Summarization of Contents
Rules for Unit Installation
Selection of Installation Location
Location for installation of the Unit must be selected so that the treated water can flow automatically.
Preparation for Construction
The wastewater pipe from the source to the Unit must be laid with a slope suitable for gravity flow.
Construction Procedures
Earthwork must be carried out strictly in accordance with normative acts and the technical or work project.
Blower and Air Supply Pipe Installation
Selection of location for the blower in accordance with technical requirements.
AUGUST BASIC Unit Installation and Connection
Installation of the Unit controller indoors or in the blower container with good air circulation.
Warranty Terms and Conditions
Manufacturer's Quality Warranty
Manufacturer's quality warranty for the underground part of the Unit housing is 10 years from the date of sale.
Warranty Coverage and Validity
Warranty covers defects due to materials or design; valid if installation, storage, and operation conditions are met.
Warranty Service Eligibility
Operator must notify Seller of defects and submit purchase and installation documents.
Unit Diagram and Technical Parameters
Unit Diagram
Schematic illustration of the wastewater treatment unit and its components.
Technical Parameters of Wastewater Treatment Plants
Table detailing technical specifications such as diameter, height, and electrical consumption for different models.
Mechanical and Electrical Devices
Solids Bag Functionality
The solids bag is used for separation of gross solids from wastewater.
Air Distribution Panel and Valves
Air supply to airlifts and regulator is adjustable by means of valves on the air distribution manifold.
Flow Controller Operation
The flow controller ensures flow balancing under high instantaneous loads.
Blower Specifications
The blower is an electromagnetic diaphragm compressor, characterised by longevity and low maintenance costs.
Diffuser Components
Diffusers are made of non-clogging membrane, polypropylene and stainless steel parts.
Airlift System
Mixing, circulation and activated sludge and wastewater recirculation are ensured by airlifts 1, 2 and 3.
AUGUST BASIC Controller Operation
Initial Controller Setup (First Run)
Instructions for the initial setup of the controller, including language, date, and time settings.
Changing Operating Mode and Programs
Procedure for entering the menu to select operating mode and programs.
Available Controller Programs
Description of standard and non-standard programs for the controller.
Additional Settings and Information
Details on DATE AND TIME SETUP, OPERATING HOURS, READ LOG, SERVICE MENU, LANGUAGE SELECT, etc.
GSM Module Functionality
Information on the control unit with GSM module and its network connection.
Operation and Maintenance Instructions
Unit Launching Procedure
Steps for launching the Unit, including setting the controller and connecting the blower.
Unit Shutdown Procedure
Procedure for safely shutting down the Unit by disconnecting the controller.
Routine Maintenance Tasks
Overview of regular maintenance tasks required for the Unit, including checks and cleaning.
Controller Maintenance Notifications
Explanation of controller warnings like 'REPLACE FILTER' and 'CHANGE MEMBRANE'.
Removal of Excess Sludge
Procedure and guidelines for removing excess sludge from the biological reactor.
Security and Safety Precautions
Servicing Personnel Requirements
Unit servicing must be performed by a qualified person aged 18 or over.
Household Wastewater Handling
Household wastewater can contain pathogenic organisms; take precautions to protect yourself.
Personal Protective Equipment
List of personal and protective equipment recommended for maintenance tasks.
Recommended Maintenance Tools
List of recommended tools for performing Unit maintenance.
