DESPIECE / PART LIST
TXT PRO
125 / 200 / 250 / 280
2003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TXT PRO - PART LIST MOTOR 2003 and is the answer not in the manual?

Questions and answers

Boyan
January 30, 2025

How much transmission oil have to put

0

Subscribe to Our Youtube Channel

Related Manuals for GAS GAS TXT PRO - PART LIST MOTOR 2003

Summary of Contents for GAS GAS TXT PRO - PART LIST MOTOR 2003

  • Page 1 DESPIECE / PART LIST TXT PRO 125 / 200 / 250 / 280 2003...
  • Page 2 MOTOR / Cto. Pedal de arranque TXT-PRO 03 Caja láminas / Reed valve TXT-PRO 03 Selector / Shift cam TXT-PRO 03 / Quickstart pedal Cárter / Crankcase TXT-PRO 03 Encendido / Ignition TXT-PRO 03 Encendido / Ignition TXT-PRO 03 125 / 200 250 / 280 Cigueñal / Crankshaft TXT-PRO 03...
  • Page 3 / ENGINE Embrague / Clutch TXT-PRO 03 Cilindro / Cylinder TXT-PRO 03 Engranajes cambio TXT-PRO 03 / Gear set 125 cc. / 200 cc. 250 cc. / 280 cc. Carburador / Carburetor TXT-PRO 03 Carburador / Carburetor TXT-PRO 03 Bomba de agua TXT-PRO 03 125 / 200 / 250 / Water pump...
  • Page 4 Cto. Pedal de arranque TXT-PRO 03 / Quickstart pedal...
  • Page 5 Nº DESCRIPCION / DESCRIPTION 125 / 200 / 250 / 280 c.c. Cant. ARANDELA 14X25X0,5 / 14X25X0,5 WASHER T4001425 MUELLE ARRANQUE TRIAL SXXI / PEDAL KICKSTART SPRING MT280226007 CENTRADOR MUELLE ARRANQUE / KICKSTART SPRING BUSHING MT280226053 CIRCLIP PARA EJE 18 MM / AXIS CIRCLIP MT280226017 PIÑON ARRANQUE TRIAL 2002 / KICKSTART GEAR MT280226002...
  • Page 6 Caja láminas / Reed valve TXT-PRO 03...
  • Page 7 Nº DESCRIPCION / DESCRIPTION 125 / 200 / 250 c.c. 280 c.c. Cant. JUNTA CAJA LAMINAS TRIAL SXXI / REED VALVE GASKET MT280244005 ALLEN 5X30 ZINCADO NEGRO / 5X30 ZINCAT BLACK ALLEN T0305030N ARANDELA 5X12X1,5 / 5X12X1,5 WASHER T4005012 ABRAZADERA CAJA LAMINAS 30X45 / CLAMP 30X45 B640005 TUBERA ADMISION TRIAL / INLET MANIFOLD MT120316131...
  • Page 8 Selector / Shift cam TXT-PRO 03...
  • Page 9 Nº DESCRIPCION / DESCRIPTION 125 / 200 / 250 / 280 c.c. Cant. CTO. PEDAL CAMBIO / GEAR OEDAL COMPLETE MT280238026 PUNTERA PEDAL CAMBIO / GEAR PEDAL END ME25636027 REMACHE PUNTERA CAMBIO / RIVOT PEDAL END ME25636030 MUELLE PUNTERA PEDAL CAMBIO / PEDAL END SPRING M121000 COJINETE 12X24X6 2Z DESMO / 12X24X6 2Z DESMO BEARING MT280238032...
  • Page 10 Cárter / Crankcase TXT-PRO 03...
  • Page 11 Nº DESCRIPCION / DESCRIPTION 125 / 200 / 250 / 280 c.c. Cant. ALLEN 5X65 ZINCADO NEGRO / 5X65 BLACK ALLEN BOLT T0315065 ALLEN 5X55 ZINCADO NEGRO / 5X55 BLACK ALLEN BOLT T0305055 ALLEN 5X75 ZINCADO NEGRO / 5X75 BLACK ALLEN BOLT T0315075 ALLEN 5X35 ZINCADO NEGRO / 5X35 BLACK ALLEN BOLT T0305035N...
  • Page 12 Nº DESCRIPCION / DESCRIPTION 125 / 200 / 250 / 280 c.c. Cant. ARANDELA 5X9X1,5 COBRE / 5X9X1,5 WASHER T4000509 TUBO DESVAPORIZADOR / DESVAP. HOSE MT280210012 DESVAPORIZADOR / DESVAP. MIT50010012 TAPON PASO ACEITE CARTER / OIL CARTER PLUG MT280210021 RETEN 30X40X7 / 30X40X7 SEAL ME25636024 RETEN EJE SELECTOR / AXLE SEAL MT280236048...
  • Page 13 Encendido / Ignition TXT-PRO 03 125 / 200...
  • Page 14 Nº DESCRIPCION / DESCRIPTION 125 / 200 c.c. Cant. ALLEN 5X20 / 5X20 ALLEN BOLT T0305020 TAPA ENCENDIDO TRIAL SXXI / COVER FLY-WHEEL MT280210004 TORNILLO M10X25 / M10X25 SCREW T0101025/2 ARANDELA GRUESA 10X23X4 / 10X23X4 WASHER T4001024 VOLANTE MAGNETICO FP8102 DIGITAL / DIGITAL IGNITION FLY-WHEEL MT120234005 ALLEN UFK 5X10 / UFK 5X10 ALLEN BOLT T0315010...
  • Page 15 TXT-PRO 03 Encendido / Ignition 250 / 280...
  • Page 16 Nº DESCRIPCION / DESCRIPTION 250 / 280 c.c. Cant. ALLEN NEGRO 5X20 / 5X20 ALLEN BOLT T0305020N TAPA ENCENDIDO TRIAL SXXI / COVER FLY-WHEEL MT280210004 TORNILLO M10X25 / M10X25 SCREW T0101025/2 ARANDELA GRUESA 10X23X4 / 10X23X4 WASHER T4001024 VOLANTE MAGNETICO FP8102 DIGITAL / DIGITAL IGNITION FLY-WHEEL MT280234005 ALLEN UFK NEGRO 5X10 / UFK 5X10 BLACK ALLEN BOLT T0315010N...
  • Page 17 TXT-PRO 03 Cigueñal / Crankshaft 125 / 200...
  • Page 18 Nº DESCRIPCION / DESCRIPTION 125 c.c. 200 c.c. Cant. CASQUILLO CIGUEÑAL TRIAL / CRANKSHAFT BUSHING MT280212024 TORICA 25X1,5 NBR / NBR 25X1,5 O’RING MT280212025 CHAVETA D10X3X3.7 TRIAL 2002 / D10X3X3.7 KEY MT280234016 CONJUNTO BIELA / CONNECTING ROD KIT, REPAIR MT120212100 NYLON CONTRAPESO / CONTERWEIGHT NYLON MT120212021 ALLEN CONICO UN15933 M6X16/ M6X16 ALLEN BOLT...
  • Page 19 TXT-PRO 03 Cigueñal / Crankshaft 250 / 280...
  • Page 20 Nº DESCRIPCION / DESCRIPTION 250 / 280 c.c. Cant. CASQUILLO CIGUEÑAL TRIAL 280 / CRANKSHAFT BUSHING MT280212024 TORICA 25X1,5 NBR / NBR 25X1,5 O’RING MT280212025 CHAVETA D10X3X3.7 TRIAL 2002 / D10X3X3.7 KEY MT280234016 CONJUNTO BIELA / CONNECTING ROD KIT, REPAIR MT280212100 NYLON CONTRAPESO / CONTERWEIGHT NYLON MT280212021...
  • Page 21 Embrague / Clutch TXT-PRO 03...
  • Page 22 Nº DESCRIPCION / DESCRIPTION 125 / 200 / 250 / 280 c.c. Cant. DISCO EMBRAGUE FORRADO TRIAL SXXI / CLUTCH DISC FIBER MT280232051 DISCO EMBRAGUE ACERO TRIAL SXXI / CLUTCH DISC STEEL MT280232050 DESMULTIPLICADOR EMBRAGUE TRIAL / CLUTCH RELEASE ARM MT280232070 PRENSA EMBRAGUE TRIAL SXXI / PRESSURE PLATE MT280332006...
  • Page 23 Cilindro / Cylinder TXT-PRO 03 125 cc. / 200 cc. 250 cc. / 280 cc.
  • Page 24 Nº DESCRIPCION / DESCRIPTION 125 c.c. 200 c.c. 250 c.c. 280 c.c. Cant. ALLEN 6X25 / 6X25 ALLEN BOLT T0306025 T0306025 ALLEN 6X30 / 6X30 ALLEN BOLT T0306030 T0306030 ARANDELA COBRE 6X10X1.5 / 6X10X1.5 WASHER T4006008 T4006008 T4006008 T4006008 CULATA TRIAL 2003 / CYL. HEAD MT120316000 MT200216000 MT250316000...
  • Page 25 Engranajes cambio TXT-PRO 03 / Gear set...
  • Page 26 Nº DESCRIPCION / DESCRIPTION 125 c.c. 200 c.c. 250 / 280 c.c. Cant. CIRCLIP E15 DIN471 / E15 CIRCLIP MT280236163 ARANDELA 15,2X23X0,5 / 15,2X23X0,5 WASHER T4001523 PIÑON 2/5 / 2/5 GEAR MT280236071 DOLLA / BUSHING MT280236164 ARANDELA 17X23X0,5 / 17X23X0,5 WASHER T4001723 DESPLAZABLE PRIMARIO / PRIMARY SELECTOR DISC MT280236073...
  • Page 27 Carburador / Carburetor TXT-PRO 03 125 / 200 / 250 17 18 20 21...
  • Page 28 Nº DESCRIPCION / DESCRIPTION 125 / 200 c.c. 250 c.c. Cant. CAPUCHON TENSOR CABLE GAS / ADJ. TENSION THROTTLE CABLE M09001055 CTO. TENSOR CABLE / CABLE TENSION SET SCREW M09001230 TENSOR CABLE GAS / CABLE TENSION TUBE M09001032 TORNILLO TAPA CARBURADOR / SCREW COVER CARBURETOR M09001025 TAPA CARBURADOR / COVER CARBURETOR M09001156...
  • Page 29 Nº DESCRIPCION / DESCRIPTION 125 / 200 c.c. 250 c.c. Cant. TORICA CUBETA GASOLINA / O’RING FUEL BOWL M09001085 CUBETA GASOLINA / FUEL BOWL M09001150 CHICLE PRINCIPAL / MAIN JET M09006105 M09006118 TORICA TAPON CUBETA / O’RING M09001090 TAPON CUBETA GASOLINA / FUEL BOWL BOLT M09001155 KIT JUNTAS CARBURADOR / GASKET CARBURETOR KIT M09001101...
  • Page 30 Carburador / Carburetor TXT-PRO 03...
  • Page 31 Nº DESCRIPCION / DESCRIPTION 280 c.c. Cant. CAPUCHON TENSOR CABLE GAS / ADJ. TENSION THROTTLE CABLE M09001055 TENSOR CABLE GAS / CABLE TENSION TUBE MT280390036 CURVA TENSOR / TENSION CONDUCTION MT280390041 TORNILLO TAPA CARBURADOR / CARBURETTOR COVER SCREW MT280390042 TAPA COMPUERTA / SLIDE COVER MT280390024 MUELLE COMPUERTA / SLIDE SPRING MT280390026...
  • Page 32 Bomba de agua TXT-PRO 03 / Water pump...
  • Page 33 Nº DESCRIPCION / DESCRIPTION 125 / 200 / 250 / 280 c.c. Cant. PASADOR 3X22 EJE BOMBA / PUMP AXIS PIN MT280218009 EJE BOMBA AGUA / AXLE TURBINE MT280218006 TORICA 37X1.5 TAPA BOMBA AGUA / O’RING WATER PUMP COVER MT280218008 RETEN 10X35X7 DUO FKM / WATER PUMP SEAL MT280210020 TURBINA BOMBA AGUA / WATER PUMP TURBINE...
  • Page 34 NOVIEMBRE 2002 C/ UNICEF nº 17 · Poligon Industrial Torremirona · 17190 Salt (Girona) SPAIN · Tel: +34 902 47 62 54 Fax: +34 902 47 61 60 E-mail: officegg @ gasgasmotos.es / partsgg @ gasgasmotos.es · Web: www.gasgasmotos.es...

This manual is also suitable for:

2003 txt pro 1252003 txt pro 2002003 txt pro 2502003 txt pro 280
