Summarization of Contents
Getting Started
Setup Local Area Connection on Your PC
Guide to connecting the AP/CPE to a PC via wired or wireless mode.
Check Access
Instructions on using the "ping" utility to verify network connectivity.
Configuration with Web-Admin
Steps for accessing and logging into the web-based administration interface.
Radio Interface Status
Radio0 Interface Status-AP Mode
Information on Radio0 interface status in AP mode, including Status, Statistic, Channel Usage, WLAN.
Radio0 Interface Status-Station Mode
Information on Radio0 interface status in Station mode, including Status, Statistic, Channel Usage, STA Info.
Radio0 Interface Status-Repeater Mode
Information on Radio0 interface status in Repeater mode, including Status, Statistic, Channel Usage, STA Info, AP Info.
Radio0 Interface Status-Bridge Mode (for C1an and C1xan)
Information on Radio0 interface status in Bridge mode for C1an and C1xan devices.
Historical Statistics
System Statistics
Displays historical data for memory free and CPU usage over time.
Ethernet Statistics
Historical statistics for Ethernet traffic, including TX/RX packet rates.
Radio Statistics
Historical statistics for Radio, including throughput, busy%, Tx/Rx usage, and noise floor.
Logs
System Log
Records system information, hardware, configuration, and self-checking results.
Panic Log
Logs internal errors that may require the system to reboot itself.
Alarm Log
Records alarm events and messages for system monitoring.
System Configuration
C1n Series AP/CPE Basic Configuration Procedures
Outlines the general procedure for saving configuration changes on the AP/CPE.
Basic System Configuration
System Info Setting
Configures device name, NE ID, location, and other system management info.
NTP Setting
Sets up Network Time Protocol (NTP) for synchronizing device time with a server.
Network Configuration
General Network Configuration
Configures general network settings including WAN, LAN, and interface assignments.
VLAN Setting (IPv4)
Configures WLAN settings for IPv4, including connection type and IP addressing.
WLAN Setting (IPv6)
Configures WLAN settings for IPv6, including connection type and IP addressing.
STP Setting
Enables or disables the Spanning Tree Protocol (STP) for network loop prevention.
WAN/LAN Interface Assignment
Assigns Ethernet and Radio0 interfaces as WAN or LAN.
LAN Setting (IPv4)
Configures the IP address and subnet mask for the local area network (LAN).
Ethernet Setting
Configures the Ethernet port's detection mode (auto/manual) and duplex settings.
VLAN
Enables or disables the VLAN function for network segmentation.
DHCP Server
Configures the device as a DHCP server to automatically assign IP addresses to clients.
Port Forwarding
Configures rules to forward external network traffic to specific internal hosts.
Safe Mode
Configures settings to detect backhaul link integrity and manage client re-association.
Wireless
Radio0 Configuration
Configures the Radio0 interface for various modes like AP, Station, Repeater, Bridge.
Radio0 Configuration – AP Mode
General Configuration
Sets up general parameters for Radio0 in AP mode, including radio enable and country code.
WLAN Configuration
Configures up to 16 individual WLANs (SSIDs) for the Radio0 interface.
WLAN X (0-15) General Configuration
Details configuration for each WLAN, including SSID, Max Clients, and Isolation.
WLAN X (0-15) Security
Configures wireless security options for WLANs, including Open, Shared Key, WPA/WPA2.
ACL Configurations
Configures Access Control Lists (ACL) for MAC address filtering (Allow/Deny).
WLAN X (0-15) Rogue Station List
Manages rogue stations by adding MAC addresses to prevent association.
WLAN X (0-15) QoS
Configures Quality of Service (QoS) parameters for WLANs using DSCP values.
WLAN X (0-15) Bandwidth Control
Sets uplink/downlink bandwidth limits for WLANs or individual clients.
Advanced Configuration
AMPDU
Enables or disables 802.11n aggregation of MAC protocol data units.
AMPDU Limit
Specifies the maximum number of data frames for AMPDU aggregation.
AMSDU
Enables or disables 802.11n aggregation of MAC service data units.
WEP Key Setting
Configure WEP Key for wireless security
Sets up WEP keys for wireless security when using Open or Shared Key modes.
Radio0 Configuration – Station Mode
General Configuration
Configures general settings for C1n when operating as a station, including SNR indicators.
Station Configuration
Configures station settings, including remote AP SSID and authentication mode.
WLAN 0 General Configuration
Details general configuration for WLAN 0 in Station mode, including MAC clone and roaming settings.
WLAN 0 Security
Configures wireless security for WLAN 0 in Station mode, matching remote AP settings.
WLAN 0 QoS
Configures QoS for WLAN 0 in Station mode, referring to AP mode QoS settings.
Radio0 Configuration – Repeater Mode
General Configuration
Configures general settings for C1n in Repeater mode, including radio enable and max clients.
Repeater Configuration
Details repeater configuration, referencing Station mode settings.
WLAN Configuration
WLAN configuration for Repeater mode, referencing AP mode settings.
Radio0 Configuration – Bridge Mode(for C1an and C1xan)
General Configuration
Configures Radio0 for Bridge mode on C1an/C1xan, requiring matching settings.
Static Bridge Setting
Configures settings for the static bridge link, including remote peer MAC and cipher mode.
QoS Setting
Configures QoS for Bridge mode, referring to AP mode QoS settings.
Thin AP Configuration
Thin AP
Enables or disables Thin AP mode, allowing centralized management by an Access Controller.
Administration Configuration
User Admin
Manages administrator accounts and authentication types (Local, RADIUS).
Web Admin
Sets the refresh interval for the web GUI and enables/disables syslog.
SNMP Setting
Enables SNMP and configures read/write communities for network management.
Trap Host Setting
Configures SNMP trap hosts to receive alerts from the device.
Certificate Management
Uploads custom SSL certificate and key files for HTTPS web portal security.
Firmware Update
Provides instructions for updating the device firmware through the web interface.
Restore Factory Default
Resets the device to factory default settings using the web interface or hardware button.
Backup/Restore
Manages device configuration by backing up or restoring settings.
Customization
Customizes default settings by editing template files and uploading them.
License
Uploads and installs license files to enable specific device features.
Tools
Channel Scan
Scans wireless channels to gather information on noise floor, busy percentage, and APs.
Diagnosis
Provides diagnostic tools like Ping and Traceroute for network troubleshooting.
Watchdog
Monitors system status and schedules reboots or log uploads for recovery.
C1n Series Information
Production Information
Shows the product name, code, serial number, and product mode of the C1n.
Hardware Version
Displays the hardware version of the C1n device.
Software Version
Displays the software version of the firmware and MIB for the C1n.
Company Information
Displays general information about Altai Technologies Limited.
