Operation, Parts
Cordless Electric Airless
Sprayers
For portable airless spraying of architectural paints and coatings (390 PC). For the
application of line striping materials (ES 500 Stencil). Not approved for use in
explosive atmospheres or hazardous (classified) locations. For professional use only.
390 PC Cordless Models: 25T804, 826280, 25T863, 25T943, 25T882, 25T805
ES 500 Stencil Models: 25U513, 25U514
3300 psi (228 bar, 22.8 MPa) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual and related
manuals before using the equipment. Be familiar with the controls
and the proper usage of the equipment. Save these instructions.
Related Manuals
Manual
Description
311861
Gun (Contractor/FTX)
334599
Pump
3A6285
Gun (Contractor PC)
311254
Silver/Flex Plus
Use only genuine Graco replacement parts.
The use of non-Graco replacement parts may void warranty.
3A8179C
EN
