.
J 715G8045 IR/LED Panel - IR/LED Board Layout
Layout diagrams for the IR/LED board (top and bottom sides).
E 715G7065 Keyboard control panel - Key+AL
Circuit diagrams for Key and AL (Ambilight) sections.
E 715G7065 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
E 715G7088 Keyboard control panel - Key
Circuit diagram for the Key section of the control panel.
E 715G7088 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
AL 715G7789 LED board - LOGO
Circuit diagram for the LOGO section of the LED board.
AL 715G7789 LED board - LED board layout top/bottom
Layout diagrams for the LED board (top and bottom sides).
AL 715G7004 Ambilight Board - TCL5971
Circuit diagram for the TLC5971 section of the Ambilight board.
AL 715G7004 Ambilight Board - Ambilight 9-LED
Circuit diagram for the Ambilight 9-LED section.
AL 715G7004 Ambilight Board - Ambilight board layout top/bottom
Layout diagrams for the Ambilight board (top and bottom sides).
AL 715G7006 Ambilight Board - Key
Circuit diagram for the Key section of the Ambilight board.
AL 715G7006 Ambilight Board - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
AL 715G7006 Ambilight Board - Ambilight 7-LED
Circuit diagram for the Ambilight 7-LED section.
AL 715G7006 Ambilight Board - LED DRIVER 49-64
Circuit diagram for the LED DRIVER 49-64 section.
AL 715G7006 Ambilight Board - HDMI Inputs
Circuit diagrams for HDMI inputs, including ESD protection.
BE-NT72333c-TX-VB1
Circuit diagram for the BE-NT72333c-TX-VB1 section.
BE-NT72333c-TX-VB1 - SCART-YPbPr-CVBS
Circuit diagram for the SCART-YPbPr-CVBS section.
BE-NT72333c-TX-VB1 - CTRL-CONNECTORS
Circuit diagram showing various connectors like IR receiver, debug, and control signals.
BE-NT72333c-TX-VB1 - CTRL-ETHERNET-PHY
Circuit diagram for the Ethernet PHY control, Wi-Fi, and Bluetooth sections.
BE-NT72333c-TX-VB1 - HTV
Circuit diagrams for Ballroom SPK, IR IN/OUT, and 12V output current protection.
BE-NT72333c-TX-VB1 - SSB Layout Top
Top view PWB layout for the SSB.
J 715G7778 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for LED, IR, 3D, and Light sensor components.
J 715G8045 IR/LED Panel - IR & 3D & Light sensor & LOGO
Circuit diagrams for IR receiver, 3D & Light sensor, and LOGO components.
J 715G8045 IR/LED Panel - LED&IR&3D&Light sensor
Circuit diagrams for IR receiver, LED, and Light sensor components.
J 715G8045 IR/LED Panel - IR/LED Board Layout
Circuit diagrams for IR receiver, LED, and Light sensor components.
E 715G7065 Keyboard control panel - Key+AL
Circuit diagrams for Key and AL (Ambilight) sections.
E 715G7065 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
E 715G7088 Keyboard control panel - Key
Circuit diagram for the Key section of the control panel.
E 715G7088 Keyboard control panel - Keyboard Layout
Layout diagrams for the keyboard control panel (top and bottom sides).
AL 715G7789 LED board - LOGO
Circuit diagram for the LOGO section of the LED board.
AL 715G7789 LED board - LED board layout top/bottom
Layout diagrams for the LED board (top and bottom sides).
AL 715G7004 Ambilight Board - TCL5971
Circuit diagram for the TLC5971 section of the Ambilight board.
AL 715G7004 Ambilight Board - Ambilight 9-LED
Circuit diagram for the Ambilight 9-LED section.
AL 715G7004 Ambilight Board - Ambilight board layout top/bottom
Layout diagrams for the Ambilight board (top and bottom sides).
AL 715G7007 Ambilight Board - TCL5971
Circuit diagram for the TLC5971 section of the Ambilight board.
AL 715G7007 Ambilight Board - Ambilight 6-LED
Circuit diagram for the Ambilight 6-LED section.
AL 715G7007 Ambilight Board - Ambilight 7-LED
Circuit diagram for the Ambilight 7-LED section.
AL 715G7007 Ambilight Board - Ambilight 9-LED
Circuit diagram for the Ambilight 9-LED section.
AL 715G7007 Ambilight Board - Ambilight board layout top/bottom
Layout diagrams for the Ambilight board (top and bottom sides).
Styling Sheets - 6801 Series 43"
Exploded view of the 43" 6801 series TV, showing part numbers and descriptions.
Styling Sheets - 6801 Series 49"
Exploded view of the 49" 6801 series TV, showing part numbers and descriptions.
Styling Sheets - 6801 Series 55"
Exploded view of the 55" 6801 series TV, showing part numbers and descriptions.
Styling Sheets - 7101 Series 55"
Exploded view of the 55" 7101 series TV, showing part numbers and descriptions.
Styling Sheets - 7101 Series 65"
Exploded view of the 65" 7101 series TV, showing part numbers and descriptions.
Styling Sheets - 7601 Series 65"
Exploded view of the 65" 7601 series TV, showing part numbers and descriptions.
Styling Sheets - 7101 Series 75"
Exploded view of the 75" 7101 series TV, showing part numbers and descriptions.
Need help?
Do you have a question about the 55PUT6801/98 and is the answer not in the manual?
Questions and answers
