- Page 1 ALTAI A8 WiFi Base Station Altai A8 WiFi Base Station Installation Guide ( R2 Hardware Platform ) Version 1.1 Date: 23-Jun-2006 A8 Installation Guide_v1.1_20060623 ALTAI Confidential...
- Page 2 ALTAI A8 WiFi Base Station Copyright © 2006 Altai Technologies Limited ALL RIGHTS RESERVED. Altai Technologies Limited 5th Floor, Photonics Centre, 2 Science Park East Avenue, Hong Kong Science Park, Shatin, New Territories, Hong Kong Telephone: +852 8200 3903 Fax: +852 2607 4021 Web: www.altaitechnologies.com...
- Page 3 ALTAI A8 WiFi Base Station Radio Frequency Interference Requirements This device complies with Part 15 of FCC Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 4: Table Of Contents
ALTAI A8 WiFi Base Station Table of content .......................5 NTRODUCTION A8 B ..................6 TATION UTLOOK A8 A ....................7 NTENNA UTLOOK A8 B ..................8 TATION ACKAGE ....................9 ANTENNA PACKAGE .......................11 REPARATION ................12 OUNTING ANTENNA ON A POLE 802.11 ..................14 OUNTING NTENNA A8 B ..............15... -
Page 5: Introduction
ALTAI A8 WiFi Base Station 1 Introduction This guide is designed to provide the information needed to mount A8 base station (BTS) and A8 antenna at the site location. The document is applicable for hardware platform A8 R2 and the following models. -
Page 6: A8 Base Station Outlook
ALTAI A8 WiFi Base Station 2 A8 Base Station Outlook Antenna Ports Console Port Power Port Ethernet Port Figure 1. A8 Front 802.11a port (optional) Sector 4 Sector 3 Sector 2 Sector 1 mounting screw Figure 2. A8 Top-view A8 Installation Guide_v1.1_20060623... -
Page 7: A8 Antenna Outlook
ALTAI A8 WiFi Base Station 3 A8 Antenna Outlook B8 Antenna Antenna mounting Antenna Port Figure 3. A8 Antenna A8 Installation Guide_v1.1_20060623 ALTAI Confidential... -
Page 8: A8 Base Station Package
2 x metal mounting tape 4 x wall plug (left), 4 x self tapping metal screw (right), 4 x flat washer (bottom) 3 x screw (left), 2 x cable clip (right) Figure 4. A8 Base Station Package A8 Installation Guide_v1.1_20060623 ALTAI... -
Page 9: A8 Antenna Package
ALTAI A8 WiFi Base Station 5 A8 antenna package 1 x A8 antenna 1 x upper mounting 1 x lower mounting 4 x screw & nut 4 x screw & nut Figure 5. A8 Antenna Package Note: 1. Parts D are used to replace the large screw for smaller antenna pole size. Please refer to the parts 11, 12, 14 &... - Page 10 ALTAI A8 WiFi Base Station Figure 6. A8 Antenna Assembly A8 Installation Guide_v1.1_20060623 ALTAI Confidential...
-
Page 11: Site Preparation
Please make sure that the network connection between central office and the site is properly connected. 3. Make sure that there is AC electrical power supply for A8 base station at the site. 4. Configure the A8 base station properly, e.g. assign correct IP address of A8 base station. -
Page 12: Mounting A8 Antenna On A Pole
ALTAI A8 WiFi Base Station 7 Mounting A8 antenna on a pole 1. Assemble the antenna with mounting kit according to Figure 6. Select the suitable screw (Parts 11, 12, 14 & 15 in Figure 6) to fix the pole size (diameter). - Page 13 ALTAI A8 WiFi Base Station Figure 11. Fix downtilt Figure 10. Measure the downtilt angle Figure 12. Antenna mounted on Pole A8 Installation Guide_v1.1_20060623 ALTAI Confidential...
-
Page 14: Mounting 802.11A Antenna
ALTAI A8 WiFi Base Station 8 Mounting 802.11a Antenna 1. Mount the 802.11a antenna to the pole. 2. Adjust the direction and downtilt degree pointing to another 802.11a antenna in other site, as shown in Figure 13. Figure 13. 802.11a Antenna A8 Installation Guide_v1.1_20060623... -
Page 15: Mounting A8 Base Station On The Pole
1. Use the metal tape to mount the metal plate on the pole, Figure 14. 2. Install the A8 base station on the metal plate, Figure 15. 3. Use the screw (Part E in Figure 4) to fix the BTS at the bottom of metal plate, Figure 16 and Figure 17. - Page 16 ALTAI A8 WiFi Base Station 10 Mounting A8 Base Station on the Wall 1. Use an electric drill to drill four suitable apertures on the wall. (It is strongly recommend that mark the suitable positions on the wall by pencil before drilling) 2.
-
Page 17: Connecting Rf Cables
ALTAI A8 WiFi Base Station 11 Connecting RF Cables 1. Connect RF cables to antenna, Figure . 2. According to the RF ports assignment in Figure 2, connect RF cables with BTS with antennas according to the table below: A8 BTS... -
Page 18: Recommendation On Rf Cable And Antenna Pole
ALTAI A8 WiFi Base Station 12 Recommendation on RF cable and Antenna Pole RF Cable A RF cable should be assembled with N-type male connectors at both ends. The length and diameter depend on the site situation. Our recommendation is that the insertion loss of the RF cable should not be greater than 1dB at 2.4GHz (for 802.11b/g) or 2dB at 5.8GHz (for 802.11a). -
Page 19: Typical Site Setup
ALTAI A8 WiFi Base Station 13 Typical Site Setup A typical site setup is shown below. Figure 21. Typical A8 Setup A8 Installation Guide_v1.1_20060623 ALTAI Confidential...
