DIRECT-VENT GAS FIREPLACE
OWNER'S OPERATION AND INSTALLATION MANUAL
EVDDVF36PN (PENINSULA) AND EVDDVF36STN (SEE THRU)
NATURAL GAS - ELECTRONIC IGNITION
WARNING: If the information in these instruc-
tions is not followed exactly, a fire or explosion
may result causing property damage, personal
injury, or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS :
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
This appliance may be installed in an aftermarket* permanently located, manufactured (mobile) home, where not
prohibited by state or local codes.
This appliance is only for use with the type of gas indicated on the rating plate.
This appliance is not convertible for use with other gases, unless a certified kit is used.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.
(Peninsula
Shown)
CHECK LOCAL CODES PRIOR TO INSTALLATION
Save this manual for future reference.
®
SAVE THIS BOOK
This book is valuable. In addition to instructing
you on how to install and maintain your appli-
ance, it also contains information that will
enable you to obtain replacement parts or
optional accessory items when needed. Keep
it with your other important papers.
WARNING: Improper installation,
adjustment, alteration, service, or
maintenance to this appliance can
cause injury or property damage.
Refer to this manual. For assistance
or additional information consult a
qualified installer, service agency,
or the gas supplier.
WARNING: This Direct-Vent Gas
Fireplace series is intended for use
with Natural or Propane/LP gas only.
Do not attempt to burn any solid
fuels in these appliances.
Advertisement
Table of Contents
Related Manuals for Desa Vanguard EVDDVF36PN
Summary of Contents for Desa Vanguard EVDDVF36PN
- Page 1 DIRECT-VENT GAS FIREPLACE OWNER’S OPERATION AND INSTALLATION MANUAL EVDDVF36PN (PENINSULA) AND EVDDVF36STN (SEE THRU) NATURAL GAS - ELECTRONIC IGNITION WARNING: If the information in these instruc- tions is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life.
-
Page 2: Right Side
(4cm) (Back) (30cm) (Right Side) Right Side Surround (27cm) RIGHT SIDE (3cm) (57cm) 32 (81cm) (Opening) (104cm) Figure 1 - EVDDVF36PN (Peninsula) Dimensions TOP VIEW Left Side Surround (Left Side) Back of Surround (60cm) ø1.5 (Back) (4cm) (30cm) (Right Side) -
Page 3: Before You Begin
DESA. Unless you use DESA approved components tested for this appliance, YOU MAY CAUSE A SAFETY HAZARD! The DESA warranty will be voided by, and DESA disclaims any responsibility for the following actions: A) Modification of the appliance or any of... -
Page 4: Pre-Installation Preparation
DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN PRE-INSTALLATION PREPARATION CLEARANCES Minimum clearances to combustibles are: • Back and Sides of Surround: ... 0" min. • Vent Surfaces: Vertical Runs: ... 1" (5cm) min. Top of Horizontal Runs . 2" (5cm) min. -
Page 5: General Venting
PRE-INSTALLATION PREPARATION Continued " (1010mm) Min. Figure 7 - Rough Opening for Installing Peninsula Fireplace Platform Must Be Solid, Flat, and Fully Supported " (1010mm) Min. Figure 8 - Rough Opening for Installing Peninsula Fireplace on Platform * As required by design as long as ceiling clearance is maintained. - Page 6 DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN GENERAL VENTING TERMINATION CAP A = clearance above grade, veranda, porch, deck, or balcony [*12 inches (305mm) minimum] B = clearance to window or door that may be opened [12 inches (305mm) minimum]...
-
Page 7: Venting Installation
• Unauthorized modification of the vent- ing system 106573 OWNER’S MANUAL • Installation of any component part not manufactured or approved by DESA International • Installation other than as instructed by these instructions WARNING: This gas fireplace and vent assembly must be vented directly to the outside. - Page 8 DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN VENTING INSTALLATION Continued INSTALLATION FOR HORIZONTAL TERMINATION 1. Determine the route your horizontal venting will take. Note: The location of the horizontal vent termination on the exterior wall must meet all local and national building codes and must not be easily blocked or obstructed.
- Page 9 VENTING INSTALLATION Continued 3. Attach vent pipe assembly to the fire- place. Set fireplace in front of it’s per- manent location to insure minimum clearances. Mark the wall for a 10" square hole (for noncombustible ma- terial such as masonry block or con- crete, a 7 "...
- Page 10 DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN VENTING INSTALLATION Continued Horizontal Termination Configurations Figures 21 through 23 show different con- figurations for venting with horizontal ter- mination. Each figure includes a chart with vertical minimum/maximum and horizon- tal maximum dimensions which must be met.
- Page 11 VENTING INSTALLATION Continued Venting with Two 90° Elbows Vertical (V) Horizontal (H Horizontal (H 5' min. 4' max. 6' min. 8' max. 7' min. 10' max. 8' min. 15' max. 20' max. 20' max. Figure 23 - Horizontal Termination Configuration for Rigid Venting Using Two 90° Elbows with Termination at 90° with Fireplace 106573 OWNER’S MANUAL 45°...
-
Page 12: Installation For Vertical Termination
DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN VENTING INSTALLATION Continued INSTALLATION FOR VERTICAL TERMINATION NOTICE: Use rigid pipe only. Flex venting is not to be used with a vertical termination. 1. Determine the route your vertical vent- ing will take. If ceiling joists, roof... -
Page 13: Installation
VENTING INSTALLATION Continued 3. Lower the support box through the hole in the roof until the bottom of the box extends at least 2" below the ceiling (see Figure 26). Align the support box vertically and horizontally using a level. Temporarily tack the support box in place through the inside walls and into the roof sheathing. - Page 14 DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN VENTING INSTALLATION Continued 45° Starter Elbow Required Venting with Two 90° Elbows Vertical (V 5' min. 6' min. 7' min. 8' min. Note: Vertical (V Vertical (V Figure 30 - Vertical Rigid Venting Configuration Using Two 90° Elbows Horizontal (H) 6' max.
-
Page 15: High Altitude Installation
Consult your local gas company to help de- termine the proper orifice for your location. For assistance with any high altitude instal- lation contact DESA International’s Tech- nical Service Department at 1-800-DESA- LOG (1-800-337-2564). PARTS LISTS FOR VENTING KITS AND COMPONENTS *NOTICE: The 7"... - Page 16 DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN INSTALLATION INSTALLING OPTIONAL WALL MOUNT SWITCH GWMS2 NOTICE: The GWMS2 includes 25' of wire for installation. Your fireplace includes 15' of wire for accessory installation. Choose the length that best fits your needs when installing this accessory.
-
Page 17: Optional Remote Control Installation
INSTALLATION Continued OPTIONAL REMOTE CONTROL INSTALLATION (Model WRC) Note: If using optional wireless hand-held remote control, the wall switch must be in the ON position to be operational. The re- mote control then becomes the switching mechanism for fireplace operation. 1. -
Page 18: Installing Log Set
DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN INSTALLATION Continued WARNING: All gas piping and connections must be tested for leaks after the installation is completed. After ensuring that the gas valve is open, apply a soap and water solution to all connections and joints. -
Page 19: Decorative Facing
INSTALLATION Continued WARNING: Improper installa- tion, adjustment, alteration, ser- vice, or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information, consult a qualified installer, service agency, or gas supplier. Figure 43 - Log Set (9 Pieces) Left Right Figure 44 - Burner and Grate (Top View) -
Page 20: Burner Removal
DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN BURNER FLAME ADJUSTMENT Continued BURNER REMOVAL CAUTION: Before proceed- ing, make sure the entire unit is cool. 1. Remove the top and bottom louvers and screen. Open the glass door (left or right side). -
Page 21: Operating Fireplace
OPERATING FIREPLACE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not fol- low these instructions exactly, a fire or explosion may result caus- ing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition device which automatically lights the main burner. -
Page 22: Service Hints
GAS LINE BURNER TECHNICAL SERVICE You may have further questions about in- stallation, operation, or troubleshooting. If so, contact DESA International’s Technical Service Department at 1-800-323-5190. You can also visit DESA International’s technical services site www.desatech.com. WALL SWITCH (SUPPLIED) FIELD WIRE... -
Page 23: Troubleshooting
TROUBLESHOOTING Note: For additional help, visit DESA International’s technical service web site at www.desatech.com. Note: Before troubleshooting the system, make sure the gas shutoff valve is ON. OBSERVED PROBLEM Can not light main burner No gas to burner, although wall switch and... - Page 24 DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN TROUBLESHOOTING Continued OBSERVED PROBLEM Delayed ignition burner Burner backfiring during combustion Slight smoke or odor during initial operation Fireplace produces a whistling noise when burner is lit Glass soots Fireplace produces a clicking/ticking noise...
- Page 25 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
- Page 26 DIRECT-VENT GAS FIREPLACE ® EVDDVF36PN and EVDDVF36STN ACCESSORIES Transmitter Receiver RECEIVER AND HAND-HELD REMOTE CONTROL KIT 00710 (WRC) For all models. Allows the gas log heater to be turned on and off by using a hand-held remote control. BLOWER KIT - DVFFBK For all models.
- Page 27 REPLACEMENT PARTS Continued HIGH VOLTAGE CABLE 14386 Front (Bottom) Left/Right (Bottom) Rear (Used for Peninsula and See-Thru) Front (Used for See-Thru Only) REFRACTORY PIECES Front (Bottom) 105886-01 (25854) Left/Right (Bottom) 105887-01 (25856) Rear - 106924-01 (27374) Front - 105888-01 (25885) TRANSFORMER 14129 (107222-01) 106573...
-
Page 28: Warranty Information
We make no other warranty, expressed or implied. DESA International warrants this product to be free from defects in materials and components for four (4) years from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions. To make a claim under this warranty the Bill of Sale or cancelled check must be presented.
