ViewSonic VX2250wm-LED Specifications page 2

VX2250wm-LED
"
22" (21.5 VIEWABLE) LED MONITOR WITH 10,000,000:1 DYNAMIC CONTRAST RATIO
ViewSonic Corporation's QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
*Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection,
offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks
stated herein are the property of their respective companies. Copyright © 2009 ViewSonic Corporation. All rights reserved.
[14938-00B-04/10] VX2250wm-LED
For more product information, visit us on the web at ViewSonic.com
LED Type
Display Area
Optimum Resolution
Contrast Ratio
Viewing Angles
Response Time
Light Source
Brightness
Panel Surface
VIDEO INPUT Analog
Digital
Frequency
Sync
COMPATIBILITY PC
Mac *
®
CONNECTOR Analog
Digital
Power
AUDIO Speakers
POWER Voltage
Consumption
CONTROLS Basic
OSD
ERGONOMICS Tilt
OPERATING Temperature
CONDITIONS Humidity
DIMENSIONS Physical with stand
(W x H x D) Physical without stand 20.5" x 12.7" x 1.8" (521mm x 340mm x 49mm)
Packaging
WEIGHT Net with stand
Net without stand
Gross
VESA ® MOUNT
REGULATIONS
POWER MANAGEMENT
PACKAGE CONTENTS
WARRANTY
22" (21.5" Viewable) Wide Color TFT Active Matrix LCD
18.7" horizontal x 10.6" vertical; 21.5" diagonal
1920x1080p
1000:1 (typ); 10,000,000:1 (dynamic)
170º horizontal, 160º vertical @ contrast ratio > 10:1
5ms (typ)
Long life, 25,000 hrs. (typ)
250 cd/m 2 (typ)
Anti-glare
RGB analog (75 ohms, 0.7/1.0 Vp-p)
DVI-D (TMDS, 100 ohms)
F h : 24~83kHz, F v : 50~75Hz
H/V separated (TTL), composite sync-on-green
VGA up to 1920x1080 non-interlaced
Power Mac G3/G4/G5 up to 1920x1080
™
15-pin mini D-sub (VGA)
DVI-D
3-pin AC plug (CEE22)
2x2-watt
AC 100–240V (universal), 50/60Hz (auto switch)
26W (typ)
Power, 1, down, up, 2
Auto image adjust, brightness, contrast, input select (analog,
digital), ViewMatch ® color adjust (sRGB, 9300K, 7500K,
6500K, 5400K, default, user color - RGB), information
(resolution, H/V frequency, pixel clock, model number,
serial number), manual image adjust (H/V position, H size,
fine tune, sharpness), setup menu (language, resolution
notice, OSD position, OSD timeout, OSD background),
memory recall
Down 5º, Up 20º
32–104º F (0–40º C)
20–90% (non-condensing)
20.5" x 15.9" x 7.5" (521mm x 404mm x 190mm)
22.7" x 19.7" x 5.2" (569.1mm x 495mm x 126mm)
7.5 lb. (3.4 kg)
7.1 lb. (3.2 kg)
10.4 lb. (4.7 kg)
100mm x 100mm
UL, cUL, FCC-B, CB, CE, ENERGY STAR
GS), ERGO (ISO13406-2 &MPR II), MPR II, GOST-R + 20
original copies hygienic, SASO, PCBC, VCCI, BSMI, CCC,
PSB, C-TICK, MIC (KCC), WEEE, RoHS, EPEAT Silver
Meets MPR II and ENERGY STAR
®
LCD display, power cable, VGA video cable, DVI cable,
audio cable, Quick Start Guide, ViewSonic Wizard CD (User
Guide and drivers)
Three-year limited warranty on parts, labor and backlight.
, NOM, GS (covers
®
standards
