Summarization of Contents
Plug and Play Installation
Before You Start Preparation
Ensure necessary components like H-RTK modules, flight controller, and laptop are ready for setup.
Connecting Hardware Components
Connect the ground station and UAV modules to the flight controller and telemetry radios.
Basic Configuration and Operation
Configuring the Base Station with Mission Planner
Set up the base station using Mission Planner, including survey-in and accuracy settings.
Verifying Base Station Status and Signals
Monitor satellite search progress, accuracy, and signal strength indicators in Mission Planner.
Saving Base Station Location
Store the base station's fixed position for future use.
Connecting UAV via Telemetry Radios
Establish communication between the base station and the UAV through telemetry.
Updating GPS Unit Firmware
Downloading and Installing u-Center Software
Obtain and install the u-Center software and necessary drivers for firmware updates.
Uploading New Firmware to GPS Modules
Connect modules to the computer and use u-Center to upload the latest firmware.
Confirming Firmware Version
Verify the successful firmware update by checking the version information in u-Center.
Advanced U-Center Usage and Settings
Real-Time Data Recording and Playback
Learn to record GNSS data for analysis and playback using u-Center's debug message feature.
GPS Unit Diagnostics and Troubleshooting
Use u-Center to diagnose performance, check fix modes, and resolve common issues like signal strength.
Changing Satellite Systems and Configuration
Modify navigation systems (GPS+Beidou) and set survey-in parameters for optimal performance.
Input/Output Ports and Protocol Settings
Configure communication protocols and ports, such as USB, for data transfer and RTK output.
Adjusting Mobile Station Output Frequency
Change the measurement period to increase the position output frequency for the rover module.
