User Manual
FOCUS-SERIES
FOCUS Venue
FV-100
FV-200
Version 1.0 / June 2019
Copyright by Fohhn Audio AG 2019; all rights reserved.
Please read this user manual through carefully before putting the system into operation and keep
it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FV-200 and is the answer not in the manual?

Questions and answers

Related Manuals for Fohhn FV-200

Summary of Contents for Fohhn FV-200

  • Page 1 User Manual FOCUS-SERIES FOCUS Venue FV-100 FV-200 Version 1.0 / June 2019 Copyright by Fohhn Audio AG 2019; all rights reserved. Please read this user manual through carefully before putting the system into operation and keep it for future reference.

  • Page 2: Table Of Contents

    4.1 Wiring ............................36 4.2 General configuration ......................... 40 4.3 Hardware and software requirements ..................43 4.4 Downloading and Installing Fohhn Audio Soft ................43 Fohhn-Net ID Allocation ....................... 44 4.6 Identifying Connected Systems ....................45 4.7 Renaming Devices / Channels ..................... 47 4.8 Graphically Arranging the Loudspeaker Systems ................
  • Page 3 4.11.2 Password Lock ........................50 4.11.3 Tilt Sensor ........................... 50 4.12 Adjusting the level relation within an array ................51 5. Control via Fohhn Audio Soft ....................52 5.1 Beam Steering – the functional principle ..................52 5.1.1 Side Lobe Free Technology ....................53 5.1.2 Two Beam Technology (Two Beam Mode) ................

  • Page 4: Introduction And General Information

    – even in the most acoustically challenging venues. All the functions of a Focus Venue system can be controlled using a single piece of software, Fohhn Audio Soft. All Focus Venue systems are available in both mobile and fixed installation variants.

  • Page 5: General Safety Instructions

    To prevent injury caused by a collapsing system, this device must be securely mounted in accordance with the rigging instructions and current safety guidelines. Only use the specially designed Fohhn® mounting accessories or components, which are explicitly specified in the rigging instructions.

  • Page 6: Electrical Safety Information

    (e.g. with unsuitable packaging) If necessary, please contact your Fohhn® dealer and the transportation company immediately. Contact details can be found in the appendix to this user manual. 1.1.3 Electrical Safety Information Focus Venue systems are Protection Class 1 appliances.

  • Page 7: Acoustic Safety Information

    Focus Venue loudspeaker systems have the following connectors located at the top connection panel: • Audio and control data In (AIREA, etherCON) • Audio In/Out (AES/EBU, XLR) • Control data In/Out (Fohhn-Net, etherCON) • Power supply In (powerCON) At the bottom connection panel: • Audio and control data Out (AIREA, etherCON) •...

  • Page 8: Operating Conditions

    Important: To enable communication between a Windows PC with Fohhn Audio Soft installed and the Focus Venue loudspeaker system, a Fohhn® network adapter (e.g. NA-11 Fohhn-Net USB Adapter, NA-3 or NA-4 Fohhn-Net Ethernet Adapter) or a connection to a Fohhn® AIREA output is required.

  • Page 9: Storage And Transportation

    1.3 Storage and Transportation Please note the following: The device should only be transported on its dedicated transport dolly or wheelboard. Store the device in a dry environment, with a constant ambient temperature, in order to avoid condensation. The permitted ambient temperature range for storing the device is -10 °C to +70 °C. Due to fluctuations in temperature during transportation and storage, condensation may start to build up on the surface of the device.

  • Page 10: The Product

    Conventional mechanical curving, i.e. the physical adjustment of the line curvature is no longer necessary, though in some cases mechanical inclination of a Focus Venue array may improve the acoustical result. The current version of the required Fohhn Audio Soft software can be downloaded free of charge from www.fohhn.com The following modules are available: •...
  • Page 11 800 Hz. FV-200 are linkable to longer stacks in an array with other FV-200. The FV-200 features the Fohhn Convertible Dispersion Technology (CDT): Its dispersion pattern is remotely switchable via Fohhn Audio Soft between omnidirectional (with enhanced low end) or cardioid (with rear sound attenuation) To learn more about CDT and its use, please refer to chapter 5.4...

  • Page 12: Product Identification

    The modules can be acoustically and mechanically combined as required, in order to suit the particular application and space situation. Long reach and optimal sound results can be achieved even in acoustically difficult situations. 2.2 Product Identification The Focus Venue module’s type designation can be found on the upper connection panel at the rear side of the speaker.

  • Page 13: Delivery And Unpacking

    Focus Venue system is delivered with the following: Your • 1 x three-part cable set for the electrical connection of two adjacent Focus Venue modules ( PowerCON for supply voltage, XLR for audio signal, RJ45/etherCON for Fohhn-Net network or AIREA) • 1 x PowerCON mains cable •...

  • Page 14: Accessories

    2.4 Accessories Setting up a Focus Venue module requires a Windows PC (Windows 7 or higher) with Fohhn Audio Soft installed and a Fohhn® network adapter or – if connected via Fohhn AIREA – an AIREA breakout Product ID Article number...
  • Page 15 FF-FV-100/200 DO-FV-100/200 RC-FV-Connect...
  • Page 16 RC-FF-FV-100/200 TC-FV-DO...

  • Page 17: Mechanical Setup And Rigging

    Each Focus Venue module has four suspension points at the top, each equipped with a recessible steel latch and four respective slots for suspending further FV-modules at the bottom. The Fohhn ILS rigging system connects latch and slot. It is spring-loaded, self-securing, easy to use and without any loose parts like ball lock pins on steel cords.
  • Page 18 To move the latch, a knurled-head screw acts as a handle and may be tightened as soon as the latch is connected to the above rigging pin to avoid rattling noise at high SPL of the system. A yellow tag on the latch indicates, that the latch is not connected to the respective slot in the upper module or flying frame.

  • Page 19: Rigging And Landing A Focus Venue System

    FV-100 and FV-200. If an FV-100 downfill adapter or a pull back frame/downfill adapter with Fohhn PT-70 or other fill systems is added, the number of cabinets has to be reduced accordingly.
  • Page 20 Danger! Please note: Make sure all four latches of the top module are at the upper stop (no yellow tag visible) and all four rigging pins are pushed through the frame, their ball bearings visible! Otherwise it is not safe to hoist the system!
  • Page 21 To rig the system, take the rigging skids out of their parking position and insert them into the central suspension rail. Again, make sure the quick release pins are safely assembled, their ball bearings protruding on the opposite side of the rail. Warning! If any other shackle than the supplied one is used, be aware that the WLL must not be less than 4,75 tons at a safety factor of at least 6!

  • Page 22: Forward Inclination Of A Focus Venue System

    • Pick point 13, quick release pins in hole 12 and 14: The number of FV-200 modules is greater than or equal to the number of FV-100 modules in a straight array. • Pick point 12, quick release pins in hole 11 and 13: The number of FV-200 modules is less than the number of FV-100 modules in a straight array.

  • Page 23: Safety Chains

    If a downfill spaker with TV-spigot is flown below the Focus Venue, the inclination angle is limited to 25° towards vertical position. 4. A straight array of up to four (4) Focus Venue modules may be inclined front-to back downwards or upwards in a maximum angle of 40° towards vertical position, a pull back frame/downfill adapter is required.

  • Page 24: Flying From The Hook Of A Crane Or Chain Hoist

    Lift off the cover from the cabinets and store it safely. 2. Connect each Focus Venue module to Fohhn Audio Soft and check its Fohhn-Net ID.
  • Page 25 Fohhn-Net ID. This can be removed before the system is actually flown. Further information on allocating and changing ID numbers can be found in chapter 4.5 as well as in the Fohhn Audio Soft user manual. This can be downloaded free of charge from our website: www.fohhn.com It may also be helpful to put together a brief overview of all integrated Fohhn-Net devices, along with their respective ID numbers.
  • Page 26 To secure the system correctly, please pay careful attention to the “Safety Chains” section (3.2.3). 6. Connect the system to its supply cables for mains power, network (Fohhn-Net) and audio signal. (For details on this, please refer to chapter 4) All cables have to be of sufficient length to form a loop.
  • Page 27 At this point, there are two different possibilities of setting the mains power switch, depending on how the array is wired. Please refer to chapter 4.1 and 4.2 7. Raise the flying frame and the top module to a suitable height that enables you to position the second module below it.
  • Page 28 9. Lower the upper module onto the lower one. The latches will guide them into correct position. Please note the following: a. There shouldn´t be any gap between the two modules. Danger! b. Stop the motor as soon as the chain loses its tension! Otherwise there is a risk for longer arrays to tilt and tip over! c.
  • Page 29 AIREA in by the provided RJ45 cable (recommended) c. Network and audio interconnection could alternatively be done by using separate cables for AES/EBU (XLR) and Fohhn-Net (RJ45). In this case, some features of the system cannot be used. (For details on this, please refer to chapter 4).
  • Page 30 13. Disengage all four ILS catches of the lower module to release it from the transport dolly and raise the modules from the dolly 14. Repeat step 7 to 13 for all modules in the array. 15. Hoist the completed Focus Venue system to its final working height. 16.

  • Page 31: Landing An Array

    3.2.5 Landing an array Landing the system is basically done in reverse order. Therefore, please observe the following: Danger! • Make sure the floor is suitable to bear the weight of the entire array, flat and even. If you have to work on sloping terrain, it could get hard to disengage the ILS between the modules and you have to take extra care to prevent the dolly from moving.
  • Page 32 2. Start by inserting the frame on one side of the connector panel, then insert it on the other side 3. Fold out the bottom of the rain cover towards the connector panel 4. Tilt the lid outwards then fasten the velcro on each side. Always make sure the air entrance (bottom panel) and outlet (top panel) are not blocked by the rain cover! The velcro has to be fastened as shown below, otherwise the system is likely to overheat and switch off.
  • Page 33 Removal: Use the lug to pull up the bottom of the rain cover from the connector panel, then pull out the rain cover by bending it. For transport of the Focus Venue, open the velcro on both sides and flatten the lid against the rear of the amplifier housing...

  • Page 34: Rain Hood For The Top Of An Array

    3.4 Rain hood for the top of an array Since Focus Venue is an active system with built-in electronics, we recommend for its outdoor use to protect each stack or array by a rain hood. Though each module in combination with two rain covers for the connector panels is weatherproof up to a certain degree, in the long run an array may suffer from heavy rain or snow.
  • Page 35 4. If any of the three suspension skids of the flying frame is not in use, the band can be used to seal the odd sleeve. 5. Secure the rain hood to the handle bars of the top FV-module with the straps at both sides...

  • Page 36: Wiring And Software Setup

    2. Fohhn-Net Remote IN The Focus Venue module is connected to the Fohhn-Net via an RJ45 etherCON socket. The receive and send LEDs (d) flash when Fohhn-Net control data is received and sent.
  • Page 37 The module has some sort of hardware fault c. sign LED The blue sign LED can be manipulated using Fohhn Audio Soft. It is connected with a corresponding blue LED at the front of the FV module below the Fohhn- Logo.
  • Page 38 Mains power is available, the module is switched on. permanently off: Makes the stack visually unobtrusive during the show flashing (sign): if switched to “sign” in the Fohhn Audio Soft, it shows which particular FV- modul is operated.
  • Page 39 8. Fohhn-Net Remote Out The parallel Link-Out socket enables Fohhn-Net control signals to be looped through via a RJ45 etherCON socket. 9. Audio Output The digital AES/EBU audio output allows the audio signal to be looped through via a male XLR socket.

  • Page 40: General Configuration

    4.2 General configuration To supply Focus Venue with Fohhn-Net and digital audio, there are several opportunities. Generally, you may use Fohhn AIREA or separate feeds for Fohhn-Net and audio. Using the AIREA input of the Focus Venue provides some advantages: 1.
  • Page 41 • Fohhn-Net & DANTE via AIREA Master • Fohhn-Net & analog audio separately...
  • Page 42 • Fohhn-Net & DANTE (converted to AIREA NET) separately • Fohhn-Net & AES/EBU separately...

  • Page 43: Hardware And Software Requirements

    5. Click on Finish to complete the installation. The software is immediately ready for use following installation and can either be opened via the program symbol on the desktop, or via the Start > All Programs > Fohhn Audio AG > Fohhn Audio Soft path.

  • Page 44: Fohhn-Net Id Allocation

    4.5 Fohhn-Net ID Allocation For the control of Focus Venue systems, each module in the Fohhn-Net must be allocated its own specific ID. Using this ID, each individual Focus Venue module can be clearly identified and controlled from within Fohhn Audio Soft.

  • Page 45: Identifying Connected Systems

    LED on or off, or let it flash in order to visually identify the module. 1. In Fohhn Audio Soft, click on the Status button in the Devices view opens a window with information on the Fohhn-Net status, the operating time and temperature of the connected devices.
  • Page 46 If a Fohhn net ID needs to be changed, either during identification or at a later date, proceed as described in section 4.5...

  • Page 47: Renaming Devices / Channels

    The new name will now appear in the Device List, Devices and Channels views. 4.8 Graphically Arranging the Loudspeaker Systems To make the Fohhn Audio Soft display easier to manage, all loudspeakers and devices in use can be graphically arranged on the software interface. With complex applications and/or in the case of permanent installations, it is particularly recommended that the arrangement of devices on the user interface corresponds with their physical positions in the room.

  • Page 48: Combining Modules To A Speaker Stack

    5. Select Combine speakers. At this point, in addition to the Fohhn-Net ID and the channel, the letter C will also have been added to the loudspeaker pictograms: This means that two or more modules have been linked together to form a “Combined Speaker“.

  • Page 49: Loading Loudspeaker Presets

    4.10 Loading Loudspeaker Presets Fohhn Audio Soft enables factory-made speaker presets to be loaded into a Focus Venue module. To load loudspeaker presets, proceed as follows: 1. Select the appropriate Focus Venue module in the Output Channels view. 2. Right click on the chosen module to open the context menu.

  • Page 50: Password Lock

    4.11.3 Tilt Sensor All Focus Venue systems have a tilt sensor whose data can be read out in Fohhn Audio Soft. The sensor detects the actual mechanical tilt of the installed loudspeaker systems. Please note that it has a tolerance of ± 1.0°.

  • Page 51: Adjusting The Level Relation Within An Array

    For more sophisticated applications with two beams, more than one FV-100 speaker stack per array or three-way systems with low-mid extensions of FV-200, a proper simulation in Fohhn Audio Soft is essential and recommended! Basically, the level of an FV-100 module has been predefined in the speaker preset and is set for combination in a stack with two FV-200 modules.

  • Page 52: Control Via Fohhn Audio Soft

    5. Control via Fohhn Audio Soft The complete control of your Focus Venue systems can be exclusively carried out via Fohhn Audio Soft. A comprehensive description of the software and all its functions can be found in the separate Fohhn Audio Soft user manual. You can download this free of charge from our website: www.fohhn.com...

  • Page 53: Side Lobe Free Technology

    Beam with Side Lobes Focus Venue systems are equipped with Fohhn Side Lobe Free Technology: A specially developed algorithm effectively reduces the side lobes. This results in fewer unwanted sound reflections in the room. Consequently, levels of speech intelligibility are improved and feedback prevention is increased.

  • Page 54: Two Beam Technology (Two Beam Mode)

    This enables an asymmetric beam dispersion to be created for precise sound coverage of two separate listening areas (e.g. stalls and balcony). Two Beam Mode: The production of two separate beams Simultaneous sound coverage of stalls and balcony using two beams from a single Fohhn Focus-Series system...

  • Page 55: Acoustic Centre

    Example of an asymmetric beam Further information on beam configuration and its associated parameters can be found in section 4.7.3 “System Setup (Focus-Series)” of the Fohhn Audio Soft user manual. 5.1.3 Acoustic Centre This function allows you to move the vertical position of a beam’s acoustic centre:...

  • Page 56: Setup In The Beam Steering View

    5.2 Setup in the Beam Steering View To adjust your Focus Venue system to the venue and the particular application, open the Beam Steering view in Fohhn Audio Soft: This display lets you set all the parameters that are relevant to Beam Steering.
  • Page 57 The Device Selection (left), Focus Simulation (centre) and Parameter Field (right) Beam Steering settings in the Parameter Field: • X-Pos (m) This defines the distance of the selected speaker (in metres) in relation to the vertical back wall. • Z-Pos (m) Defines the height of the selected speaker’s lower edge (in metres) in relation to the floor.

  • Page 58: Adjustment Of Dsp Functions

    Fohhn algorithm. Because this makes the room less “excited”, levels of speech intelligibility will be significantly improved. With the overall volume level of the system now somewhat lower as a result, you can use the volume control in Fohhn Audio Soft to compensate for this.

  • Page 59: Using Convertible Dispersion Technology (Cdt)

    5.4 Using Convertible Dispersion Technology (CDT) The FV-200 features the Fohhn Convertible Dispersion Technology (CDT): The dispersion pattern of the FV-200 is remotely switchable between omnidirectional (enhanced low end) or cardioid (rear sound attenuation) The conversion can be done at any stage of the setup-process, its completely independent from settings made in the beam steering section.

  • Page 60: Saving Projects

    Important: If it is part of an already existing stack of FV-200, the software command sent by Fohhn Audio Soft addresses every member of this stack, thus all FV-200 are switched simultaneously to the same mode. In Fohhn Audio Soft, click on the Cardioid checkbox in the Beam steering view. If checked, the FV-200 is in “cardioid”...

  • Page 61: Technical Documentation

    135 kg Optional features Optional colours [5] all RAL-colours Remote control, remote monitoring and simulation Remote control Fohhn-Net, Fohhn Audio Soft Remote monitoring temperature, protect, AES/EBU signals, power supply, Fohhn-Net, Fohhn Audio Soft Simulation Beam Fohhn-Net, Fohhn Audio Soft...
  • Page 62 Delay Output 0 - 640 ms (0 - 220 m) Delay Input 0 - 350 ms (0 - 120 m) System latency 1,2ms CAAD Simulationsdaten Fohhn Designer, EASE Connections and control elements Control elements mains switch (remote-controllable via AIREA connect)
  • Page 63 1 x etherCON Airea Connect / stack link, 1 x XLR AES/EBU, 1 x etherCON Fohhn-Net Outputs 1 x etherCON stack link, 2 x XLR AES/EBU, 2 x etherCON Fohhn-Net Signal inputs AES/EBU 32 kHz – 96 kHz, 16/24 bit...

  • Page 64: Technical Drawings

    6.2 Technical Drawings...

  • Page 68: Pin Assignments And Cable Lengths

    Important: Please also note the maximum permitted cable lengths. To ensure correct operation, these should not be exceeded! 6.3.1 CAT cable Fohhn net For the transmission of Fohhn Net control data to, the following specifications apply: RJ-45 Fohhn-Net Pinout Signal...

  • Page 69: Cat Cable Airea Net

    6.3.2 CAT cable AIREA net AIREA includes Fohhn Net, AES/EBU and 48V Power in one cable. RJ-45 Airea Pinout Signal Fohhn-Net+ Fohhn-Net- AES/EBU+ Power+ Power+ AES/EBU- Power- Power- Cable lengths: Use shielded CAT5 cables with RJ45 connectors with a maximum length of 100 m 6.3.3 Audio cable AES/EBU...

  • Page 70: Troubleshooting

    The module is not recognized Several products have the same Change the ID – no ID can by Fohhn Audio Soft. Fohhn-Net ID. (An ID conflict appear twice. (See “4.5 Fohhn- will be displayed in Fohhn Net ID Allocation“). Audio Soft.)

  • Page 71: Service And Repair

    Do not carry out any servicing or any repairs to the device beyond what is listed in the “Maintenance Measures” section below. For details of a Fohhn® Service provider in your area, please contact us at the address on the previous page.

  • Page 72: Glossary

    To communicate with the Focus Venue systems, Fohhn Audio Soft requires Fohhn-Net Adapter an adapter for the Fohhn-Net, which is connected to the control computer and transmits the data generated in Fohhn Audio Soft to the systems – e.g. an NA-3 or NA-11. Listening Area This term denotes the area in which sound coverage is required for spectators/listeners.
  • Page 73 and one low-mid module in each case). Two Beam Mode see “Two Beam Technology“ Two Beam Technology Every Focus Venue module can generate two separate, completely independent acoustic beams over its entire line length. All parameters can be separately and individually set for each beam. Working load limit...

  • Page 74: Appendix

    CE marking. The relevant Declarations of Conformity are available on request from Fohhn Audio AG, 72622 Nürtingen 10.3 Trademarks All trademarks and brand names referred to in this manual, which may be protected by third parties, are subject to the provisions of trademark law and the title rights of their respective owners.

  • Page 75: Disclaimer And Copyright

    10.5 Disclaimer and Copyright 10.5.1 Disclaimer The contents of this user manual have been created with great care. However, Fohhn Audio AG cannot guarantee that the information therein (images, text and other representations) is always complete, correct and current. Fohhn Audio AG therefore reserves the right to make changes or additions to the given information at any time.
