Summarization of Contents
For Your Safety
Qualified Service
Only qualified personnel may install or repair mobile terminal equipment.
Accessories and Batteries
Use only approved accessories and batteries. Do not connect incompatible products.
Connecting to Other Devices
When connecting to any other device, read its user’s guide for detailed safety instructions.
General Information
Product selection
RM-583 (Nokia 3806) mobile terminal offers a CDMA single band engine.
Phone features and sales package
Details of hardware and software features and items included in the sales package.
Technical Specifications
Provides general specifications and battery endurance details for the RM-583.
Parts Lists and Exploded View
Phone exploded view
An exploded view diagram showing the internal components of the RM-583.
Spare parts overview
Information on obtaining spare parts for the RM-583.
Service Software Instructions
Installation
Step-by-step guide for installing the Nokia 3806 AMS tool and its drivers.
PRI operation
How to use the PRI Settings Editor for reading and writing PRI NV values.
RF calibration
Procedure for automatic tuning of RF values using the RF Calibration tool.
Write NV
Procedure for writing NV values to the phone using the Write NV function.
Service Tools
Service tools
Table detailing service tools like CA-101, MJ-272, AK05G, CA-128RS, PK-86.
Power on sequence
Procedure for powering on the device using AC or DC power supplies.
Antenna Description
Failures and corrective measures
Common antenna failures and their corresponding corrective actions.
RF connector failure
Diagnosis and repair for RF connector failures affecting antenna performance.
Baseband Description and Troubleshooting
Power Does Not Stay ON
Troubleshooting guide for failures where the power does not remain on.
Audio Faults
Troubleshooting common audio issues like no sound in earpiece or microphone.
Display Faults
Steps for troubleshooting common display defects like white panel or color issues.
Keypad Faults
Procedure for diagnosing and resolving keypad defects.
RF Description and Troubleshooting
TX troubleshooting
Instructions for troubleshooting transmission (TX) related issues.
TX DC test points
Identification and description of DC test points for TX path.
TX path troubleshooting
Troubleshooting guide for issues in the transmission (TX) path.
