Summarization of Contents
Getting Started with C1n Series AP/CPE
Local Area Connection Setup
Configures the PC's local area connection for wired or wireless access to the AP/CPE.
Network Access Verification
Verifies network connectivity to the C1n Series AP/CPE using the 'ping' utility.
Web-Admin Configuration Access
Accesses and configures the AP/CPE settings via a web browser interface.
Permanent Secondary IP Configuration
Sets a secondary IP address using the Ethernet MAC address for the device.
Interface, Logout, and Reboot Guide
Explains the web interface structure, logout procedure, and device reboot.
System Status and Monitoring
System Information
Displays basic system details like product name, CPU, memory, time, and uptime.
Interface Status Overview
Shows status and information for Radio0 and Ethernet interfaces.
Radio Interface Status
Provides detailed status information for the Radio0 interface in various modes.
Ethernet Interface Status
Displays status information for the Ethernet interface, including speed and link detection.
Historical Statistics
Offers historical statistics for system, Ethernet, and radio for troubleshooting.
Log Management
Provides access to System, Panic, and Alarm logs for monitoring and diagnosis.
System Configuration
Basic Configuration Procedures
Guides users through saving and applying configuration changes to the device.
System Settings Configuration
Configures system parameters like name, NTP, and historical statistics collection.
Network Configuration
Sets up general network parameters, VLAN, DHCP, Port Forwarding, and Safe Mode.
Wireless Network Configuration
Manages wireless settings for Radio0, including AP, Station, Repeater, and Bridge modes.
Administration and Management
User Administration and Authentication
Manages administrator accounts and login authentication methods (Local/RADIUS).
Web Administration Settings
Configures web page refresh intervals and system log settings (Syslog).
SNMP and Trap Host Configuration
Sets up SNMP for monitoring and defines trap hosts for network management.
Certificate Management
Uploads SSL certification files for HTTPS web portal security.
Firmware Update Process
Details the procedure for upgrading or downgrading the device firmware.
Factory Default Restore
Resets the device to factory default settings via web GUI or hardware button.
Backup and Restore Configuration
Allows users to back up or restore the device's configuration settings.
Customization of Default Settings
Customizes default system, network, and wireless configuration files.
License Management
Manages customized license files for defining Radio module operating modes.
Tools and Utilities
Channel Scan Tool
Scans 2.4GHz/5GHz radio channels to collect noise floor, busy percentage, and AP counts.
AP List Information
Displays details of nearby APs, including SSID, authentication, and signal strength.
Diagnosis Tools (Ping/Traceroute)
Provides diagnostic tools like Ping and Traceroute for network troubleshooting.
Watchdog Timer Settings
Configures periodic reboots and log uploads for system maintenance.
C1N Series Product Information
Product and Company Details
Shows production, hardware, software versions, and Altai company information.
