Redwall SIP-3020 Installation Instructions Manual

INSTALLATION INSTRUCTIONS
Synthesized Intelligent PIR
Synthesized Intelligent PIR
REDWALL-V series
REDWALL-V series
FEATURES
* Intelligent PIR Detection System
- Detection of ambient temperature and illuminance for
automatic sensitivity management
- Advanced detection algorithm
- Three dual pyro-elements with patented Double Conductive
Shielding
* Anti-vandalism functions
- Anti-rotation function with accelerometer
- Anti-masking function with photo-beam
- Reinforced polycarbonate housing
- Max. 4 m (13 ft.) installation height
* n I d e p e n d e t n s e n i s v i t y t i s e e l
* Detection logic selector
* Detection range selector
* Independent N.C. and N.O. outputs
* Adjustable alarm interval time
• SIP-3020CAM DN (EU), SIP-3020CAM DN (US)
* H g i h q - u l a y t i c a m e a r i m a g : e
* 480 TV lines
* Varifocal lens 3-9 mm
REDWALL-V
: Synthesized Intelligent PIR
• SIP-3020
• SIP-4010
• SIP-404
* UL/c-UL Listed
1
PARTS IDENTIFICATION
Base
Main unit
Fixing screw
for the base
Adjustment screws
(two facing each other)
Angle adjustment guide
Arrow marking
Fixing screw
No. 59-1494-6 1710-11
No. 59-1494-6 1710-11
UL
c o t f r r o n e a f / r r a a e r a s
D a y c ( o o l u ) r N / g i h ( t / B W )
REDWATCH-V
: Synthesized Intelligent PIR
with D/N camera
• SIP-3020CAM DN (EU)
• SIP-3020CAM DN (US)
* UL-1: SIP-3020CAM DN (EU) and
-3020CAM DN (US) are not listed by UL
Far area mirror
Masking plate for far area
Fixing rubber form
Window
Fixing rubber
Fixing screw
form (*1)
for the cover
Masking plate for near
Cover
area (*1)
Near area mirror
*1: Not used for the SIP-4010 and SIP-404.
SIP-3020CAM DN
Camera unit
2
INSTALLATION AND MAINTENANCE NOTES
Failure to follow the instructions provided
Warning
with this indication and improper handling
may cause death or serious injury.
Failure to follow the instructions provided
Caution
with this indication and improper handling
may cause injury and/or property damage.
The check
mark indicates recommendation.
The nix sign indicates prohibition.
Warning
Never repair or
modify product
Nylon wire
loop
When servicing, the sensor
can be hooked onto the base
using the nylon wire loop.
2-1 INSTALLATION HINTS
2.3-4.0 m
(7.6-13 ft.)
The detection zones of Redwall-V and Redwatch-V, which may be
cause of false alarms can be eliminated by masking.
1. To confirm detection zones
Use optional Area View Finder, AVF-1
2. To eliminate unnecessary detection zones
a. Use supplied area masking seals.
b. Use equiped area masking plates.
The following shows an example;
Detection zones and related segments of the mirror of SIP-3020.
See step 4 and 6.
REDWALL-V SIP-3020
* SIP-4010 and SIP-404 do not have a
masking function.
FAR
NEAR
Area View Finder
3020 (521203)
1 2 4 5 6 7
B6
B1
B3 B4
B2 B5
C2 C3 C4
C1 C5 C6
D1 D6
D 3 D 4
D2 D5
E1 E6
E2 E3 E4 E5
F1 F6
F 2 F 3 F 4 F 5
* UL-2: SIP-3020, -4010 and -404 are recommended not to be connected to an alarm initiating
circuit but may be connected to a trouble alarm circuit if nuisance trips are not tolerable.
- 1 -
Caution
Hold the main unit
securely when you
install or service it.
If you remove your
hands from the main
unit when cables are
connected to it, the
main unit may fall
and the connector
cables may break
or the circuit board
may be damaged.
Caution
Verify that the
power is off before
connecting the
wiring.
Mount the detector so that the majority of
traffic flow is across the detection pattern.
1
2 3
4 5 6
7
B1
B2
B3
B4
B5 B6
C1
C2
C3
C4
C5
D1
C6
D2
D3
D4
D5
E1
D6
E2
E3
E4
E6
E5
F1
F2
F3
F4
F5
F6
Area Masking Seals
6 4 2 5
F 6 F 4 F 2 F 5
F
E E 6 E 4 E 2 E 5
D D 6 D 4 D 2 D 5 D 3 D 1
C C 6 C 4 C 2 C 5 C 3 C 1
B B 6 B 4 B 2 B 5
3 1
F 3 F 1
E 3 E 1
B 3 B 1
