SERVICE MANUAL
Level 1&2
RM-588 / RM-594 / RM-629
Transceiver characteristics
Band:
• EGSM 850/900/1800/1900
• WCDMA 900/2100 (RM-588)
• WCDMA 850/1900 (RM-594)
• WCDMA 850/2100 (RM-629)
Display:
nHD 3.2" TFT, up to 16 million colours (640x360 pixel
resolution)
active area
16:9 aspect ratio
Camera:
2.0 Mpix (1600 x 1200), CMOS
3x digital zoom
Operating System:
Symbian OS ver. 9.4 Series60 5th Edition (5.0)
Connections:
Cellular radio: 3GPP GSM+(E)GPRS+WCDMA+HSDPA
USB 2.0 (micro USB), Bluetooth wireless technology
2.0 + EDR + A2DP + AVRCP
3.5mm AV connector
Talk time
GSM:
Up to 420 min
WCDMA:
Up to 258 min
Note: Talk times are dependant on network
parameter settings.
Confidential • Copyright © 2010 NOKIA • All rights reserved
Nokia 5235 Comes With Music
RM-588 / RM-594 / RM-629
Service Manual Level 1&2
39.6 mm x 70.4 mm
Standby
GSM:
Up to 438 h
WCDMA:
Up to 458 h
Version 1.0
Advertisement
Table of Contents
Related Manuals for Nokia RM-588
Summary of Contents for Nokia RM-588
- Page 1 GSM: Up to 420 min Up to 438 h WCDMA: WCDMA: Up to 258 min Up to 458 h Note: Talk times are dependant on network parameter settings. Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0...
-
Page 2: Table Of Contents
Battery information ................................. 8 Exploded view ................................... 9 Service devices ..................................10 SW-update ....................................11 Disassembly instructions ..............................12 10. Assembly Hints ..................................19 11. Solder Components ................................20 Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0... -
Page 3: Change History
16.4.2010 Exploded view updated The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is confidential. Please note that NOKIA provides also other guidance documents (e.g. -
Page 4: Copyright
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused. -
Page 5: Warnings And Cautions
3. Use only approved components as specified in the parts list. 4. Ensure all components, modules screws and insulators are correctly re–fitted after servicing and alignment. 5. Ensure all cables and wires are repositioned correctly Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0... -
Page 6: Esd Protection
RM-588 / RM-594 / RM-629 Service Manual Level 1&2 3. ESD PROTECTION Nokia requires that service points have sufficient ESD protection (against static electricity) when servicing the phone. Any product of which the covers are removed must be handled with ESD protection. -
Page 7: Care And Maintenance
All of the above suggestions apply equally to the product, battery, charger or any accessory. Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0... -
Page 8: Battery Information
Batteries’ performance is particularly limited in temperatures well below freezing. Do not dispose batteries in a fire! Dispose of batteries according to local regulations (e.g. recycling). Do not dispose as household waste. Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0... -
Page 9: Exploded View
Phones without stylus (thin Battery cover): I0032 RM-588(Europe, Eurasia), RM-593, RM-629 BATTERY COVER I0031 Only available as These parts can not be Ver. 2.0 assembly reused after removal Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0... -
Page 10: Service Devices
For more information, refer to the Service Bulletin (SB-011) on NOKIA Online. Supplier or manufacturer contacts for tool re-order can be found in “Recommended service equipment” document on NOKIA Online. Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0... -
Page 11: Sw-Update
To use the FLS-5 Flash Dongle, follow the user guide inside the sales package. Please check always for the latest version of flash software, wich is available on Nokia Online. Confidential • Copyright © 2010 NOKIA • All rights reserved... -
Page 12: Disassembly Instructions
5) Remove the BATTERY COVER. If there is a battery 6) Unscrew the four TORX+ size 5 screws in the inserted, remove it also. order shown. Remove them with the tweezers. Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0... - Page 13 SS-93. 11) Continue to the bottom side and release two 12) Then release the remaining clips on both sides clips holding the A-COVER. of the phone. Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0...
- Page 14 LCD and the LCD FRAME ASSY. Carefully slide the carefully lay it down. Be careful not to break the tool underneath the LCD to loosen the adhesive. flex! Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0...
- Page 15 23) Turn over the ENGINE BOARD. Be careful not to 24) Open the locking mechanism of the LCD break the flex! connector. Be careful not to damage the components nearby! Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0...
- Page 16 29) Remove the lids with the tweezers. Do not use 30) Use the camera removal tool SS-88 to lift up the them again. Discard them. camera. Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0...
- Page 17 Remove it with the tweezers. 35) Lever out the EAR PIECE with the dental tool. 36) Remove it with the tweezers. Remove also the remains of the GASKET from the EAR PIECE. Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0...
- Page 18 41) Also, make sure the adhesive which is on top of 42) Nokia 5230 disassembly is now complete. the TOUCH PANEL ASSY is removed while detaching the TOUCH FRAME ASSY. -END OF DISASSEMBLY- Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0...
-
Page 19: Assembly Hints
10. ASSEMBLY HINTS Tighten the 2 screws to the torque of 16 Ncm in the Tighten the screws to the torque of 17 Ncm in the order shown. order shown. Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0... -
Page 20: Solder Components
Nokia 5235 Comes With Music RM-588 / RM-594 / RM-629 Service Manual Level 1&2 11. SOLDER COMPONENTS X6200 X6400 S2504 F2000 BOTTOM X2401 X2450 S2502 S2503 S2505 X2500 S2500 X2470 Ver. 1.0 Confidential • Copyright © 2010 NOKIA • All rights reserved Version 1.0...
